Replacing the Battery
5. Gently pull on the battery's connector to disconnect it from its socket.
Battery
Battery's wires
Battery's connector
6. Pull the battery up to remove it.
7. Place the new battery so that its wires are located on the left side,
toward the front.
Wires
25/30
