WARNINGS/AVERTISSEMENT
• WARNING: Substitution of components may impair intrinsic safety.
AVERTISSEMENT: La substitution de composants peut compromettre la
Sécurité Intrinsèque.
• WARNING: To prevent ignition of hazardous atmosphere, batteries must only
be charged (removed and replaced) in an area to be known non-hazardous.
AVERTISSEMENT: Afin de prévenir l'inflammation d'atmosphères
dangereuses, ne changer les batteries que dans des emplacements désignés
non dangereux.
• WARNING: Use only SKC charger Cat. No. 220-300.
• WARNING: Maximum charge input voltage U
CAUTIONS
• CAUTION: The battery used in this device may present a risk of fire or explosion
when heated above 212 F (100 C) or incinerated. Replace battery with SKC
Battery Pack Cat. No. P76303 only. Use of another battery may present a risk
of fire or explosion.

Battery Pack Replacement

Turn off pump by pressing the Power On/Off button located on the top of the
1.
pump. The screen will go dark.
2. Use 1.5-mm hex key to loosen two screws on back of battery pack housing.
3. To remove battery pack, lift it up against belt clip. Once clear of case, pull away
from pump case.
4. To install battery pack, align it with bottom of pump case and push it up
against belt clip until battery pack presses easily into place. Ensure it fits
flush with pump case. Use 1.5-mm hex key to tighten two screws on back of
battery pack housing in alternating fashion.
SKC Inc., Eighty Four, PA
•
724-941-9701
= 5.5V DC.
m
•
skcinc.com
Form 38059 Rev 220810
