Figure 6: Mw730B - Large Enclosure Details; Figure 7: Mw730B Configuration Examples - Bosch Solution 6000-IP CC615GWF Quick Start Manual

C
B
A
A
D
A
A
D
A
A
D
A
A
B
A = PCB Mounting Clip Holes
B = Enclosure Mounting Holes
C
= Tamper Bracket Mounting Holes
D = Earth Stud - 4mm

Figure 6: MW730B - Large Enclosure Details

The following examples show the MW710 -Large enclosure
configured using 6 small modules and 1 large module.
Bosch Security Systems 10/22 BLCC615R
320 mm
C
A A
A A
CABLE ENTRY (REAR)
A A
A A
CABLE ENTRY (REAR)
A A
A A
CABLE ENTRY (REAR)
A A
A A
When installing large modules you should fit 5
mounting clips as shown.
Clip 5 provides support under the main terminal
block only. No screw is fitted.
B
A
A
1
A
4
A
A
A
A
A
B
1
4
When installing small modules, you should
fit 4 mounting clips as shown.

Figure 7: MW730B Configuration Examples

Solution 6000-IP Quick Start Guide
MODULE
SPACE 1
5
CABLE ENTRY (REAR)
MODULE MODULE
SPACE 2 SPACE 3
CABLE ENTRY (REAR)
MODULE MODULE
SPACE 4 SPACE 5
CABLE ENTRY (REAR)
2
MODULE MODULE
SPACE 6 SPACE 7
3
2
3
7
