- Page 1 400W Precision File Belt Sander TTB910SDR EAN:5059340252926 WARNING: Read the instructions before using the product!
-
Page 2: Table Of Contents
Let’s get started These instructions are for your safety. Please read through them thoroughly before use and retain them for future reference. started... Getting Safety information Your product Before you start more detail... Product functions Operation Care and maintenance Trouble shooting Recycling and disposal Guarantee Declarations of conformity... - Page 3 TTB910SDR by TITAN Safety information Safety warnings General power tool safety warnings WARNING!Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.
-
Page 4: Safety Information
Safety information TTB910SDR by TITAN c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock. d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. - Page 5 TTB910SDR by TITAN Safety information on invites accidents. d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury.
- Page 6 Safety information TTB910SDR by TITAN Safety warnings d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
- Page 7 TTB910SDR by TITAN Safety information Belt sander and drum sander safety warnings Hold the power tool by insulated gripping surfaces, because the sanding surface may contact its own cord. Cutting a "live" wire may make exposed metal parts of the power tool "live" and could give the operator an electric shock.
- Page 8 Safety information TTB910SDR by TITAN Safety warnings low-noise operating modes as well as wear personal protective equipment. Take the following points into account to minimise the vibration and noise exposure risks: > Only use the product as intended by its design and these instructions.
- Page 9 TTB910SDR by TITAN Safety information injury and damage remain. The following dangers can arise in connection with the structure and design of this product: > Health defects resulting from vibration emission if the product is being used over long periods of time or not adequately managed and properly maintained.
- Page 10 Safety information TTB910SDR by TITAN Safety warnings > Silica is a natural mineral present in large amounts in things like sand, sandstone and granite. It is also commonly found in many construction materials such as concrete and mortar. The silica is broken into very fine...
- Page 11 TTB910SDR by TITAN Safety information Please always work with approved safety equipment, such as those dust masks that specially designed to filter out microscopic particles and use the dust extraction facility at all time. For more information please see the HSE website: http://www.hse.gov.uk/construction or...
- Page 12 Safety information TTB910SDR by TITAN Safety warnings The declared vibration emission value should be used as a minimum level and should be used with the current guidance on vibration. Calculating the actual period of the actual period off use can be difficult and the HSE website has further information.
- Page 13 TTB910SDR by TITAN Safety information Warning: Identify safety measures to protect the operator that are based on an estimation of exposure in the actual conditions of use (taking account of all parts of the operating cycle such as the times when the tool is switched off and when it is running idle in addition to the trigger time).
- Page 14 Safety information TTB910SDR by TITAN Symbols On the product, the rating label and within these instructions you will find among others the following symbols and abbreviations. Familiarize yourself with them to reduce hazards like personal injuries and damage to property.
-
Page 15: Your Product
TTB910SDR by TITAN Your product Your product 1. Front roller 10. Power cord with plug 2. Sanding belt 11. Lock-on button 3. Sanding arm 12. On/off switch Spring* 13. Rear hand guard Holder* 14. Motor housing Support* 15. Air vents Pin* 16. - Page 16 Proper measures include among others regular maintenance and care of the product and accessories, keeping hands warm, periodical breaks and proper planning of work processes. RATING LABEL EXPLANATION TTB910SDR = MODEL NUMBER TT - Titan B - 220-240 V~ 910 - Sequential code...
-
Page 17: Before You Start
TTB910SDR by TITAN Before you start Unpacking > Unpack all parts and lay them on a flat, stable surface > Remove all packing materials and shipping devices, if applicable. > Make sure the delivery contents are complete and free of any damage. If you find that parts are missing or show damage do not use the product but contact your dealer. - Page 18 Before you start TTB910SDR by TITAN Sanding arm assembly > Place the spring (3a) in the holder (3b) and keep it in position. > Align the pin (3d) with the spring and attach the sanding arm (3) onto the support (3c).
- Page 19 TTB910SDR by TITAN Before you start > Pay attention to the rotational direction indicated on the inside of the sanding belt (2). Align the sanding belt (2) in accordance with the direction indicated on the product housing and slide it over the front roller (1) and the drive roller (6) (Fig.
- Page 20 Before you start TTB910SDR by TITAN Sanding belt Fig. 4 Fig. 5 > Disconnect the product from the power supply before performing further assembly and adjustment. Removing/Replacing > Pull the clamp lever (4) backward all the way out and remove the sanding belt (2) (Fig.
- Page 21 TTB910SDR by TITAN Before you start Dust bag assembly Attaching/Removing > Check and re-fit the dust bag (17a) to the connector (17b) if necessary (Fig. 7). > Make sure dust (17a) properly assembled onto connector (17b)/frame (17c) (Fig. 8). Fig. 7 Fig.
- Page 22 Before you start TTB910SDR by TITAN Dust extraction Fig. 9 Fig. 10 Emptying > Open the zipper (17d) and empty chippings into a suitable rubbish bag (Fig. 11). Fig. 11 NOTE: Empty the dust bag when it is half full. An overfilled dust bag lowers the performance of the product.
- Page 23 TTB910SDR by TITAN Before you start Dust extraction Alternatively dust extraction system or suitable vacuum cleaner can be connected to the dust extraction outlet (16) for a cleaner and safer work area (Fig. 12). Fig. 12 Connection to power supply >...
-
Page 24: In More Detail
TTB910SDR by TITAN more detail... Product functions Operation Care and maintenance Trouble shooting Recycling and disposal Guarantee Declarations of conformity... - Page 25 TTB910SDR by TITAN Product functions Intended use This product is intended for sanding the following materials: wood, plastic, metal, fillers as well as varnished surfaces. This product should not be used on other materials or those harmful to health. It is to be used for dry operation only without water or other cooling liquids.
- Page 26 Product functions TTB910SDR by TITAN Sanding arm adjustment WARNING! Always switch the product off and disconnect it from power supply before making any adjustments! Always ensure the sanding arm is properly secured by the locking lever after adjustment. Never use the product if the locking lever is not...
- Page 27 TTB910SDR by TITAN Product functions / Operation Switching on/off Operate the product either in instant or continuous mode. Instant mode > Switch the product on by squeezing the on/off switch (12) (Fig. 18). > Switch the product off by releasing the on/off switch (12).
- Page 28 Operation TTB910SDR by TITAN General operation > Do not overwork yourself. Take regular breaks to ensure you can concentrate on the work and have full control over the product. > Ensure the workpiece is free of obstacles like nails or screws before operation.
- Page 29 TTB910SDR by TITAN Operation / Care and maintenance WARNING! Always use the front part (“A” range) of the sanding belt to sand the workpiece (Fig. 21). Fig. 21 > To remove paint or smooth very rough wood, sand across the grain at 45º in two directions, and then finish parallel with the grain >...
- Page 30 Care and maintenance TTB910SDR by TITAN The golden rules for care > Regular and proper cleaning will help ensure safe use and prolong the life of the product. > Inspect the product before each use for worn and damaged parts. Do not...
-
Page 31: Care And Maintenance
TTB910SDR by TITAN Care and maintenance UK plug If you need to replace the fitted plug, then follow the instructions belo . IMPORTANT: The wires in the mains lead are coloured in accordance with the following code: Blue – Neutral Brown – Live... - Page 32 Care and maintenance TTB910SDR by TITAN Repair This product does not contain any parts that can be repaired by the consumer. Contact an authorised service centre or a similarly qualified person to have it checked and repaired. Storage > Switch the product off and disconnect it from the power supply.
-
Page 33: Troubleshooting
TTB910SDR by TITAN Troubleshooting / Recycling and disposal Troubleshooting Suspected malfunctions are often due to causes that the users can fix themselves. Therefore check the product using this section. In most cases the problem can be solved quickly. WARNING! Only perform the steps described within these instructions! -
Page 34: Guarantee
We take special care to select high quality materials and use manufacturing techniques that allow us to create products incorporating design and durability. This product (TITAN TTB910SDR) has a manufacturer’s guarantee of 2 years against manufacturing defects, from the date of purchase (if bought in store) or date of delivery (if bought online), at no additional cost. - Page 35 TTB910SDR by TITAN EC declaration of conformity EC declaration of conformity (EN) EU DECLARATION OF CONFORMITY (FR) DÉCLARATION UE DE CONFORMITÉ (PL) DEKLARACJA ZGODNOŚCI UE (RO) DECLARAȚIA DE CONFORMITATE UE (ES) DECLARACIÓN UE DE CONFORMIDAD (PT) DECLARAÇÃO DE CONFORMIDADE UE Product/ Produit/ Produkt/Produsul/Producto/Produto •...
- Page 36 EC declaration of conformity TTB910SDR by TITAN 2006/42/WE w zmienionej dyrektywie maszynowej 2014/30/UE ze zmianami Dyrektywa Kompatybilność elektromagnetyczna 2011/65/UE ze zmianami Dyrektywa Ograniczenie stosowania niektórych niebezpiecznych substancji w sprzęcie elektrycznym i elektronicznym 2006/42/CE, astfel a fost modificată Directiva privind echipamentele 2014/30/UE, astfel a fost modificată...
- Page 37 TTB910SDR by TITAN EC declaration of conformity EC declaration of conformity (UK) DECLARATION OF CONFORMITY Product 400W Precision File Belt Sander • TTB910SDR • Serial number: 00001 to 999999 • Name and address of the manufacturer or his authorised representative:...
