PARTS LIST
ITEM QTY REFERENCE
Additional Demo Board Circuit Components
1 0 COUT17, COUT18, COUT22, COUT23,
COUT35, COUT36, COUT37, COUT38,
COUT39, COUT40
2 0 C5, C51, C183, C187, C193, C199
3 0 D11
4 0 R119, R120, R125, R160, R161, R167,
R168, R169, R170, R174, R181, R183,
R184, R185, R189, R197, R198, R199,
R200, R204, R209, R211, R213, R215,
R217, R17, R22, R23, R24, R25, R26,
R27, R28, R31, R32, R35, R36, R37,
R38, R87, R122, R134, R136, R141,
R142, R145, R151, R139, R85, R159,
R121, R195, R194, R59
Hardware: For Demo Board Only
1 16 E1-E4, E7, E8, E21-E26, E28, E34, E36,
E37
2 5 JP1, JP2, JP3, JP4, JP5
3 2 J11, J12
4 1 J13
5 1 J14
6 1 J15
7 1 J16
8 1 SW2
9 5 XJP1 XJP2 XJP3 XJP4 XJP5
10 4 MH1 MH2 MH3 MH4
DEMO MANUAL DC2605A
PART DESCRIPTION
CAP ., OPTION
CAP ., OPTION
DIODE., SOD323 OPTIONAL
RES. OPTIONAL
TEST POINT TURRET, 0.094" MTG. HOLE
CONN. HDR MALE 1×3 2mm THT STR
CONN. BNC PC MOUNT RECEPT. JACK 50Ω TF-4 POST
CONN. HEADER 2×7 2mm R/A (F)
HEADER 12PIN 2mm STR DL
CONN. HEADER 2×7 2mm R/A (M)
HEADER 4PIN 2mm STR DL
SWITCH Slide Switch DPDT Through Hole
CONN. SHUNT FEMALE 2 POS 2mm
STANDOFF SNAP ON
MANUFACTURER/PART NUMBER
MILL-MAX 2501-2-00-80-00-00-
07-0
WURTH ELEKTRONIK
62000311121
AMPHENOL CONNEX 112404
SULLINS NPPN072FJFN-RC
FCI 98414-G06-12ULF
MOLEX 87760-1416
HIROSE DF3A-4P-2DSA
C&K JS202011CQN
WURTH ELEKTRONIK
60800213421
KEYSTONE 8834
