LTPOWERPLAY QUICK START PROCEDURE
The following procedure describes how to use LTpower-
Play to monitor and change the settings of LTC3884-1.
1. Download and install the LTPowerPlay GUI:
http://linear.com/ltpowerplay
2. Launch the LTpowerPlay GUI.
a. The GUI should automatically identify the DC2605A.
The system tree on the left hand side should look like
this:
b. A green message box shows for a few seconds in the
lower left hand corner, confirming that LTC3884-1 is
communicating:
DEMO MANUAL DC2605A
c. In the Toolbar, click the "R" (RAM to PC) icon to read the
RAM from the LTC3884-1. This reads the configuration
from the RAM of LTC3884-1 and loads it into the GUI.
d. If you want to change the output voltage to a different
value, like 1.2V. In the Config tab, type in 1.2 in the
VOUT_COMMAND box, like this:
