Nexa DORNIER DO-27 Instruction Manual

Radio control model
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Radio control model
R/C Flugmodell
INSTRUCTION MANUAL
MONTAGEANLEITUNG
Designed for brushless electric motors
Entwickelt für Brushless Elektro Motoren
TECHNISCHE DATEN
Spannweite
Lange
Elektroantrieb
(siehe nächste Seite)
Verbrennerantrieb
7.5cc 2-T / 8.5cc 4-T
Fernsteuerung
6 Kanal / 6-7 Servos
WARNING! This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of controll and
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
ACHTUNG! Dieses ferngesteuerte Modell ist KEIN Spielzeug! Es ist für fortgeschrittene Modellflugpiloten bestimmt,
die ausreichende Erfahrung im Umgang mit derartigen Modellen besitzen Bei unsachgemäßer Verwendung kann
hoher Personen- und/oder Sachschaden entstehen. Fragen Sie in einem Modellbauverein in Ihrer Nähe um
professionelle Unterstützung, wenn Sie Hilfe im Bau und Betrieb benötigen. Der Zusammenbau dieses Modells ist
durch die vielen Abbildungen selbsterklärend und ist für fortgeschrittene, erfahrene Modellbauer bestimmt.
SPECIFICATIONS
Wingspan
1620mm
Length
1210mm
Electric Motor
Glow Engine
Radio
DORNIER
DO-27
(.46-.52 class glow conversion optional)
(7,5 -8,5cc Glühzündermotor Einbau möglich)
(See next page)
.46 2Stroke / .52 4-Stroke
6 Channel / 6-7 Servos
63 in.
47.6 in.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DORNIER DO-27 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nexa DORNIER DO-27

Summary of Contents for Nexa DORNIER DO-27

  • Page 1 Radio control model DORNIER R/C Flugmodell INSTRUCTION MANUAL DO-27 MONTAGEANLEITUNG Designed for brushless electric motors (.46-.52 class glow conversion optional) Entwickelt für Brushless Elektro Motoren (7,5 -8,5cc Glühzündermotor Einbau möglich) SPECIFICATIONS TECHNISCHE DATEN Wingspan 63 in. Spannweite 1620mm Length 47.6 in. Lange 1210mm Electric Motor...

  • Page 2: Horizontal Stabilizer

    DORNIER DO-27 1-Horizontal stabilizer Full the elevator out of the horizontal stabilizer. Cut away only the film both side Aluminum wing joiner B=B’ B’ Stabilizer Stabilizer A=A’ A’ When you are satisfied with the alignment, use a pencil to trace around the top and bottom of the stabilizer where it meets the fuselage.

  • Page 3: Vertical Stabilizer

    DORNIER DO-27 2-Horizontal stabilizer WARNING! Securely glue together. Thin CA glue If coming off during flights, you lose control of your airplane which leads to accidents ! Vergewissern Sie sich, sauber geklebt zu haben. Andernfalls konnen Probleme mit der Flugeigenschaft...
  • Page 4 DORNIER DO-27 4-Vertical stabilizer When you are satisfied with the alignment, use a pencil to trace around the right and left of the stabilizer where it meets the fuselage. Cut away only the covering both side WARNING! Securely glue together.

  • Page 5: Rudder Control Horn

    DORNIER DO-27 5-Rudder control horn Control horn ...2 WARNING! Securely glue together. If coming off during flights, you lose control of your airplane which leads to accidents ! Note: The slots for the control horn installation pre- cut at factory.
  • Page 6 DORNIER DO-27 7- Main gear Cut off the shadow area 3X15mm hex bolt ..4 4X40mm screw ..2 4mm nut ......2 ......6 4mm washer 4mm nut 4x40mm screw Aluminum landing gear...

  • Page 7: Electric Motor

    DORNIER DO-27 8- Electric motor Plywood motor mounting Pull the magnetic battery hatch out of the fuselage Aluminum motor mounting plate (included with electric motor set) Using a aluminum motor mounting plate as a template, mark the plywood motor mounting plate where the four holes are to be drilled (A).
  • Page 8 DORNIER DO-27 9- Electric motor continued SIDE-VIEW / Seitenansicht B=B’ Attach the aluminum motor mounting B’ plate on to the motor and secure it in Firewall place with four screws ( included with 113mm motor set) (F). A=A’ A’ ! Engine thrust on balk head...

  • Page 9: Joining The Wing

    DORNIER DO-27 11- Cowling 1/16 1.5mm 2.5x10mm screw ..4 DORNIER DO-27 12- Wing Aileron & flap extension cord Aileron & flap pushrod 1.2mm O Alenk-Gestange Trial fit the control horn into the slot. If the parts will join, but with...
  • Page 10 DORNIER DO-27 14- Joining the wing DORNIER DO-27 15- Decor Note: Cut out the stickers and apply them in the proper area. Do not peel the backing paper off all at once. Peel off one corner of the backing and cut off with scissors.
  • Page 11 DORNIER DO-27 14- Balance and control surface THE CENTER OF GRAVITY IS LOCATED 65 - 70mm BACK FROM THE LEADING EDGE OF THE WING, AT THE FUSELAGE. BALANCE A PLANE UPSIDE DOWN WITH THE FUEL TANK EMPTY. 65-70mm 1- Mount the wing to the fuselage. Using a couple of pieces of masking tape, place them on the top side of the wing (65-70mm) back from the leading edge, at the fuselage sides.
