PELLET STOVES USER MANUAL
UK
INSERTO COMFORT P70 AIR - P70 AIR PLUS
MADE
IN
ITALY
design & production
004280424 - Rev 000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INSERTO COMFORT P70 AIR and is the answer not in the manual?

Questions and answers

Related Manuals for Extraflame INSERTO COMFORT P70 AIR

Summary of Contents for Extraflame INSERTO COMFORT P70 AIR

  • Page 1 PELLET STOVES USER MANUAL INSERTO COMFORT P70 AIR - P70 AIR PLUS MADE ITALY design & production 004280424 - Rev 000...
  • Page 2 APPLY TECHNICAL DATA LABEL ENGLISH...

  • Page 3: Table Of Contents

    INSTALLATION .............................................. 7 PREPARATIONS FOR MAINTENANCE ..............................................7 DETAILS OF INSERTO COMFORT P70 AIR ....................................9 COMFORT P70 AIR PLUS INSERT DETAILS ....................................10 INSTALLATION INSERTO COMFORT P70 AIR P70 AIR PLUS ..............................11 GENERAL ........................................................11 MINIMUM CLEARANCE ....................................................11 INSTALLATION ......................................................12 FRESH AIR DUCTS ............................................

  • Page 4: English

    We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a ame gives, in complete safety. WARNINGS This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner...
  • Page 5 RECEIVED INSTRUCTIONS ON SAFE USE OF THE APPLIANCE AND THAT THEY UNDERSTAND THE INHERENT DANGERS. Š THE GENERATOR MUST NOT BE USED BY PERSONS INCLUDING CHILDREN WITH REDUCED PHYSICAL, SENSORY AND MENTAL CAPACITIES OR WHO ARE UNSKILLED PERSONS, UNLESS THEY ARE SUPERVISED AND TRAINED REGARDING USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR SAFETY.

  • Page 6: Routine Maintenance

    STRONG WIND, FREEZING SAFETY SYSTEMS MAY INTERVENE THAT SWITCH THE GENERATOR OFF. IF THIS OCCURS, CONTACT THE TECHNICAL AFTER SALES SERVICE AND ALWAYS DISABLE THE SAFETY SYSTEMS. Š IN THE EVENT THE FLUE CATCHES FIRE, USE SUITABLE SYSTEMS FOR SUFFOCATING THE FLAMES OR REQUEST HELP FROM THE FIRE BRIGADE.

  • Page 7: Installation

    INSTALLATION GENERAL The ue gas exhaust and hydraulic connections must be carried out by quali ed personnel who must issue installation conformity documentation compliant with national standards. The installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity, supplied with: 1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);...
  • Page 8 In the presence of type B gas appliances with intermittent operation not intended for heating, they must have their own aeration and/or ventilation opening. The air inlets must meet the following requirements: Š they must be protected with grids, metal mesh, etc., but without reducing the net useful section; Š...

  • Page 9: Details Of Inserto Comfort P70 Air

    DETAILS OF INSERTO COMFORT P70 AIR Ambient air outlet Pellet hopper TA inlet Access to combustion chamber Fuse 230V power supply and ash drawer Emergency module Rail Combustion air inlet Fumes outlet Bulb thermostat rearm ENGLISH...

  • Page 10: Comfort P70 Air Plus Insert Details

    COMFORT P70 AIR PLUS INSERT DETAILS Room air outlet Pellet hopper 230V power supply Access to combustion chamber Air ducting Z1 outlet Combustion air inlet and ash drawer Fuse Emergency module Ducting thermostat inlet Z1 Bulb thermostat reactivation Flue gas outlet Rail TA inlet ENGLISH...

  • Page 11: Installation Inserto Comfort P70 Air P70 Air Plus

    INSTALLATION INSERTO COMFORT P70 AIR P70 AIR PLUS ASSEMBLY MUST BE CARRIED OUT BY QUALIFIED PERSONNEL! GENERAL The insert is supplied with a sliding base in iron that allows it to be installed in a pre-existing chimney. This sliding base allows the insert to be removed easily to load the pellets inside the hopper and for any maintenance or cleaning at the end of the season.

  • Page 12: Installation

    INSTALLATION Open the door and release the latch using the poker supplied. Remove the 6 screws and remove the ue pipe from the base. Fix the base to the existing ue pipe. ATTENTION! RESPECT THE 50MM HEIGHT FOR OPENING AND CLOSING THE INSERT CORRECTLY! ENGLISH...
  • Page 13 Fix the base to the kit if it is a new installation (optional kit). Block the rails with two screwdrivers and secure the ue pipe to the base with 6 screws. Close the insert and block the latch. ENGLISH...

  • Page 14: Fresh Air Ducts

    FRESH AIR DUCTS For correct operation, air must be allowed to recirculate inside the structure that covers the insert in order to prevent the appliance from overheating. To guarantee this, just realise one or more openings in the lower and upper part of the covering. The following measurements must be respected: Š...

  • Page 15: New Installation

    NEW INSTALLATION EXAMPLE 1 EXAMPLE 2 A: Air convection outlet. Minimum section 120cm C: Air convection outlet. Minimum section 240cm B: air inlet from room. Minimum section 120cm D: air inlet from room. Minimum section 240cm For the insert to operate correctly, a minimum side of 20 mm and rear space of 10 mm must be guaranteed; the coatings must be made of non- ammable material.

  • Page 16: Safety Latch

    SAFETY LATCH Use the poker supplied to perform the release/block operation. (Turn clockwise to release and anti-clockwise to block). Holes present on two sides for the extraction of the insert via pokers. Extraction of the insert allows both the pellets to be loaded inside the hopper and routine maintenance (cleaning the ash pipe at year end) or unscheduled maintenance (replacement of mechanical parts if the product should break) to be performed.

  • Page 17: Extraction Of Insert And Pellet Loading

    EXTRACTION OF INSERT AND PELLET LOADING Extraction of the insert allows both the pellets to be loaded inside the hopper and routine maintenance (cleaning the ash pipe at year end) or unscheduled maintenance (replacement of mechanical parts if the product should break) to be performed. To extract the insert, follow the procedure below: Open the re door and turn the latch clockwise (using the poker supplied).

  • Page 18: Optional Loading Accessories

    OPTIONAL LOADING ACCESSORIES FRONT PELLET LOADING KIT UPPER/SIDE PELLET LOADING KIT The optional pellet loading kit allows to load the pellets into the The optional pellet loading kit allows to load the pellets into the hopper from the front without having to remove the insert (which hopper without removing the insert from the installation opening would require the machine to be switched o ).

  • Page 19: Comfort P70 Air Plus Hot Air Ducting

    COMFORT P70 AIR PLUS HOT AIR DUCTING The model is equipped with a ducting outlet. The pipe used for ducting the hot air must have an internal diameter of 80 mm and it must also be insulated or at least be protected against heat dispersion. AIR DUCTING FEATURES Š...

  • Page 20: Operation In Air Ducting With Thermostat Or Probe Optional

    OPERATION IN AIR DUCTING WITH THERMOSTAT OR PROBE OPTIONAL The stove is tted with an independent motor for ducting. The connection of an external thermostat or temperature probe (NTC 10K) in the input, located in the rear part of the stove, makes it possible to control the air ducting motor independently of the stove. Su ce it to connect the thermostat/temperature probe and set the desired temperature.

  • Page 21: Emergency Module

    EMERGENCY MODULE The stove is tted with an emergency module located at the side, allowing the basic operation of the stove in the event the handheld remote is damaged or malfunctions. The functions that can be managed from the emergency module are: Key P1 Stove ignition/switch-o L1: Blue LED o :...

  • Page 22: Radio Control

    RADIO CONTROL CONFIGURATION RADIO CONTROL CODING PROCEDURE: 1. Disconnect the power supply to the stove. 2. Press the keys at the same time until the screen to choose RADIO ID appears. select the new RADIO ID. 3. Using keys 4. Power the stove. Con rm the selected unit within 10 seconds (the LED will ash on the radio/emergency card) by pressing the OK key on the remote control.

  • Page 23: Radio Control Features

    RADIO CONTROL FEATURES The radio control is tted with an LCD backlit display. The display remains lit for 5 seconds. After a certain period of time, in order to minimise battery consumption, the display turns o (sleep mode). It turns on again after pressing the ON/OFF key (6). CAUTION! Do not place the radio control device in direct or indirect contact with water.

  • Page 24: Display

    DISPLAY SCREEN IN OPERATION STAND BY active Chrono active Battery low Power 1-5^ Hour Air ducting active Tangential fan active Temperature detected in room Set ambient temperature Display text Tangential fan active in COMFORT mode SCREEN WITH EXTERNAL THERMOSTAT CONNECTED TO THE TERMINAL “TA” Time Indicates contact of the external additional...

  • Page 25: General Menu

    GENERAL MENU FUNCTION FUNCTION Scroll through parameters Back - exit key Modify settings Ignition - switch-o key Access menu key MODE FRONT AIR *AIR DUCTING **TEMPERATURE ***AIR ZONE CONTROL EASY SETUP CHRONO ENABLING PRG1 PRG2 SETTINGS DATE/TIME PRG3 LANGUAGE PRG4 DISPLAY STAND BY FIRST LOAD...

  • Page 26: First Ignition Settings

    FIRST IGNITION SETTINGS After connecting the power cord at the back of the generator, turn the switch (if any) to position (I). The switch is used to power the heat generator board. If the switch is in the OFF position, the generator will remain o and the word OFF will appear on the panel. DATE/TIME This menu allows the date and time to be set.

  • Page 27: Operation And Logic

    OPERATION AND LOGIC IGNITION Once the previously listed points have been checked, press key for three seconds to ignite the stove. During ignition, the stove will check for a ame for a period of 15 minutes. Once the control temperature has been reached, the stove interrupts the ignition phase and switches to PREPARATION.

  • Page 28: Modes

    MODES This menu allows you to set the machine operation logic. Range: (AUTOMATIC, SELF CONTROL) If AUTOMATIC mode is selected, the stove power will be automatically adjusted to reach the set temperature without exceeding it. This function improves the experience of using the generator in terms of consumption, thermal and acoustic comfort and the reduction in the need for cleaning and maintenance.

  • Page 29: Chrono

    CHRONO This function allows stove ignition and switch-o to be automatically programmed. The factory setting for CHRONO is o . The chrono allows the programming of 4 time slots per day, which can be used every day of the week. For each time slot, it is possible to set ignition and switch-o times, speci c days of application, desired temperature and set power.
  • Page 30 EXAMPLE OF CHRONO OVERLAPPING TIMES/SLOTS Time slot 02:00 08:00 16:30 23:00 Set Power 02:00 08:00 16:30 23:00 Set Temperature 22° 18° 02:00 08:00 16:30 23:00 start 02:00 Time slot 1 Set Power 3 - Set Temp 22°C stop 23:00 start 08:00 Time slot 2 Set Power 1 - Set Temp 18°C stop 16:30...

  • Page 31: Settings

    SETTINGS Š DATE/TIME Š LANGUAGE SEE CHAPTER: COMMISSIONING SETTINGS. Š DEGREES DISPLAY The "DISPLAY" menu allows: Š Regulation of DISPLAY contrast Š Activation/Deactivation of backlight. Š Enabling/disabling of acoustic signal. Š Setting of the timer to turn o the Display backlight. Š...

  • Page 32: First Load

    FIRST LOAD This function allows you to activate the gearmotor for continuous pellet feeding. Before starting the function, make sure the stove is cold and “OFF”. To set: OK > SETTINGS > FIRST LOAD To stop continuous feeding, simply press and hold the key for 2 seconds.

  • Page 33: Cleaning And Maintenance

    TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR VISIT THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM CLEANING AND MAINTENANCE ALWAYS FOLLOW THE INSTRUCTIONS IN COMPLETE SAFETY! Š MAKE SURE THAT THE POWER CORD IS UNPLUGGED BECAUSE THE GENERATOR MAY HAVE BEEN PROGRAMMED TO SWITCH ON.
  • Page 34 THE FOLLOWING IMAGES ARE FOR ILLUSTRATION PURPOSES BURN POT AND COMBUSTION CHAMBER: Remove the burn pot completely from the Š relevant compartment. Once the ame guard (A) has been removed, Š vacuum the residue in the burn pot. Unblock all the holes in the burn pot using the Š...

  • Page 35: Routine Maintenance Performed By Qualified Technicians

    How often the ash drawer is emptied depends on a number of factors: the type of pellets, the stove output, the use of the stove and the type of installation. TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR VISIT THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM ROUTINE MAINTENANCE PERFORMED BY QUALIFIED TECHNICIANS Routine maintenance must be performed at least once a year.
  • Page 36 HEAT EXCHANGER ENGLISH...
  • Page 37 ROUTINE MAINTENANCE THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES. P70 AIR Fumes motor (dismantling and cleaning, ue pipe and "T” tting). Gaskets, inspections, door (replace if necessary), burn pot and heat exchanger Combustion chamber and heat exchanger (full cleaning) including ignition plug pipe Hopper (complete emptying and cleaning).
  • Page 38 ROUTINE MAINTENANCE THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES. P70 AIR PLUS Fumes motor (dismantling and cleaning, ue pipe and "T” tting). Gaskets, inspections, door (replace if necessary), burn pot and heat exchanger Combustion chamber and heat exchanger (full cleaning) including ignition plug pipe Hopper (complete emptying and cleaning).

  • Page 39: Displays

    DISPLAYS UPDATE REASON Generator o START The START phase is in progress PELLET LOADING Continuous pellet feeding is in progress during the ignition state IGNITION The phase dedicated to ignition is in progress PREPARATION The ame stabilisation phase is in progress WORK The generator has reached operating capacity and is working on user settings MODULATION...

  • Page 40: Disposal

    DISPOSAL INFORMATION FOR MANAGEMENT OF ELECTRIC AND ELECTRONIC APPLIANCE WASTE CONTAINING BATTERIES OR ACCUMULATORS This symbol, which is used on the product, batteries, accumulators or on the packaging or documents, means that at the end of its useful life, this product, the batteries and the accumulators included must not be collected, recycled or disposed of together with domestic waste. Improper management of electric or electronic waste or batteries or accumulators can lead to the leakage of hazardous substances contained in the product.
  • Page 41 ENGLISH...
  • Page 42 ENGLISH...
  • Page 43 ENGLISH...
  • Page 44 TO FIND THE SERVICE CENTRE NEAREST TO YOU CONTACT YOUR DEALER OR CONSULT THE SITE WWW.LANORDICA EXTRAFLAME.COM The manufacturer reserves the right to vary the characteristics and the data reported in this pamphlet at any moment and without notice, in order to improve its products.
