Nexa Pilatus Porter PC-6 Building Instructions

26-30cc gas engine
Hide thumbs Also See for Pilatus Porter PC-6:

Advertisement

Quick Links

Download this manual
26 ~ 30cc
Gas Engine
RADIO CONTROL MODEL / RC FLUGMODELL
BUILDING INSTRUCTIONS / MONTAGEANLEITUNG
SPECIFICATIONS
Wingspan
Length
Flying weight
Gas Engine
Radio
Technische Daten
Spannweite
Länge
Fluggewicht
Verbrennerantrieb
Fernsteuerung
WARNING! This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of controll and
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
ACHTUNG! Dieses ferngesteuerte Modell ist KEIN Spielzeug! Es ist für fortgeschrittene Modellflugpiloten bestimmt,
die ausreichende Erfahrung im Umgang mit derartigen Modellen besitzen Bei unsachgemäßer Verwendung kann
hoher Personen- und/oder Sachschaden entstehen. Fragen Sie in einem Modellbauverein in Ihrer Nähe um
professionelle Unterstützung, wenn Sie Hilfe im Bau und Betrieb benötigen. Der Zusammenbau dieses Modells ist
durch die vielen Abbildungen selbsterklärend und ist für fortgeschrittene, erfahrene Modellbauer bestimmt.
Pilatus
Porter
Semi scale model
107 in.
78.7 in.
14.4 lbs
26 ~ 30cc
6 Channel / 8 servos
2.720mm
2.000mm
6.500g
26 ~ 30cc
6 Kanal / 8 Servos
PC-6

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pilatus Porter PC-6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nexa Pilatus Porter PC-6

Summary of Contents for Nexa Pilatus Porter PC-6

  • Page 1 PC-6 Pilatus 26 ~ 30cc Porter Gas Engine Semi scale model RADIO CONTROL MODEL / RC FLUGMODELL BUILDING INSTRUCTIONS / MONTAGEANLEITUNG SPECIFICATIONS Wingspan 107 in. Length 78.7 in. Flying weight 14.4 lbs Gas Engine 26 ~ 30cc Radio 6 Channel / 8 servos Technische Daten Spannweite 2.720mm...
  • Page 2 REQUIRED FOR OPERATION (Purchase separately) BENOTIGTE KOMPONENTEN FUR DEN ABFLUG (Nicht enthalten) Extension for aileron servo, Flap servo. Gas Engine: 26 ~ 30cc Minimum 6 channel radio for airplane with 8 servos .Motor control x1 .Aileron x2 .Elevator x2 .Rudder x1 Fuel tube .Flap x 2 GLUE...
  • Page 3 1- Landing gear / Fahrwerk 5.5mm Collar Stellring 3x12mm screw Stopper (metal) 5.5mm Collar Stopper (metal) ....8 ...2 ...4 Nylon strap 5mm landing Collar Kunststoffstreifen 3mm set screw gear ....4 ....4 Aluminum tube 5mm landing gear 5mm Main landing gear (front) Note: All holes on the bottom of the fuselage are pre-drilled at factory...
  • Page 4 2.5mm collar BOTTOM - VIEW / Unteransicht 4- Tail gear / Heckspornrad Tail gear control arm 3x12mm screw ...4 ..1 2.5mm Tail gear 2.5mm Collar ..3 2.5mm collar 2.5mm collar 3x12mm screw BOTTOM - VIEW / Unteransicht 5- Tail gear / Heckspornrad Note: Slide the tail gear push rod in to 3x12mm screw Tail gear control arm...
  • Page 5 7- Vertical Stabilizer See Step 10 (installing the Seitenleiwerk elevator) on next page. BOTTOM - VIEW / Unteransicht 8- Tail gear / Heckspornrad Tail gear push rod 2x350mm rod ..2 Bottom View 9- Horizontal Stabilizer / Hohenleitwerk Thin CA ! Securely glue together. If coming off during 6x22mm dowel flight, you lose control of your air plane.
  • Page 6 10- Horizontal Stabilizer / Hohenleitwerk 1.5mm 2x8mm screw Note: You can fix this detail with screw ..6 or glue. 11- Horizontal Stabilizer / Hohenleitwerk 6X45 Nylon bolt 6x45mm nylon bolt ..1...
  • Page 7 12- Elevator / Hohenruder 5 minute epoxy ! Securely glue together. If coming off during flight, you lose control of your air plane. Apply a thin layer of machine oil or petroleum jelly to only the pivot point of the hinges Petroleum jelly on the elevator, then push the elevator and its hinges into the hinge slots in the trailing edge of the horizontal stabilizer.
  • Page 8 14- Servo Open the rear door (on the right side of the fuselage only) Install the servos as show Elevator servo (R) To right elevator control horn Magnetic piece To left elevator control horn Elevator servo (L) OPEN To ruder control horn Rudder servo SIDE-VIEW / Seitenansicht 15- Engine / Motor...
  • Page 9 16- Fuel tank / Tankeinbau FUEL TANK OPEN SIDE-VIEW / Seitenansicht Filler tube Rubber stopper Air tube Stopper To engine 17- Cowling / Motorverkleidung 2.5x10mm screw ....4...
  • Page 10 18- Li-Po Battery stand 3x12mm screw .....3 Li-Po battery stand (3mm plywood) Put the Li-Po battery in place. Magnetic battery hatch. Install the Li-Po battery stand and secure it in place using three 3x12mm screws Note: Three holes on the battery stand pre-drilled at factory Install the magnetic battery hatch.
  • Page 11 Cut away only the cover 20- Decor / Aufkleber Plywood Plywood Plywood Plastic Plywood (x2) Plywood (x2) 21- Decor / Aufkleber 22- Installing the wing / Tragflacheneinbau Aluminum tube...
  • Page 12 23- Servo installation / Servoeinbau BOTTOM - VIEW / Unteransicht Aileron servo extension cord Using the thread (pre-installed at factory) to slide the aileron and flap extension cord into the wing half. Flap servo extension cord Aileron servo extension cord BOTTOM - VIEW / Unteransicht...
  • Page 13 24- Servo installation / Servoeinbau AILERON SERVO HATCH - BOTTOM VIEW Hard wood servo mount 1.5mm Thin CA ! Securely glue together. If coming off during fly, you lose control of your air plane. 1.5mm Connector ..1 FLAP SERVO HATCH WITH SERVO TOP VIEW IMPORTANT: To be safe, you must attach the four screws...

  • Page 14: Side View

    25- Servo installation / Servoeinbau AILERON SERVO HATCH - BOTTOM VIEW Hard wood servo mount Thin CA ! Securely glue together. If coming off during fly, you lose control of your air plane. 1.5mm Connector ..1 AILERON SERVO HATCH WITH SERVO IMPORTANT: TOP VIEW To be safe, you must attach the four screws...

  • Page 15: Aileron Linkage

    26- Flap and Aileron linkages Aileron Control horn ....1 2x30mm screw ....2 Flap Control horn ....1 The rectangular hole is pre-cut at factory, cut away only the covering. The rectangular hole is pre-cut at factory, cut away only the covering. FLAP LINKAGE Push rod exit BOTTOM...
  • Page 16 27- Installing the wing / Tragflacheneinbau Wooden dowel Wooden dowel 28- Installing the wing / Tragflacheneinbau 5x20mm screw 5mm washer ..2 ....2 29- Installing the wing / Tragflacheneinbau 3x15mm screw / Schraube ......2 Wing 3x15mm sscrew Wing brace The holes on the bottom of the wings and bottom of the fuselage are pre-drilled at factory All blindnuts are...
  • Page 17 30- Door 4mm nylon bolt ....2 Secure the door (left and right side) using the 4x25mm nylon bolt as show. 31- Decor / Aufkleber Cut to open Sticker IMPORTANT: Please do not clean your model with pure alcohol, only use liquid soap with water or use glass cleaner to clean on surface of your model to keep the colour not fade.

  • Page 18: Lateral Balance

    32- Balance / Schwerpunkt Do not try to fly an out-of balance model! Uberprufen Sie vor dem Flug den Schwerpunkt. 90 ~ 95mm 1- Mount the wing to the fuselage. Using a couple of pieces of masking tape, place them on the top side of the wing (90-95mm) back from the leading edge, at the fuselage sides.
