- Page 1 User Guide For Free Chlorine Sensor with Analog output A420-FCL User Guide For Free Chlorine Sensor with Analog output A420-FCL...
- Page 2 This document is applied for the following products 1. Introduction Free Chlorine Sensor with Analog output A420-FCL The Chlorine Electrode is an amperometric (or polarographic) electrode (or “probe”) used for continuous measurement of chlorine in drinking water, swimming pools, spas, industrial applications, or dirty/colored samples where colorimetric methods are inadequate.
-
Page 3: Specification
2. Specification Two-electrode amperometric technology with gas permeable membranes Sensing Technology (replaceable) Measuring range 0-10mg/L or 0-20mg/L Accuracy & Resolution +/- 0.1 mg/L Repeatability +/- 0.05 mg/L (25 oC) Response Time T90 < 90s (25 oC) Working Condition 0 .. 50 oC with pH = 5 .. 9 Working Pressure 0 .. - Page 4 3.1. Electrode Assembly steps 1-8 1. Ensure you have the necessary components to assemble the electrode Internal Filled Gel (IFG) Electrode & Membrane Cap Protection Boot Electrode polishing strips 2. Remove the protection boot from the electrode or membrane cap 3.
- Page 5 2. The output current of power source should be more than 100 mA. 3. The A420-FCL output can be measured by multimeter or other devices which allow the analogue input and measurement. The maximum loop resistance of the devices should be less than 400Ω for testing the current...
- Page 6 For the zero point (1st point), it can be obtained in zero chlorine water during the conditioning processing. Generally, the zero point of A420-FCL should be within the specification ranges provided in Tables 1 and 2. The zero point drift is very slow and negligible in most cases.
-
Page 7: Maintenance
5.2. Changing the Internal Filled Gel (IFG) If the zero point of the A420-FCL does not meet the listed specifications it may be necessary to change the IFG. The IFG also needs be changed if the stainless-steel ring (counter electrode) is not submersed in the water when the electrode is powered for more than 5 minutes. -
Page 8: Troubleshooting
(RE) a few times in one direction, and then follow the next steps for electrode assembly. 5.6. Storing the Electrode The A420-FCL electrode can be stored in clean water or stored dry, preferably at normal room temperatures, while not in use. It is recommended to: 1. -
Page 9: Package Include
Problem Possible Cause Solution Reading should appear within 10 No reading (1) Insufficient conditioning. mins. Electrode connection or power No reading (2) Check connection/wiring. supply. No reading and electrode feels warm PCB shorted or corrupted. Replace electrode 1. Water sample is not 1. -
Page 10: Support Contacts
Distributor in Australia and New Zealand Daviteq Technologies Inc No.11 Street 2G, Nam Hung Vuong Res., An Lac Ward, Binh Tan Dist., Ho Chi Minh City, Vietnam. Templogger Pty Ltd Tel: +84-28-6268.2523/4 (ext.122) Tel: 1800 LOGGER Email: info@daviteq.com | www.daviteq.com Email: contact@templogger.net...
