Advantech PCM-3380 Startup Manual

PCM-3380 Intel
104 CPU module Startup Manual

Packing List

Before you begin installing your card, please make
sure that the following materials have been shipped:
• 1 PCM-3380 SBC
• 1 Start-up manual
• 1 Utility CD
• 1 BATTERY 3V/210 mAf cable
CR2032WK with Wire ASS'Y
• 1 Y -cable external cable
• 1 IDE cable
• 1 Wire ATX power
• 1 Ethernet RJ-45 Conn.conversion
cable
• 1 KB/MOUSE Y-cable
• 1 COM port cable
• 1 USB Cable Adaptor
• 1 VGA cable
• 1 Audio cable
• 1 LPT cable
If any of these items are missing or damaged, contact
your distributor or sales representative immediately.
Note 1: For detailed contents of the PCM-3380,
please refer to the enclosed CD-ROM (in PDF
format).
Note 2: Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at:
www.adobe.com/Prodindex/acrobat/read-
step.html (Acrobat is a trademark of Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://service.advantech.com.tw/eservice/
This manual is for the PCM-3380
Part No. 2006338001
Printed in Taiwan
® ®
Pentium M/Celeron
p/n: 1750129010
p/n: 1703060053
p/n: 1701440350
p/n: 1703200380
p/n: 1701100202
p/n: 1700060202
p/n: 1701200220
p/n: 1700000897
p/n: 1700000898
p/n:1700000918
p/n:1700000916
2nd. Edition
February 2005
®
M PCI-

Specifications

Standard Motherboard Functions

• CPU:
Embedded Intel Pentium-M Processor 1.1GHz, Cele-
ron-M 600 MHz, Pentium-M 1.6GHz (option)
• Second level cache: 1MB on Pentium-M processor,
512KB on Celeron-M 600MHz
• BIOS: AWARD 512 KB Flash memory
• System Chipset: Intel 855GME ICH4 Chipset 400MHz FSB
• Enhanced IDE interface: Supports up to two EIDE devices.
BIOS auto-detect, PIO Mode 3 or Mode 4 transfer, Ultra
DMA33 mode supported
• Serial ports: 2 serial ports with power (option by cable)
COM1,2: RS-232
• Parallel port: One parallel port, supports SPP/EPP/ECP
mode
• DRAM: 200 pin SO-DIMM sockets, support 128 MB to 1GB,
accept 128/256/512/1000MB, DDR200/266/333 DRAM
• Keyboard/mouse connector: 6-pin wafer box connector for
keyboard and PS/2 mouse
• SSD: Supports CompactFlash Card Type I / Type II (option for
Micro Drive)
• Power management: Supports Advanced Power Manage-
ment /ACPI, Intel Speedstep
• Watchdog timer: 255-level-interval Watchdog timer, setup by
software, selection, generates system reset
• Audio: AC' 97 2.0 compliant. Supports Mic in, line in,
line out
• USB: 6 x USB 2.0, UHCI specification compliant
• FAN connector: Support for + 5 V FAN
• PCI-104 expansion: 120-pin PCI PC/104-Plus module
connector

VGA/LCD Interface

• Chipset: Intel 855GME
• Supports CRT Display, 2CH 18-bit LVDS LCD display
• Supports Dual Display Combination: CRT+ 36bit/48bit LVDS,
18bit LVDS+ 18bit LVDS
• Optimized Shared Memory Architecture, support 64MB frame
buffer using system memory

Ethernet Interface

• Chipset: Intel 82562EMT
• Ethernet interface: RJ-45 cable, PCI Ethernet controller,
IEEE 802.3u protocol compatiblePCI 10/100 Mbps Ethernet.

Solid State Disk

•
Supports CompactFlash Card Type I / Type II (option for
Micro Drive)
