DEMO MANUAL DC2605A
PARTS LIST
ITEM
QTY
REFERENCE
32
1
R1
33
1
R2
34
15
R3, R4, R30, R51, R52, R56, R87, R91,
R113, R114, R117, R127, R137, R138,
R148
35
3
R5, R16, R70
36
7
R6, R8, R10, R29, R34, R98, R123
37
3
R9, R128, R150
38
3
R11, R12, R13
39
4
R14, R20, R135, R143
40
24
R43, R124, R129, R162, R164, R171,
R173, R175, R176, R177, R186, R188,
R190, R191, R192, R202, R203, R205,
R206, R207, R212, R214, R216, R218
41
2
R49, R89
42
1
R55
43
3
R95, R96, R107
44
2
R79, R130
45
1
R81
46
1
R85
47
1
R92
48
1
R93
49
1
R94
50
1
R97
51
1
R99
52
1
R100
53
2
R101, R102
54
1
R103
55
1
R104
56
2
R105, R106
57
4
R147
58
4
R163, R172, R187, R201
59
1
U1
60
1
U2
61
1
U4
62
1
U5
63
1
U6
64
1
U8
65
4
U15, U16, U17, U18
10
PART DESCRIPTION
RES. 0.001Ω 1% 1W 2512
RES. 1Ω 1% 1/10W 0603
RES. 0Ω 1/10W 0603
RES. 10Ω 1% 1/10W 0603
RES. 10kΩ 1% 1/10W 0603
RES. 4.99kΩ 1% 1/10W 0603
RES. 1kΩ 1% 1/10W 0603
RES. 649Ω 1% 1/10W 0603
RES. 0Ω 1/10W 0402
RES. 2Ω 1% 1/10W 0603
RES. 100KΩ 5% 1/10W 0603
RES. 20kΩ 1% 1/10W 0603
RES. 402Ω 1% 1/10W 0603
RES. 255Ω 1% 1/10W 0603
RES. 27.4Ω 1% 2512
RES. 3.3Ω 1% 1/10W 0603
RES. 154kΩ 1% 1/10W 0603
RES. 1MΩ 5% 1/10W 0603
RES. 681kΩ 1% 1/10W 0603
RES. 301Ω 5% 1/10W 0603
RES. 82.5Ω 5% 1/10W 0603
RES. 0.01Ω 1%2512
RES. VARIABLE 5K
RES. 1.21kΩ 1% 1/10W 0603
RES. 118kΩ 1% 1/10W 0603
RES. 15.8kΩ 1% 1/10W 0603
RES. 10kΩ 1% 1/10W 0402
IC. Dual Output PolyPhase Step-Down Controller with
Sub-Milliohm DCR Sensing and Digital Power System
Management
IC. PolyPhase Step-Down Synchronous Slave Controller
with Sub-Milliohm DCR Sensing
IC. High Efficiency, 65V 500mA Synchronous
Step-Down Converter
IC. Voltage-Controlled Pulse Width Modulator
IC. Single 100V/µs,85MHz, Rail-to-Rail Input and
Output Op Amps
IC. SERIAL EEPROM
DrMOS
MANUFACTURER/PART NUMBER
VISHAY WSL25121L000FEA
VISHAY CRCW06031R0FKEA
VISHAY CRCW06030000Z0EA
VISHAY CRCW060310R0FKEA
VISHAY CRCW060310K0FKEA
VISHAY CRCW06034K99FKEA
VISHAY CRCW06031K00FKEA
VISHAY CRCW0603649RFKEA
VISHAY CRCW04020000Z0EA
VISHAY CRCW06032R0FKEA
VISHAY CRCW0603100KJNEA
VISHAY CRCW060320K0FKEA
VISHAY CRCW0603402RFKTA
VISHAY CRCW0603255RFKEA
VISHAY CRCW06033R30FKEA
VISHAY CRCW06033R30FKEA
VISHAY CRCW0603154KFKEA
VISHAY CRCW06031M00JNEA
VISHAY CRCW0603681KFKEA
VISHAY CRCW0603301RFKEA
VISHAY CRCW060382R5FKEA
VISHAY WSL2512R0100FEA
BOURNS 3386P-1-502-LF
VISHAY CRCW06031K21FKEA
VISHAY CRCW0603118KFKEA
VISHAY CRCW060315K8FKEA
VISHAY CRCW040210K0FKED
LINEAR TECH.LTC3884ERHE-
1#10GV-1PBF-ES
LINEAR TECH.LTC3874EUF-1
LINEAR TECH. LTC3630EMSE#PBF
LINEAR TECH. LTC6992IS6-1#PBF
LINEAR TECH. LT1803IS5#PBF
MICROCHIP 24LC024-I/ST
Fairchild FDMF3170
dc2605af
