A24.1001
Gem Microscope
Instruction Manual
It is recommended strongly that you study this manual thoroughly before using the
microscope. Retain this manual in an easily accessible place near the work desk for future.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A24.1001 and is the answer not in the manual?

Questions and answers

Summary of Contents for OPTO-EDU A24.1001

  • Page 1 A24.1001 Gem Microscope Instruction Manual It is recommended strongly that you study this manual thoroughly before using the microscope. Retain this manual in an easily accessible place near the work desk for future.
  • Page 2: Table Of Contents

    A24.1001 Contents ..................1 CONTENTS ................. USER NOTICE 1. Components ................3 2. Assembly .................. 4 2.1 Assembly Diagram ................. 4 2.2 Detailed Assembly Procedure ............5 3. Adjustment and Operation ............. 7 Stand Adjustment ............... 7 3.2 Adjusting Binocular Viewing Head ..........8 3.3 Bottom Illumination ...............
  • Page 3 A24.1001 Use Notices 1. Safety Precaution 1. Carefully open the box, avoid the accessories, like lens, dropping to ground and being damaged. 2. Check the input voltage, be sure the input voltage which marked on the microscope is consistent with the power supply voltage, otherwise it will bring a serious damage to the instrument.
  • Page 4: Components

    A24.1001 Components 1.Name of Components Zoom body 15×Eyepieces Stand Zoom body knob Fluorescent lamp Focusing knobs LED lighting Stone Holder Base Main Switch Brightness adjusting knob A24.1001...
  • Page 5: Assembly

    A24.1001 2. Assembly 2.1 Assembly Diagram The diagram below shows how to assemble the various modules. The numbers indicate the order of assembly. ★When assembling the microscope, make sure that all parts are free of dust and dirt, and avoid scratching any parts or touching glass surfaces.
  • Page 6: Detailed Assembly Procedure

    A24.1001 2.2 Detailed Assembly Procedure 2.2.1 Mounting zoon body (Fig. 1) Loosen the clamping bolt① on the stand and ④ ② insert the zoom body ② into the bracket of the stand, then screw down the bolt①. 2.2.2 Mounting eyepieces (Fig.1) ③...
  • Page 7 A24.1001 2.2.4 Install fluorescent lamp (Fig. 3) ① 1. Install the fluorescent lamp into the socket② in front of the stage, and seat it as deeply as possible. 2. Tightening the screw cap① to fix it. 3. The tile of fluorescent lamp illumination is ②...
  • Page 8: Adjustment And Operation

    3.Adjustment and Operation A24.1001 3. 1 Adjusting Stand 3.1.1 Adjusting the base(Fig. 5) Rotating the microscope to a suitable position for viewing comfort by pushing the base ① gently. 托架 3.1.2 Adjusting the tilt of stand(Fig. 5) The tilt of stand is adjustable by holding down the frontage of base①...
  • Page 9: Adjusting Binocular Viewing Head

    A24.1001 3.2 Adjusting Binocular Viewing Head 3.2.1 Adjusting interpupillary distance (Fig. 7) While looking through the eyepieces, hold the left and right of the binocular assembly ① and adjust the eyepieces by opening or closing them for binocular vision until the left and right fields of view coincide ①...
  • Page 10: Bottom Illumination

    A24.1001 3.3 Bottom illumination (Fig. 9, 10) Turn the main switch① to “I”(on) state, and rotate the brightness adjusting knob② to obtain a comfortable brightness. 1. Adjusting the iris diaphragm ; the iris diaphragm restricts the diameter of the beam of light entering the objective and thus ①...
  • Page 11: Top Illumination

    A24.1001 3.4 Top illumination (Fig. 11) 1. Fluorescent lamp illumination: turning the main switch⑤ to “I” (on) state, and fluorescent lamp ⑥ switch⑥ to“I”(on) station, it could get a daylight equivalent fluorescent overhead light source, and its tile is adjustable for individual comfort.
  • Page 12: Specification

    4. specification A24.1001 Specification Zoom ratio 1:6.3 0.8×~5× Zoom magnification Binocular viewing Inclined at 45°interpupillary distance range: 52~75mm head Working distance 115mm 15×/Φ16 with diopter adjustment Eyepiece Focusing range 110mm Illumination system 6V/20W Halogen illumination 8W fluorescent lamp LED lighting 0-38°Rotatable...
  • Page 13: Outfit

    PROBLEM CAUSE SOLUTION PAGE Diopter ring is not Adjust it correctly. correctly adjusted. 4. Specimen image blurs when zoom magnification is Focus specimen Not in complete focus on changed. correctly at a high specimen. magnification. 5.Coarse focus adjustment Tension adjustment ring knobs rotate with too much Loosen it properly.
