E2S E2xBL2 Instruction Manual page 6

2
1
A
OPTIONAL LINE MONITORING RESISTOR, CUSTOMER SUPPLIED,
REQUIRED MINIMUM VALUES:
24VDC : 1KΩ MIN, 2W MIN OR 3K9Ω MIN, 0.5W MIN
48VDC : 3.9KΩ MIN, 2W MIN OR 15KΩ MIN, 0.5W MIN
DC LED E2XBL2 UNITS
Line Monitoring
B
Stage 1 Flash Pattern: Apply power to +ve & -ve
Stage 2 Flash Pattern: Apply power to +ve & -ve. Connect Stage 2 to -ve
Stage 3 Flash Pattern: Apply power to +ve & -ve. Connect Stage 3 to -ve
C
+ve OUT
+ve IN
D
-ve OUT
-ve IN
Stage 2
E
Stage 3
F
DRAWING TO BS8888:2000
DRAWN
GEOMETRIC TOLERANCES TO ISO1101:1983
LINEAR DIMENSIONAL TOLS R.S.RAIT
ANGULAR DIMENSIONAL TOLS
CHECKED
G
R.N.POTTS
STANDARDS
APPROVED
Ex N
R.N.POTTS
3 4
+
+
-
-
S2
S3
SURFACE FINISH WEIGHT (Kg)
DATE
05/08/2020
MATERIAL
DATE
05/08/2020
ALTERNATIVE MATERIAL
DATE
05/08/2020
5
6
AC LED E2XBL2 UNITS
Power: Live & Neutral
LIVE OUT
LIVE IN
NEUTRAL OUT
NEUTRAL IN
EARTH OUT
EARTH IN
THIS DRAWING AND ANY INFORMATION OR DESCRIPTIVE
MATTER THEREIN IS COMMUNICATED IN CONFIDENCE AND
IS THE COPYRIGHT PROPERTY OF EUROPEAN SAFETY
SYSTEMS LTD. NEITHER THE WHOLE OR ANY EXTRACT MAY
BE DISCLOSED, LOANED, COPIED OR USED FOR
MANUFACTURING OR TENDERING PURPOSES WITHOUT THEIR
WRITTEN CONSENT.
C EUROPEAN SAFETY SYSTEMS LTD.
AS PER LATEST DATE OF ISSUE SHOWN ABOVE
7 8 9
ISSUE MOD No.
INTRODUCTION
A
RSR - 05/08/2020
ALL DIMENSIONS IN MM
2S
IF IN DOUBT, ASK -
DO NOT SCALE
warning signals
E2xBL2 LED BEACON
TITLE
EUROPEAN SAFETY SYSTEMS LTD
WIRING DIAGRAMS
IMPRESS HOUSE
MANSELL ROAD
ACTON
LONDON W3 7QH
DRAWING NUMBER
SCALE SHEET
WWW.E2S.COM
NTS 1 1
OF
10
REASON - INITIAL - DATE
A
A
B
C
L
L
D
N
N
E
E
E
F
A3
G
D209-06-401
