PCM-3347 Series/
PCM-3348 Series
STPC Elite 133MHz Module with
SVGA/LCD/LAN Interface and
STPC Consumer II 133MHz CPU
Module with VGA/LAN/SSD/FDD
Users Manual

Advertisement

Table of Contents
loading

Related Manuals for Advantech PCM-3347 Series

Summary of Contents for Advantech PCM-3347 Series

  • Page 1 PCM-3347 Series/ PCM-3348 Series STPC Elite 133MHz Module with SVGA/LCD/LAN Interface and STPC Consumer II 133MHz CPU Module with VGA/LAN/SSD/FDD Users Manual...
  • Page 2 Copyright This document is copyright ©, 2000 and 2002, by Advantech Co., Ltd. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmit- ted in any form or by any means without the prior written permission of the original manufacturer.
  • Page 3 Packing List Before you begin installing your card, please make sure that the following materials have been shipped: • PCM-3347 All-in-one single board computer • 1 Start-up manual • CD-ROM or Disks for utility, drivers, and manual (in PDF format) •...
  • Page 4 PCM-3347 User’s Manual...

  • Page 5: Table Of Contents

    Contents Chapter 1 General Information ........2 Introduction ............... 2 Features ................3 Specifications ..............3 1.3.1 Standard SBC functions..........3 1.3.2 VGA function (PCM-3347 only)........4 1.3.3 VGA function PCM-3348..........4 1.3.4 Ethernet function............. 4 1.3.5 Solid state disk ..............4 1.3.6 Mechanical and environmental........
  • Page 6 2.17 LCD-B connector (CN11)..........17 2.18 CompactFlash™ socket (CN22) ........17 2.19 I2C BUS (CN4).............. 17 2.20 HDD LED connector (CN15) ......... 17 2.21 SIR connector (CN20)............. 18 Chapter 3 Software Configuration .........20 Introduction ..............20 Connections for four standard LCDs (PCM-3347) ..20 3.2.1 Sharp LM64183P,LM64P89 (640x480 DSTN MONO LCD) ........
  • Page 7 5.1.2 Display memory............36 Installation of SVGA driver ..........36 5.2.1 Installation for Windows 3.1 ........37 5.2.2 Installation for Windows 95 ......... 40 Chapter 6 PCI SVGA Setup ..........48 Introduction ..............48 6.1.1 Chipset ................48 6.1.2 Display memory............48 6.1.3 Display types..............
  • Page 8 C.10 Reset button connector (CN13)....91 Table C.10:Reset button connector (CN13) ....91 C.11 Main power (+5 V) connector (CN14) ..... 92 Table C.11:Main power (+5 V) connector (CN14) ..92 C.12 PS/2 keyboard/mouse connector (CN18) ... 92 Table C.12:PS/2 keyboard/mouse connector (CN18)... 92 C.13 5 V connector (CN16) ......
  • Page 9 General Information This chapter gives background infor- mation on the 3347/PCM-3348. Sections include: • Introduction • Features • Specifications • Board dimensions...

  • Page 10: Chapter 1 General Information

    Chapter 1 General Information 1.1 Introduction The PCM-3347 is the ultimate cost-effective PC/104 solution for limited- space applications. It offers all the functions of an AT-compatible indus- trial computer on a single board, and occupies less space than a 3¾" hard drive.

  • Page 11: Features

    (96 mm x 90 mm) • Onboard STPC Elite 133MHz/Cousumer II CPU • Onboard 32/64 MB system memory, default is 32MB • Onboard VGA/36-bit LCD interface PCM-3347 Series • Supports CompactFlash™ card • Built-in Enhanced IDE (AT bus) hard disk drive interface •...

  • Page 12: Vga Function (Pcm-3347 Only)

    Colors 640 x 480 800 x 600 1024 x 768 Resolution Map for PCM-3347 Series 1.3.3 VGA function PCM-3348 • Display memory: 512 KB ~ 4 MB share memory, set in BIOS • Display type: Supports CRT • CRT display mode: Non-interlaced CRT monitors resolutions up to 1280 x 1024 @ 24 bpp 1.3.4 Ethernet function...

  • Page 13: Board Dimensions

    1.4 Board Dimensions Figure 1.1: PCM-3347 Dimensions Chapter 1...
  • Page 14 PCM-3347 User’s Manual...
  • Page 15 Introduction This chapter tells how to set up the PCM-3347 hardware. It includes instructions on setting jumpers and connecting peripherals, switches and indicators. Make sure you read all the safety precautions before you begin the installation procedure.

  • Page 16: Chapter 2 Introduction

    Chapter 2 Introduction 2.1 Connectors (PCM-3348 has no LCD connectors) The board has a number of connectors that allow you to configure your system to suit your application. The tables below shows the function of each of the board's connectors:. Table 2.1: Connectors Label Function...
  • Page 17 Table 2.1: Connectors Clear CMOS Setting WatchDog trigger event Battery Socket Chapter 2...

  • Page 18: Locating Connectors

    2.2 Locating connectors Warning: Make sure you use the correct component side. Improper installation can cause serious damage to your hardware! Figure 2.1: Locating connectors (component side) PCM-3347 User’s Manual...
  • Page 19 Figure 2.2: Locating connectors (solder side) Chapter 2...

  • Page 20: Installation Procedures

    2.3 Installation Procedures Warning: Always completely disconnect the power cord from your board whenever you are working on it. Do not make connections while the power is on, because sensitive electronic components can be damaged by a sudden rush of power. Caution: Always ground yourself to remove any static charge before touching the board.

  • Page 21: Serial Ports (Cn5, Cn6, Cn8, Cn9)

    2.6 Serial ports (CN5, CN6, CN8, CN9) The PCM-3347 offers four serial ports, three RS-232. These ports allow you to connect to any serial device (a mouse, printers, etc.) or communi- cation network. 2.6.1 COM1,COM3,COM4 RS-232 port (CN6,CN9,CN8) The serial port connector's consist of a 10-pin dual-in-line pin head hous- ing.

  • Page 22: Pc/104 Connector (Cn17, Cn19)

    Connect one end of the cable to CN1. Make sure that the red (or blue) wire corresponds to pin 1 on the connector, which is labeled on the board (on the right side). Plug the other end of the cable into the Enhanced IDE hard drive, with pin 1 on the cable corresponding to pin 1 on the hard drive.

  • Page 23: Crt Display Connector (Cn10)

    2.11.1 CRT display connector (CN10) CN10 is a 16-pin, pin head housing connector. Please use the VGA cable (provided with your kit) to convert the pin head housing connector into a connector for conventional CRT displays. Detailed information on pin assignments for CRT display connector CN10 is given in Appendix C.

  • Page 24: Connector (Cn16)

    2.15 5 V connector (CN16) The PCM-3347 is equipped with a low power dissipation STPC. With only a heat sink, the PCM-3347 will operate normally at temperatures up to 60× C. At temperatures above 60× C, a fan is recommended. A CPU fan power supply connector is provided (+5 V input) in addition to the CPU power supply.

  • Page 25: Lcd-B Connector (Cn11)

    The CompactFlashô disk card is defaulted as the E disk drive in your PC system. To fit the Advantech CFC into the PCM-3347, simply plug it into the designated connector. It will only fit when the red triangle on the CFC is aligned with the triangle on the connector.

  • Page 26: Sir Connector (Cn20)

    2.21 SIR connector (CN20) PCM-3347 provides a 5-pin SIR connector. PCM-3347 User’s Manual...
  • Page 27 Software Configuration This chapter details the software con- figuration information. It shows you how to configure the card to match your application requirements. Award System BIOS is covered in Chapter 4. Sections include: • Introduction • Connections for four standard LCDs •...

  • Page 28: Chapter 3 Software Configuration

    Chapter 3 Software Configuration 3.1 Introduction The PCM-3347 system BIOS and custom drivers are located in a 256 KB, 32-pin (JEDEC spec.) Flash ROM device, designated U18. A single Flash chip holds the system BIOS and VGA BIOS. The display can be config- ured via CMOS settings.

  • Page 29: Toshiba Ltm10C042(640X480 Tft Color Lcd)

    CN1-11 CN1-12 CN1-13 CN1-14 CN1-15 * LM64183P -17 V LM64P89 -20 V Note: Standard BIOS supports TFT and DSTN LCD panels. 3.2.2 Toshiba LTM10C042(640x480 TFT color LCD) Table 3.2: Connections to Toshiba LTM10DC042 LTM10C042 PCM-3347 CN7 Name Name SHFCLK Chapter 3...

  • Page 30: Sharp Lm64C142(640X 480 Dstn Color Lcd)

    ENAB +5 V 31, 32 +5 V 3.2.3 Sharp LM64C142(640x 480 DSTN color LCD) Connections to Sharp LM64C142 LM64C142 PCM-3347 CN7 Name Name CN1-1 CN1-2 CN1-3 SHFCLK CN1-4 DISP +5 V CN1-5 +5 V CN1-6 CN1-7 ó +27* CN1-8 CN1-9 CN1-10 CN1-11 CN1-12...

  • Page 31: Connections To Toshiba Ltm12C275A (800 X 600 Tft Color Lcd)

    CN2-2 CN2-3 CN2-4 CN2-5 CN2-6 CN2-7 CN2-8 CN2-9 CN2-10 3.2.4 Connections to Toshiba LTM12C275A (800 x 600 TFT color LCD) Connections to Toshiba LTM12C2775A LTM12C275A PCM-3347 CN7 Name Name NCLK SHFCLK Chapter 3...

  • Page 32: Ethernet Software Configuration

    ENAB M/DE +5 V +5 V 3.3 Ethernet software configuration The PCM-3347 ís onboard Ethernet interface supports all major network operating systems. To configure the medium type, to view the current configuration, or to run diagnostics, do the following: Power the PCM-3347 on. Make sure that the RSET8139.EXE file is located in the working drive.
  • Page 33 Each option has its own display screen that shows the format and result of any diagnostic tests undertaken. Note 1: For Ethernet installation, please see Chapter 7. Note 2: There is no Ethernet function on PCM-3347L Chapter 3...
  • Page 34 PCM-3347 User’s Manual...
  • Page 35 Award BIOS Setup This chapter describes how to set BIOS configuration data.

  • Page 36: Chapter 4 Award Bios Setup

    Chapter 4 Award BIOS Setup 4.1 System test and initialization These routines test and initialize board hardware. If the routines encoun- ter an error during the tests, you will either hear a few short beeps or see an error message on the screen. There are two kinds of errors: fatal and non-fatal.

  • Page 37: Award Bios Setup

    CMOS Data Backup Because CMOS memory retention and integrity is especially critical for normal startup, original CMOS memory values stored in the BIOS Flash memory allow system boots to proceed normally. This is especially criti- cal in unmanned applications where system monitoring is not convenient. This data redundancy (backup) combined with error detecting capability make for more stable and reliable systems.

  • Page 38: Standard Cmos Setup

    4.2.2 Standard CMOS setup When you choose the Standard CMOS Setup option from the Award BIOS Setup Utility menu, the screen shown below is displayed. This standard setup menu allows users to configure system components such as date, time, hard disk drive, floppy drive and display. Once a field is highlighted, on-line help information is displayed at the bottom left of the menu screen.

  • Page 39: Advanced Cmos Setup

    4.2.3 Advanced CMOS setup By choosing the Advanced CMOS Setup option from the Award BIOS Setup Utility menu, the screen below is displayed. Figure 4.2: Standard CMOS setup screen 4.2.4 Advanced chipset setup By choosing the Advanced Chipset Setup option from the Award BIOS Setup Utility menu, the screen below is displayed.

  • Page 40: Power Management Setup

    4.2.5 Power management setup By choosing the Power Management Setup option from the Award BIOS Setup Utility menu, the screen below is displayed. Figure 4.4: Power management setup 4.2.6 PCI / Plug and Play configuration By choosing the PCI / Plug and Play Setup option from the Award BIOS Setup Utility menu, the screen below is displayed.

  • Page 41: Peripheral Setup

    4.2.7 Peripheral setup By choosing the Peripheral Setup option from the Award BIOS Setup Utility menu, the screen below is displayed. This sample screen contains the manufacturerís default values for the PCM-3347. Figure 4.6: Peripheral setup 4.2.8 Load BIOS defaults Auto Configuration loads the default system values directly from ROM.

  • Page 42: Save Settings And Exit

    Confirm Password: Enter the current password and press <Enter>. After pressing <Enter> (ROM password) or the current password (user-defined), you can change the password stored in the CMOS. The password can be at most eight (8) characters long. Remember: To enable this feature, you must first select either Setup or System in Change User Password.
  • Page 43 SVGA Setup • Introduction • Installation of SVGA driver • - for Windows 3.1 • - for Windows 95 Further information...

  • Page 44: Chapter 5 Svga Setup

    Chapter 5 SVGA Setup 5.1 Introduction The PCM-3348 has an on-board VGA interface. The specifications and features are described as follows: 5.1.1 Chipset The PCM-3348 uses a SGS Thomson STPC for its SVGA controller, which supports conventional analog CRT monitors. In addition, it also supports interlaced and non-interlaced analog monitors (color and mono- chrome VGA) in high-resolution modes while maintaining complete IBM VGA compatibility.

  • Page 45: Installation For Windows 3.1

    5.2.1 Installation for Windows 3.1 a. Insert the CD/disk into the CD-ROM/FDD drive. b. Select "Main" in Program Manager. c. Double click the "Windows Setup" icon. d. Select "Change System Setting" in Options. e. Select "Other display (Requires disk from OEM)" in display. a.
  • Page 46 a. During the installation, you can shoose the resolution and colors you want to use. b. Press "OK". a. a. Type in the path of the Win31 source code. b. Press "OK". D:\PC104\3347\Video\Umavga\Win31 a. Type in the path of Win31 VGA driver. b.
  • Page 47 a. Type in the path of the Win31 source. b. Press "OK" to finish. D:\Vga\Umavga\Win31\ a. A. When Windows asks you to restart select "Continue". a. Before you restart Windows, insert the following system.ini file into the Windows directory: [display] Redundancy = off b.

  • Page 48: Installation For Windows 95

    5.2.2 Installation for Windows 95 a. Select "Start", "Settings", "Control Panel", "Display", "Settings". b. Press "Advanced Properties".. a. Choose the "Adapter" label. b. Press the "Change..." button. b. Click “Next” a. Press the "Have Disk" button. PCM-3347 User’s Manual...
  • Page 49 a. Insert the utility disc into the CD-ROM drive. b. Type: D:\VGA\Umavga\Win95 c. Press "OK". D:\VGA\Umavga\Win95 a. Select the highlighted item. b. Click the "OK" button.. a. SGS-Thompson STPC appears in the adapter label. b. Click the "Apply" button. Chapter 5...
  • Page 50 a. Press "Yes" to reboot. a. Repeat Step 1 on the previous page of this manual. The "UMA config" label appears in "Display". b. Adjust resolution and color. PCM-3347 User’s Manual...
  • Page 51 a. Click the "UMA Config" label. b. Adjust the refresh rate and display type. c. Press "OK" to exit. a. Press "Yes" to se the monitor type. Chapter 5...
  • Page 52 a. Select "Standard", "Super VGA 800 x 600", or "XGA". b. Press the "OK" button. a. Choose "Restart" to reboot. PCM-3347 User’s Manual...
  • Page 53 You may find a "PCI Early non-VGA device" message in System Properties. This message merely indicates a normal situation, and your system's functionality remains unimpaired. Advantech will further resolve the display of this message in the near future. Chapter 5...
  • Page 54 PCM-3347 User’s Manual...
  • Page 55 PCI SVGA Setup (For PCM-3347 only) This chapter provides information on the PCI SVGA setup. Sections include: • Introduction • Installation of SVGA Drivers - for Windows 98/2000/ME - for Windows NT - for Windows XP Further Information...

  • Page 56: Chapter 6 Pci Svga Setup

    Chapter 6 PCI SVGA Setup 6.1 Introduction The PCM-3347 has an onboard AGP flat panel/VGA interface. The spec- ifications and features are described as follows: 6.1.1 Chipset The PCM-3347 uses a C&T 69000 chipset for its PCI/SVGA controller. It supports many popular LCD, EL, and gas plasma flat panel displays and conventional analog CRT monitors.

  • Page 57: Installation Of The Svga Driver

    6.2 Installation of the SVGA Driver Complete the following steps to install the SVGA driver. Follow the pro- cedures in the flow chart that apply to the operating system that you are using within your PCM-3347. Notes: 1. The windows illustrations in this chapter are intended as examples only.
  • Page 58 a. Choose the language you want to use during installation. a. Select the highlighted item. b. Press "ENTER" PCM-3347 User’s Manual...
  • Page 59 a. Press "ENTER" to install all resolutions. a. Type the path of the operation system. a. When installation is completed, reboot the system. Chapter 6...
  • Page 60 b. You will see the "ChipsCPL" icon in the control panel. a. Double click "ChipsCPL" b. Adjust screen size, color and refresh rate to your preferences. PCM-3347 User’s Manual...

  • Page 61: Installation For Windows 95

    6.2.2 Installation for Windows 95 a. Select "Start", "Settings", "Control Panel" b. Press "Advanced Properties". a. Choose the "Adapter" label. b. Press the "Change..." button. Chapter 6...
  • Page 62 a. Press the "Have Disk" button. a. Insert the utility disc into the CD-ROM drive. b. Type D:\VGA\69000\Win95 c. Press "OK" D:\VGA\69000\Win95 a. Select the highlighted item. b. Click the "OK" button. PCM-3347 User’s Manual...
  • Page 63 a. C&T69000 appears in the adapter label. b. Click the "Apply" button. a. Press the "Yes" to reboot. a. Repeat Step 1 on the previous page of this manual. The "Chips" label appears in "Display". Chapter 6...
  • Page 64 b. Adjust resolution and color. a. Click the "Chips" label. b. Adjust the refresh rate and display type. c. Press "OK" to exit. PCM-3347 User’s Manual...
  • Page 65 a. Press "Yes" to set the monitor type. a. Select "Standard" "Super VGA 800 x 600" or "XGA". b. Press the "OK" button. a. Choose "Restart" to reboot. Chapter 6...

  • Page 66: Installation For Windows Nt

    6.2.3 Installation for Windows NT a. Select "Start", "Settings", "Control Panel" b. Double click the "Display" icon. a. Choose the "Settings" label. b. Press the "Display Type" button. PCM-3347 User’s Manual...
  • Page 67 a. Press the "Change..." button. a. Click the "Have Disk..." button. Chapter 6...
  • Page 68 a. Insert the utility disc into the CD-ROM drive. b. Type D:\VGA\69000\NT31 c. Press the "OK" button D:\VGA\69000\NT31 a. Select the highlighted item. b. Press the "OK" button. PCM-3347 User’s Manual...
  • Page 69 a. Press "Yes" to proceed. a. Press "OK" to reboot. a. Repeat Step 1 in this manual, to select the "Settings" label. b. Adjust resolution and color. c. Click "Test" to see the result. Chapter 6...

  • Page 70: Further Information

    Click "OK" to save the setting. 6.3 Further information For further information about the PCI/SVGA installation in your PCA- 3347, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: C&T website: www.chips.com Advantech websites: www.advantech.com www.advantech.com/support PCM-3347 User’s Manual...
  • Page 71 PCI Bus Ethernet Inter- face (PCM-3347F/3348F only) This chapter provides information on Ethernet configuration. Sections include: • Introduction • Installation of Ethernet driver - for MS-DOS and Windows 3.1 - for Windows 95/98 • Further information...

  • Page 72: Chapter 7 Pci Bus Ethernet Interface

    Chapter 7 PCI Bus Ethernet Interface 7.1 Introduction The PCM-3347F/PCM-3348F is equipped with a high performance 32- bit Ethernet chipset which is fully compliant with IEEE 802.3 100 Mbps CSMA/CD standards. It is supported by major network operating sys- tems. It is also both 100Base-T and 10Base-T compatible. The medium type can be configured via the RSET8139.exe program included on the utility disk.

  • Page 73: Installation For Windows 95/98

    7.2.2 Installation for Windows 95/98 a. Select "Start", "Settings", "Control Panel" b. Double click "Network" a. Click "Add" and prepare to install network functions. Chapter 7...
  • Page 74 a. Select the "Adapter" item to add the Ethernet card. a. Click "Have Disk" to install the driver. a. Insert the CD into the D:\drive. b. Type: D:\LAN\8100BL\98-me-2k-xp PCM-3347 User’s Manual...
  • Page 75 c. Click "OK". D:\LAN\8100BL\98-me-2k-xp a. Choose the "Realtek" item. b. Click "OK". Chapter 7...
  • Page 76 a. Make sure the configurations of relevant items are set correctly. b. Click "OK" to reboot. Note: The correct path for Windows 98 is: D:\LAN\8100BL\98-me-2k-xp PCM-3347 User’s Manual...

  • Page 77: Installation For Windows Nt

    7.2.3 Installation for Windows NT a. Select "Start", "Settings", "Control Panel" b. Double click "Network" a. Choose the "Adapters" label. b. Click the "Add" button. Chapter 7...
  • Page 78 a. Press "Have Disk". a. Insert the CD into the D:\drive. b. Type: D:\LAN\8100BL\nt40 c. Click "OK". D:\LAN\8100BL\nt40 a. Choose the "Realtek" item. PCM-3347 User’s Manual...
  • Page 79 b. Click "OK" a. Make sure the configurations of relevant items are set correctly. b. Click "OK" to reboot. Chapter 7...

  • Page 80: Further Information

    7.3 Further information Realtek website: www.realtek.com Advantech websites:www.advantech.com www.advantech.com/support PCM-3347 User’s Manual...
  • Page 81 Programming the Watchdog Timer The PCM-3347 is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned environments.

  • Page 82: Appendix A Programming The Watchdog Timer

    Appendix A Programming the Watchdog Timer A.1 Programming the watchdog timer The default configuration of the timer is enabled with system reset. To enable the watchdog timer, you must make a program which writes 1 to I/O port address 443 (hex) at regular intervals. The first time your pro- gram reads the port, it enables the watchdog timer.
  • Page 83 1070 RETURN 2000 REM Subroutine #2, takes 1 second to complete 2090 RETURN Appendix A...
  • Page 84 PCM-3347 User’s Manual...
  • Page 85 Installing PC/104 Modules This appendix gives instructions for installing PC/104 modules.

  • Page 86: Appendix B Installing Pc/104 Modules

    Appendix B Installing PC/104 Modules B.1 Installing PC/104 modules The PCM-3347's PC/104 connectors give you the flexibility to attach PC/ 104 modules. Installing these modules on the PCM-3347 is quick and simple. The fol- lowing steps show how to mount the PC/104 modules: Remove the PCM-3347 from your system paying particular atten- tion to the safety instructions already mentioned above.
  • Page 87 PC/104 Mounting Support Male Female PC/104 module PCM-3346 82.5 95.9 φ 90.8 90.8 φ 85.1 90.2 Appendix B...
  • Page 88 Table B.1: PCM-3347/PCM-3348 PC/104 (CN12) Signal (CN17) Signal (CN19) Number Row A Row B Row C Row D IOCHCHK* SBHE* MEMCS16* RESETDRV LA23 IOCS16* +5 V LA22 IRQ10 IRQ9 LA21 IRQ11 -5 V LA20 IRQ12 DRQ2 LA19 IRQ15 -12 V LA18 IRQ14 ENDXFR*...
  • Page 89 Table B.1: PCM-3347/PCM-3348 PC/104 (CN12) IRQ5 IRQ4 IRQ3 DACK2* BALE +5 V * low active Appendix B...
  • Page 90 PCM-3347 User’s Manual...
  • Page 91 Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • Ethernet connector • LCD-A connector • COM1 connector • COM2 connector • EIDE HDD connector • PC/104 connector • Parallel port connector • Backlight connector •...

  • Page 92: Appendix C Pin Assignments

    Appendix C Pin Assignments C.1 Ethernet connector (CN2) Table C.1: Ethernet connector (CN2) Signal Signal Vcc (+5 V) ACTLED- LILED- PCM-3347 User’s Manual...

  • Page 93: Lcd-A Connector (Cn7)

    C.2 LCD-A connector (CN7) Table C.2: LCD-A connector (CN7) Signal Signal VDDSAFE +5 V VDDSAFE +5 V VDDSAFE +3.3 V VDDSAFE +3.3 V SHIFT CLOCK FLM (FIRST LINE MARKER) M (DISPLAY ENABLE) LP (LATCH PULSE) ENABKL ENAVEE Note: The model number of the CN7 socket is DF13A- 40DP-1.25V (Hirose Electric Co., Ltd.) Appendix C...

  • Page 94: Com1, Com3, Com4 Connector (Cn6, Cn 9, Cn8)

    C.3 COM1, COM3, COM4 connector (CN6, CN 9, CN8) Table C.3: COM1,COM3,COM4 (CN6,CN 9,CN8) Signal Signal RLSD PCM-3347 User’s Manual...

  • Page 95: Com2 Connector (Cn5, Cn23)

    C.4 COM2 connector (CN5, CN23) Table C.4: COM2 RS-232 connector (CN5) Signal Signal RLSD Table C.5: COM2 RS422/485 connector (CN27) Pin 1 TX- (RS422) Pin 3 RX+ (RS422) Pin 4 RX+ (RS422) Pin 2 TX+(RS422) Pin 1 DATA- (RS485) Pin 3 NC (RS485) Pin 2 DATA+ (RS485)

  • Page 96: Eide Hard Drive Connector (Cn1)

    C.5 EIDE hard drive connector (CN1) Table C.6: EIDE hard drive connector (CN1) Signal Signal RESET- IOW- IOR- IOCHRDY DACK- SA 0 HDCS1- HDCS3- HDLED * low active PCM-3347 User’s Manual...

  • Page 97: Pc/104 Connector (Cn17, Cn19)

    C.6 PC/104 connector (CN17, CN19) For details on PC/104 connectors, please refer to Appendix B. C.7 Parallel port connector (CN12) Table C.7: Parallel port connector (CN12) Signal Signal *STROBE ERROR INIT SLIN ACKNOWLEDGE BUSY PE (PAPER EMPTY) SLCT * low active Appendix C...

  • Page 98: Backlight Connector (Cn3)

    C.8 Backlight connector (CN3) Table C.8: Backlight connector (CN3) Signal +12 V BACKLIGHT ENABLE C.9 VGA connector (CN10) Table C.9: VGA connector (CN10) Signal Signal RED_OUT VCC_VGA GREEN_OUT PCM-3347 User’s Manual...

  • Page 99: Reset Button Connector (Cn13)

    Table C.9: VGA connector (CN10) Signal Signal BLUE-OUT D2C_DATA D2C_CLOCK C.10 Reset button connector (CN13) Table C.10: Reset button connector (CN13) Signal *MASTER RESET * low active Appendix C...

  • Page 100: Main Power (+5 V) Connector (Cn14)

    C.11 Main power (+5 V) connector (CN14) Table C.11: Main power (+5 V) connector (CN14) Signal +12V Vcc (+5 V) C.12 PS/2 keyboard/mouse connector (CN18) Table C.12: PS/2 keyboard/mouse connector (CN18) Signal PS/2 KB CLOCK PS/2 KB DATA PS/2 MOUSE CLOCK PS/2 MOUSE DATA PCM-3347 User’s Manual...

  • Page 101: Connector (Cn16)

    C.13 5 V connector (CN16) Table C.13: 5 V connector (CN16) Signal Vcc (+5 V) Appendix C...

  • Page 102: Fdd Connector (Cn22)

    C.14 FDD connector (CN22) Table C.14: FDD connector (CN22) Signal Vcc (5 V) INDEX Vcc (5 V) DRIVE SELECT 0 Vcc (5 V) DISK CHANGE NC (READY) NC (HD OUT) MOTOR ON DIRECTION SELECT NC (1.6 MB IN) STEP WRITE DATA WRITE GATE TRACK 00 WRITE PROTECT...

  • Page 103: Lcd-B Connector (Cn11)

    C.15 LCD-B connector (CN11) Table C.15: LCD-B connector (CN11) Signal Signal Note: The model number of the CN11 socket is DF13A- 20DP-1.25V (Hirose Electric Co., Ltd.) Appendix C...

  • Page 104: Compactflash™ Socket (Cn21)

    C.16 CompactFlash™ socket (CN21) Table C.16: CompactFlash™ socket (CN21) Signal Signal *CS1 *ATA SEL +5 V *IOCS16 *CD2 *CD1 *VS1 *IORD *IOWR INTRQ +5 V *CSEL *VS2 *RESER IORDY DREQ *REG *DASP *PDIAG * low active PCM-3347 User’s Manual...
  • Page 105 Figure C.1: CompactFlash™ socket Table C.17: I2C BUS connector (CN4) Pin 1 I2C DATA Pin 2 I2C CLK HDD LED connector (CN15) Pin 1 Pin 2 HDD LED SIR connector (CN20) Pin 1 Pin 2 Pin 3 IRRX Pin 4 Pin 5 IRTX COM2 RS232/422/485 Jumper...
  • Page 106 Table C.17: I2C BUS connector (CN4) Pin 1 I2C DATA Pin 1-2 RS232 Pin 3-4 RS422 Pin 5-6 RS485 Clear CMOS (J2) Pin 1-2 Clear CMOS Pin 2-3 RTC Power Setting WatchDog trigger event (J3) Pin 1-2 IRQ11 Pin 2-3 Reset PCM-3347 User’s Manual...
  • Page 107 System Assignments This appendix contains information of a detailed or specialized nature. It includes: • System I/O ports • DMA Channel Assignments • Interrupt Assignments • 1st MB memory map...

  • Page 108: Appendix D System Assignments

    Appendix D System Assignments D.1 System I/O ports Table D.1: System I/O ports Addr. range (Hex) Device 000-01F DMA controller 020-021 Interrupt controller 1, master 022-023 Chipset address 040-05F 8254 timer 060-06F 8042 (keyboard controller) 070-07F Real-time clock, non-maskable interrupt (NMI) mask 080-09F DMA page register...

  • Page 109: Dma Channel Assignments

    * PNP audio I/O map range from 220 ~ 250H (16 bytes) MPU-401 select from 300 ~ 330H (2 bytes) D.2 DMA channel assignments Table D.2: DMA channel assignments Channel Function Available Available Floppy disk (8-bit transfer) Available Cascade for DMA controller 1 Available Available Available...

  • Page 110: Interrupt Assignments

    D.3 Interrupt assignments Table D.3: Table D-3: Interrupt assignments Interrupt# Interrupt source IRQ 0 Interval timer IRQ 1 Keyboard IRQ 2 Interrupt from controller 2 (cascade) IRQ 8 Real-time clock IRQ 9 Cascaded to INT 0A (IRQ 2) IRQ 10 Available IRQ 11 Available...

  • Page 111: 1St Mb Memory Map

    D.4 1st MB memory map Table D.4: 1st MB memory map Addr. range (Hex) Device F000h - FFFFh System ROM D000 - EFFFh Expansion ROM CC00 - CFFFh Ethernet boot ROM C000 - CBFFh 32/40/44 K VGA BIOS B800h - BFFFh CGA/EGA/VGA text B000h - B7FFh Unused...
  • Page 112 PCM-3347 User’s Manual...
  • Page 113 LCD Services This appendix contains information on Advantech's LCD lighting ser- vices.

  • Page 114: Appendix E Lcd Services

    LCD package. Advantech reserves the right to refuse service if the customer cannot provide the required documents and auxiliary parts Advantech will supply a BIOS file and connection cable to the cus- tomer upon completing the service A minimum of seven working days is required for completion of...
