DEVI Devireg 550 Instruction Manual

Devireg 550
Setting up your Devireg 550 programmable thermostat with
your devimat system
If the thermostat is displaying 'CODE' ,
initially you will ONLY be presented with
step 1 and step 4, set these as described
below.
Once you have either completed steps 1 and 4, or the
controller is displaying something other than 'CODE' ,
you must press and hold the button until the word
'CODE' is displayed and follow the steps below:
STEP 1 - Setup code
Rotate button to select code 0044 and
then press button once
STEP 2 - Operating mode
Rotate button to select code ALO and
then press button once
STEP 3 - Adaptive function
Rotate button to select 'AdAP' and then
press button once
STEP 4 - Sensor selection
Rotate button to select 'FS' to activate the
floor sensor, then press button
(not rFs or rs)
STEP 5 - Maximum floor temp. selection
At 'nt' rotate button to select either of
the following temperature selection
maximum floor temperatures, then press
button
Tiles on timber based floor 29°C
Tiles on concrete based floor 40°C
Timber covered floors (parquet etc.) 27°C
STEP 6 - Off periods
'LO' should be displayed, you should
rotate dial to select -30°C, then press
button
STEP 7 - Save settings
Save Settings - Press button once
(if the controller is now displaying 'CODE' , disconnect
the power to the controller and then reconnect)
Now you can set the time and day on the controller.
If any steps are skipped, hold button until word 'CODE'
is displayed to reset controller and start again at step 1
Press and hold button until
left corner. The display now shows the time and day
(number 1 represents Monday, number 7 is Sunday).
Rotate the dial to show the correct time and day of the
week and then press the button to save the correct time
setting and press button once.
Finally you can now set how you wish the controller to
operate.
You can operate the controller in either Manual or Timer
Mode, by pressing the button you can toggle between
these two modes.
is displayed in bottom
