Manual for Sigfox-Ready Single-
Axis Vibration Sensor - WSSFC-
V1A | FW2
Thank you very much for choosing Daviteq Wireless Sensors. We are the leading wireless sensor manufacturer in the
World. We have a wide range of wireless sensors which support different connectivity like LoRaWAN, Sigfox, Sub-GHz,
NB-IoT...Please find out more information at
This manual is applied to the following products
Item code
WSSFC-V1A-025
Product Features
Connectivity Type
Product Type
Mounting Type
Powered by
Information Changes in this version v.s previous version
Item
1
Initial version
To use this product, please refer step by step to the below instructions.
Operating Principle
1. Quick Guide
Reading time: 10 minutes
this
HW Version
Changes
Changed by
D.Q.Tuan
Battery
Installation
Configuration
Specification
link.
Firmware Version
Sigfox
2 parts
Direct process mounting for sensor, wall mount for transmitter
2 x AA batteries 1.5V
Changed Date
29-08-2022
2
Approved by
N.V.Loc
Uplink Payload
Connect to Sigfox Network
Troubleshooting
Calibration
Warranty and Support
Remarks
Approved Date
05-09-2022

Advertisement

Table of Contents
loading

Related Manuals for daviteq WSSFC-V1A-025

Summary of Contents for daviteq WSSFC-V1A-025

  • Page 1 Axis Vibration Sensor - WSSFC- V1A | FW2 Thank you very much for choosing Daviteq Wireless Sensors. We are the leading wireless sensor manufacturer in the World. We have a wide range of wireless sensors which support different connectivity like LoRaWAN, Sigfox, Sub-GHz, NB-IoT...Please find out more information at...
  • Page 2 Finish this part so you can understand and put the sensor in operation with the default configuration from the factory. 1.1 What is the Sigfox-Ready V1A Single-Axis Vibration Sensor and its principle of operation? WSSFC-V1A is a cost-effective, single-axis vibration sensor designed for condition monitoring and preventive maintenance applications.

  • Page 3: What's In The Package

    01 x Wall mounting bracket and screws 01 x Vibration sensor module V1A Figure 2. Product package of WSSFC-V1A-025 1.3 Quick Test With the default configuration, the device can be connected quickly to the Sigfox Network by the following steps.

  • Page 4: Sensor Installation

    For the Uplink Payload structure, please refer to this link. Note: Please select the right Payload document to suit the FW version of the sensor 1.5 Sensor Installation 1.5.1 Dimension drawings Figure 3. Dimensions of Sigfox Transmitter Figure 4. Dimensions of V1A vibration sensor module 1.5.2 Installation The Sigfox-Ready V1A vibration sensor combines a wireless transmitter WSSFC and a V1A vibration sensor.

  • Page 5: Troubleshooting

    Figure 5. Complete set of WSSFC-V1A-025 vibration sensor 1.5.3 Device calibration & configuration Please refer to this link. 2. Maintenance 2.1 Troubleshooting Problems with Sigfox communication like not receiving the packets...please refer to this link to troubleshoot the device. Problems with the sensor functions like not measuring or inaccurate measuring..please refer to this link troubleshoot the sensor part.

  • Page 6: Advanced Guide

    3.1 Operating principle of the Sigfox-Ready V1A Single-axis Vibration Sensor 3.1.1 Operating principle of the complete device The Daviteq Sigfox-Ready V1A Single-axis Vibration Sensor comprises 02 parts connected together as shown below picture. - The Daviteq Sigfox-Ready wireless transmitter - The Daviteq V1A vibration sensor module Figure 6.

  • Page 7: Sensor Configuration

    Interval time to send an uplink message regardless of any conditions constant_A | Default = calibrated value by factory This value will affect the measurement accuracy. DO NOT change this value! Those configuration parameters can be changed by downlink or offline tools. For more other configuration parameters, please refer to the next section.
  • Page 8 TX_POWER int16 Read/Write RF Tx power CONSTANT_A float Read/Write Constant a for scaling measured value ENB_DATGRAM uint16 Read/Write bit0: enable datagram bit1: enable datagram bit2: enable datagram TEMPERATURE_OFFSET_X10 int16 Read/Write Offset adjustment measured temperature value 3.3 Calibration for Sigfox-Ready V1A Vibration Sensor Please refer to this link.
