- Page 1 ® R&S NGP800 Power Supply Instrument Security Procedures (Æ1ÊÁ2) 5601605102...
- Page 2 6 Instrument Declassification..............6 1 Overview In many cases, it is imperative that the R&S NGP800 Power Supplies are used in a secured environment. Generally these highly secured environments do not allow any test equipment to leave the area unless it can be proven that no user information leaves with the test equipment.
- Page 3 "National Industrial Security Program Operating Manual (NISPOM)", Chapter 8. 4 Types of Memory and Information Storage The R&S NGP800 Power Supplies contain various memory components. The following table provides an overview of the memory components that are part of your instrument.
- Page 4 Certification and Accreditation of Classified Systems under the NISPOM. Main Processor Internal Caches and Memory The R&S NGP800 series have internal caches and memory in its main processor on the front controller board. These contain startup and operating instructions, operating data and states that are critical to device performance and operation.
- Page 5 Sanitization procedure: Turn off instrument power SRAM The R&S NGP800 series has up to four 32 KByte SRAM devices which are integrated in the power supply’s channel microcontrollers. The SRAMs contain the control and status/operating data of the channel control firmware and loses its memory as soon as power is removed.
- Page 6 R&S NGP800 1. Press the menu button to the left of the R&S NGP800 series' LCD Panel. 2. Under the "Device" tab, scroll down to select "Save/Recall Device Settings". 3. Select "Factory Reset". Tap "Yes" to proceed when prompted to reset all settings to factory defaults.
- Page 7 ® Instrument Declassification R&S NGP800 © 2020 Rohde & Schwarz GmbH & Co. KG Mühldorfstr. 15, 81671 München, Germany Phone: +49 89 41 29 - 0 Fax: +49 89 41 29 12 164 Email: info@rohde-schwarz.com Internet: www.rohde-schwarz.com Subject to change – Data without tolerance limits is not binding.
