McCrometer Water Specialties ML04D Operation And Maintenance Manual And Part List

McCrometer Water Specialties ML04D Operation And Maintenance Manual And Part List

2”-20” electronic main line meters

Advertisement

Quick Links

30119-05
Rev. 4.0/07-09
2"-20"
ELECTRONIC
MAIN LINE METERS
MODELS
ML04D, ML08D, ML12D, ML16D, ML20D, ML22D, MLI1D
OPERATION AND MAINTENANCE MANUAL
PARTS LIST
FEATURING:
*MODEL FC101 FLOWCOM REGISTER INDICATOR-TOTALIZER
*CERAMIC BEARING CARTRIDGE PROPELLER
* ONE PIECE SEPARATOR/SPINDLE AND THREADED REVERSE THRUST BEARING CARTRIDGE
3255 WEST STETSON AVENUE
HEMET, CALIFORNIA 92545 U.S.A.
PHONE:
951-652-6811
FAX:
951-652-3078
VISIT OUR WEBSITE:
www.mccrometer.com
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Water Specialties ML04D and is the answer not in the manual?

Questions and answers

Summary of Contents for McCrometer Water Specialties ML04D

  • Page 1 OPERATION AND MAINTENANCE MANUAL PARTS LIST FEATURING: *MODEL FC101 FLOWCOM REGISTER INDICATOR-TOTALIZER *CERAMIC BEARING CARTRIDGE PROPELLER * ONE PIECE SEPARATOR/SPINDLE AND THREADED REVERSE THRUST BEARING CARTRIDGE 3255 WEST STETSON AVENUE HEMET, CALIFORNIA 92545 U.S.A. PHONE: 951-652-6811 FAX: 951-652-3078 VISIT OUR WEBSITE: www.mccrometer.com...
  • Page 2: Warranty

    State of California. Copyright © 2000-2007 McCrometer. All written material should not be changed or altered without permission of McCrometer. The published technical data and instructions are subject to change without notice. Contact your McCrometer representative for current technical data and instructions.
  • Page 3 UNCRATING. When uncrating the meter, any damage due UNCRATING to rough or improper handling should be reported to the transportation firm and McCrometer. If for any reason it INSTALLATION is determined that the unit or parts of the unit should be...
  • Page 4 1/32” and should allow cartridge to be unscrewed without damaging the spindle III. MAINTENANCE. McCrometer products have been carefully thread. NOTE: If the bearing area appears to be clogged designed to be as maintenance free as possible. Periodic...
  • Page 5 30119-05 Rev. 4.0/07-09 and reverse thrust bearing cartridge (#6) by turning tool reverse thrust bearing cartridge. T-2402X-1 counterclockwise unscrewing the reverse thrust Thread the reverse thrust bearing cartridge on the bearing cartridge (#6) from the spindle (#12). The propeller spindle (#12) until the trailing edge of the propeller contacts assembly with reverse flow cartridge will now slide off the the gearbox (#16).
  • Page 6 If it is determined that the meter should be returned for repair, please notify McCrometer prior to shipment. Each meter must be properly packaged to prevent damage to the meter in shipment.
  • Page 7 30119-05 Rev. 4.0/07-09 MAIN LINE METER INSTALLATION INSTRUCTIONS...
  • Page 8 30119-05 Rev. 4.0/07-09 2”-20” ELECTRONIC MAIN LINE METERS MODELS ML04D, ML08D, ML12D, ML16D, ML20D, ML22D, MLI1D PARTS LIST (Provide Meter Serial Number When Ordering Parts) Part Number Description none 7-MLI1D-* Model MLI1D Main Line Meter Head Assembly 5-2425-‡-PT Propeller Assembly (Items 2 thru 8) 3-2425-‡-P Propeller 1-1125-6...
  • Page 9 30119-05 Rev. 4.0/07-09 2”-20” ELECTRONIC MAIN LINE METERS MODELS ML04D, ML08D, ML12D, ML16D, ML20D, ML22D, MLI1D *MODEL FC101 DIGITAL INDICATOR-TOTALIZER ASSEMBLY *CERAMIC BEARING CARTRIDGE PROPELLER *ONE PIECE SEPARATOR/SPINDLE AND THREADED REVERSE THRUST BEARING CARTRIDGE References to 26-29 not used.
  • Page 10 30119-05 Rev. 4.0/07-09 WARNING: BEFORE REMOVING THE METER HEAD FROM THE PIPELINE THE WATER MUST BE TURNED OFF AND PRESSURE MUST BE RELIEVED FROM THE LINE. SERIOUS INJURY CAN RESULT FROM REMOVING A METER HEAD UNDER PRESSURE.
