Step 6:
N o t e :
Step 7:
Step 8:
Step 9:
N o t e :
7
6
11
Cable Clamp in
Housing
Step 10: Insert the knurled head screw (6) through the housing socket (7) casting as
Step 11: Install the shorter green ground wire (18) onto the screw. The prongs on the
Step 12: Install the ground spring (29) onto the screw and secure it with the Southco flat
N o t e :
6
All manuals and user guides at all-guides.com
Install the lamp retainer spring (5). The lamp retainer spring secures the socket.
Insert the spring one end at a time, making sure the rectangular slot in each side
of the spring seats on the corresponding tab in the casting. See
If the spring does not seat correctly, coax it into place with a screwdriver or needle-
nose pliers.
7
27
24
10
Install the bushing cup (12) into the housing socket casting (7) as shown in
Figure 5. The cup should slide smoothly up and down, but not side to side.
Insert the threaded end of the index hub (4) through the holes in the bushing cup
and the back of the housing socket casting (7).
Slide the X-Y knob (10) over the exposed index hub bolt (4), then insert the wave
washer (27) on the bolt and secure with the 9/16 hex nut (24). Hand tighten the
X-Y knob (10).
Install the wave washer with the upward curve toward the hex nut.
28
26
18
29
22
8
Figure 6
shown in Figure 6.
crimped connector should be toward the casting.
retaining ring (26). Install the Southco ring with its prongs away from the casting.
Use pliers to straighten the Southco retaining ring (26) if it bends when you install
it on the bolt.
4
12
23
Figure 4.
Figure 5
Green wires
White wires
Figure 7
