Radio control model
R/C Flugmodell
NE-1 NAVY CUB
TECHNISCHE DATEN
Spannweite
Lange
Elektroantrieb
(siehe nächste Seite)
Verbrennerantrieb
Fernsteuerung
WARNING! This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of controll and
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
ACHTUNG! Dieses ferngesteuerte Modell ist KEIN Spielzeug! Es ist für fortgeschrittene Modellflugpiloten bestimmt,
die ausreichende Erfahrung im Umgang mit derartigen Modellen besitzen Bei unsachgemäßer Verwendung kann
hoher Personen- und/oder Sachschaden entstehen. Fragen Sie in einem Modellbauverein in Ihrer Nähe um
professionelle Unterstützung, wenn Sie Hilfe im Bau und Betrieb benötigen. Der Zusammenbau dieses Modells ist
durch die vielen Abbildungen selbsterklärend und ist für fortgeschrittene, erfahrene Modellbauer bestimmt.
SPECIFICATIONS
2400mm
1510mm
20cc 2-T
6 Kanal / 6 Servos
INSTRUCTION MANUAL
MONTAGEANLEITUNG
Wingspan
Length
Electric Motor
Glow Engine
Gasoline Engine
Radio
6 Channel / 6 Servos
2400mm
1510mm
(See next page)
.91 2T / 1.20 4T
20cc 2T
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Nexa NE-1 NAVY CUB
Summary of Contents for Nexa NE-1 NAVY CUB
- Page 1 Radio control model INSTRUCTION MANUAL R/C Flugmodell MONTAGEANLEITUNG NE-1 NAVY CUB SPECIFICATIONS TECHNISCHE DATEN Wingspan 2400mm Spannweite 2400mm Length 1510mm Lange 1510mm Electric Motor (See next page) Elektroantrieb (siehe nächste Seite) Glow Engine .91 2T / 1.20 4T Verbrennerantrieb 20cc 2-T...
- Page 2 REQUIRED FOR OPERATION (Purchase separately) BENOTIGTE KOMPONENTEN FUR DEN ABFLUG (Nicht enthalten) Extension for aileron servo, throttle servo. Glow Engine: 1.20 4T Gas Engine: 20cc Fuel tube Minimum 6 channel radio for airplane with 6 servos Glow Engine: 1650W Brushless .Motor control x1 .Aileron x2 .91 2T Motor...
-
Page 3: Horizontal Stabilizer
NAVY CUB section 1 HORIZONTAL STABILIZER Full the elevator out of the horizontal stabilizer. Cut two slots (only the covering) on the top and along the trailing edge of the horizontal stabilizer. Cut away only the covering both side Trial fit the horizontal stabilizer in place . Check the alignment A’... - Page 4 NAVY CUB section 2 HORIZONTAL STABILIZER Pull the horizontal stabilizer through the other side Cut away only the covering of the fuselage and repeat the previous procedures on the top and bottom to glue the second torque rod wire into the horizontal stabilizer.
-
Page 5: Vertical Stabilizer
NAVY CUB section 3 VERTICAL STABILIZER Cut away only the covering on the left and right side. Remove the vertical stabilizer from the fuselage. Using the sharp hobby knife, carefully cut away the covering inside the lines which were marked above. 5 min. -
Page 6: Main Landing Gear
NAVY CUB section 5 TAIL WHEEL & RUDDER Thin CA 2x10mm BOTTOM - VIEW / Unteransicht ..2 2x10mm screw ..2 NAVY CUB section 6 MAIN LANDING GEAR 4X20mm screw ..6 BOTTOM - VIEW / Unteransicht Cut away only the covering * WARNING: When removing any covering from the airframe, please ensure that you secure the cut edge with CA or similar cement. - Page 7 NAVY CUB section 7 MAIN LANDING GEAR 3mm plywood connector 3x10mm 3x10mm screw ..2 Connector ..2...
- Page 8 NAVY CUB section 8 MAIN LANDING GEAR 2x6mm screw ..24 NAVY CUB section 9 MAIN LANDING GEAR Heat sink Heat sink- long 100mm ...1 3x10mm screw ..8...
- Page 9 NAVY CUB section 10 MAIN LANDING GEAR 4x50mm screw Spring Spring ...4 4x50mm screw ...2 4mm nut....4 4mm washer...6...
- Page 10 NAVY CUB section 11 MAIN LANDING GEAR Lighter...
- Page 11 NAVY CUB section 12 ENGINE Using a aluminum motor mounting plate as a template, mark the fire-wall where the four holes are to be drilled (1). Remove the aluminum motor mounting plate and drill a 5mm hole through the plywood at each of the four marks marked (2). Aluminum motor mounting plate Note: The aluminum motor mounting and screws included with the engine.
- Page 12 NAVY CUB section 13 ELECTRIC MOTOR and COWLING Using a aluminum motor mounting plate as a template, mark the fire-wall where the four holes are to be drilled (1). Remove the aluminum motor mounting plate and drill a 5mm hole through the plywood at each of the four marks marked (2).
- Page 13 NAVY CUB section 14 COWLING 2x6mm screw black rubber tube metal wire black rubber tube with metal wire inside IN CASE OF ELECTRIC MOTOR USING...
- Page 14 NAVY CUB section 15 COWLING 4 - 6mm 1.5mm 2.mm 2.5x10mm ..5 2.5x10mm Relive the cowl to clear the silencer, carburetor and plug. IN CASE OF GASOLINE ENGINE USING FUEL TANK To muffler Filler tube Rubber stopper To engine 3x35mm screw Blow Water 23x8mm screw...
- Page 15 NAVY CUB section 16 SERVO & LINKAGES Elevator Servo (1) (3) Rudder Servo (2) Throttle Servo (4) 2x8mm metal tube cable 3mm set Screw ..4 Elevator pushrod ..2 ..2 2 mm 2x8mm metal tube ..4 ....2...
- Page 16 NAVY CUB section 17 PILOT CHAIR NAVY CUB section 18 AILERON SERVO & LINKAGE Aileron servo 2x10mm Servo mount screw 1.5mm Extension cord not include. Aileron servo hatch WING BOTTOM BOTTOM - VIEW / Unteransicht Control horn ......2 2x30mm screw ....6 Connector ....2...
- Page 17 NAVY CUB section 19 AILERON SERVO & LINKAGE Aileron servo and hatch Aileron servo and hatch RIGHT LEFT Aileron control horn Aileron servo hatch 2X30mm Aileron push rod Wing - Bottom view / Unteransicht WING SECTION Pushrod Servo hatch NAVY CUB section 20 WING: DOWEL and CONNECTOR 7mm diameter dowel BOTTOM - VIEW / Unteransicht...
-
Page 18: Wing Installation
NAVY CUB section 21 WING INSTALLATION Aluminum tube Slide the aluminum tube into the fuselage as shown. Carefully, push the wing halves to the fuselage. Do the same way with other wing halves. Secure the wing halves in place using 6mm nylon bolts. Do the same way with other wing halves. - Page 19 NAVY CUB section 22 WING BRACE Stabilizer...
- Page 20 NAVY CUB section 23 CABLE WIRE 0.7mm dia. Cable ...1 roll 2mm metal tube ....4 Aluminum tube ..2 cable ..2 NAVY CUB section 24 BALANCE & CONTROL SURFACE Aileron 20mm 20mm 50mm Rudder Querruderausschlag 50mm Seitenruderausschlag Elevator 25mm 25mm 86 ~ 91mm Hohenruderausschlag Do not try to fly an out-of balance model! Uberprufen Sie vor dem Flug den Schwerpunkt.
