- Page 1 CM728B and CM729B Fingerprint Reader Modules Security Systems Installer Reference Guide Security System...
- Page 2 CM728B - Black and CM729B - White The addition of a CM728B or CM729B Fingerprint reader to your installation will allow users to turn areas on and off or open a door simply by presenting their unique fingerprint credential to the reader. The fingerprint reader fea- tures 3D pixel sensing technology and can read virtually any finger;...
-
Page 3: Module Addressing
CM728B-CM729B Installer Reference Guide Module Addressing CM728B & CM729B Mounting Template Each reader fitted to the system must be assigned a Scale 1:1 unique address on the LAN using the on board rotary address switch. The following table shows the address setting for each reader as well as the number of keypad, reader devices each panel can support. - Page 4 The LED indicators will only display the status of the programmed home area. You cannot move Note between areas from this reader. If you require mul- tiple area status visibility you should use a display keypad like the CP700. Bosch Security Systems 06/12 CM728B-CM729BIRG FTR1.0...
- Page 5 CM728B-CM729B Installer Reference Guide Alert Tones Egress and Lock Control The reader emits several distinct tones to alert you The fingerprint reader includes an egress input and a of particular system events. The volume level can be lock output which can be used to simplify the wiring adjusted or turned off via programming by setting the when the reader is being used for door or access control.
-
Page 6: Cleaning The Sensor
4) Repeat the process if necessary. Avoid using detergents and soaps containing oily substances since they can leave contaminants that negatively effect the sensor performance. Note Bosch Security Systems 06/12 CM728B-CM729BIRG FTR1.0... -
Page 7: Wiring Connection Diagram
Address 1. Figure 5: CM728B and CM729B Connection Diagram You must power cycle the panel or perform a LAN scan after connecting the CM728B or CM729B Note for the system to initialise the module. Bosch Security Systems... - Page 8 Translation - is defined as the difference in horizontal and/or vertical direction from the enrolled template to the verification occasion. The CM728B and CM729B readers allow a few millimetres in both horizontal and vertical direction (between the enrolled fingerprint and the verified fingerprint). Translation is essentially a result of the lack of guidance of the fingertip in both directions.
- Page 9 CM728B-CM729B Installer Reference Guide Finger Pitch - occurs when only the upper part of the fingertip is placed on the sensor, as if the user is pointing at something. As the upper parts of all fingerprints look very much alike with very few distinct areas, this situation should be avoided.
- Page 10 John Smith Press OK or MENU Press OK or MENU 5. A Master user can only delete a fingerprint of a user that has been assigned to the same area(s) as the Master user. Bosch Security Systems 06/12 CM728B-CM729BIRG FTR1.0...
- Page 11 74mm(W), 23mm(D), 116mm(H). CM444 = 46mm(W), 12.5mm(D), 12mm H) Environment: -30˚ to 55˚C RH 5 to 85% at 30˚C non-condensing. The CM728B and CM729B should be mounted on a sturdy vertical wall using fixtures appropriate Fixing Method: for the wall construction type.
- Page 12 Bosch Security Systems 25 Huntingwood Drive Huntingwood, NSW 2148 Australia Phone: +612 9672 1777 Facsimile: +612 9672 1717 © 2012 Bosch Security Systems CM728B-CM729BIRG Issue FTR1.0...
