PROPER USE GUIDELINES
Cumulative Trauma Disorders can result from the prolonged use of manually powered hand tools. Hand tools are intended for occasional use and low volume
applications. A wide selection of powered application equipment for extended-use, production operations is available.
Stationary Crimping
Dies (Anvils)
Head
Tool Color Code: Yellow
Tool Dot Code: 1
TOOL
TYPE
PIDG* Vinyl and Nylon Terminal and
y
Splice and PLASTI-GRIP* Terminal
PIDG Insulation Restricting Nylon
59239 4
59239-4
Terminal
59239-8
525692
PIDG Radiation Resistant
Terminal and Splice
Spare Wire Cap 328309
PIDG Vinyl and Nylon Terminal and
y
59287 2
59287-2
Splice and PLASTI-GRIP Terminal
G
Heavy Duty
1. INTRODUCTION
Heavy Head Hand Tools (HHHT) 525692, 59239–4,
59239–8, and 59287–2 are designed to crimp the
product listed in Figure 1 onto the wire also listed.
E
2007 Tyco Electronics Corporation, Harrisburg, PA
All International Rights Reserved
TE logo and Tyco Electronics are trademarks.
*Trademark. Other products, logos, and company names used are the property of their respective owners.
Heavy Head Hand Tools
59239-4, 59239-8,
59287-2, and 525692
Locator
Movable Crimping
Dies (Indenters)
PRODUCT
INSULATION
COLOR CODE
Yellow
y
Yellow with Black Stripe
Yellow with 3 Yellow Stripes
g
y
Yellow with 3 Brown Stripes
Natural with Yellow Stripe
Natural with Black Stripe
Yellow
Yellow
y
Yellow with Black Stripe
Figure 1
TOOLING ASSISTANCE CENTER 1-800-722-1111
PRODUCT INFORMATION 1-800-522-6752
Handles
Insulation Crimping
Adjustment Pin
TYPE
Solid or Stranded
Copper
Stranded Copper
Stranded Copper
Stranded Copper
Stranded Copper
Stranded Copper
Solid or Stranded
Copper
NOTE
Measurements are in metric units [with U.S.
customary units in brackets]. Figures and
i
illustrations are for reference only and are not
drawn to scale.
This controlled document is subject to change.
For latest revision and Regional Customer Service,
visit our website at www.tycoelectronics.com
Instruction Sheet
408-1261
18 OCT 07
Rev F
Ratchet
WIRE
INSULATION
SIZE (AWG)
DIAMETER
(mm [in.])
12-10
5.84-6.35
G
[.230-.250]
16-14 HD
2.41-5.08
12
[.095-.200]
3.02-5.08
10
[.119-.200]
12-10
6.60 [.260]
[
]
G
Max
16-14 HD
12-10
5.33 [.210] Max
12-10
6.99-7.62
G
[.275-.300]
16-14 HD
1 of 9
LOC B
