- Page 1 Quick Start Guide for M53015EVB M53015EVB 32-bit ColdFire MCU...
- Page 2 Get to know the M53015EVB P&E BDM USB Port RESET Button DB9 RS232 ABORT Button Serial Port USB-to-Serial Port SD Slot MCF53015 SIM Slot Barrel LED1, LED2, Connector LED3, LED4 External Power University Breakout Connector Power Switch On-Board On-Board Speaker...
- Page 3 Quick Start Guide for M53015EVB Introduction In this Quick Start Guide, you will learn how to setup the Web server on the board and use the pre-loaded u-boot bootloader to boot the µClinux kernel with filesystem resident in flash. In addition, this Quick Start Guide will provide a...
-
Page 4: Connect The Usb Cable
Step-by-Step Installation Instructions STEP STEP Connect the Connect the USB Cable Power Connector Connect the USB cable from the PC to the Serial-to-USB connector Plug the power connector into the barrel (UART0) on J49. connector (J51) on the board. Power-on the board via the switch (SW6). - Page 5 Quick Start Guide for M53015EVB STEP Open and Configure HyperTerminal Configure for 115200, 8 bits, no flow control, 1 stop bit. STEP Connect an Ethernet Cable to the Network If you would like to connect the board via a local network, connect an Ethernet cable between the network and the board via the bottom RJ45 jack.
- Page 6 STEP STEP Connect an Ethernet If Necessary, Manually Cable Between Setup TCP/IP on the PC the PC and the Board The default IP address of the board is 169.254.3.3. Typically, when you connect Connect an Ethernet cable between your computer directly to the board, the PC and the board via the top the computer will default to an auto IP RJ45 jack (P2).
- Page 7 Quick Start Guide for M53015EVB STEP Confirm IP Address of Board Now, go to the previously configured HyperTerminal window. At this point, the board would have already booted and you will have to hit “Enter” in order to see the “$”...
-
Page 8: Open A Web Browser
Insert the included SD memory device previous step, to view the Web page that into the board’s SD connector (P1). resides in the M53015EVB external flash You will see µClinux automount the SD memory. memory device, which is a new feature added to the standard ColdFire µClinux... -
Page 9: Record Your Voice
Quick Start Guide for M53015EVB STEP Record Your Voice After the SD memory device has In HyperTerminal, type the command: mounted, it is now ready to use. We will vrec -w -t 10 -s 8000 -b 16 -D /dev/ dsp1 /mnt/sd/test.wav. Now, speak use the on-board microphone to record voice with the internal voice codec. - Page 10 For further details of the internal and external codecs, please refer to the M53015EVB User’s Manual. Insert the included USB mass storage Next, type the command: vplay -t 10 -s device into the board’s USB Type A...
- Page 11 Quick Start Guide for M53015EVB STEP Hear the Music After the USB mass storage device has initialized and attached, it is now ready to use. In HyperTerminal using the kernel prompt, type the command: ls /mnt/usb. You will see the contents listed as: sample1.mp3* and sample2.
-
Page 12: Create New Project
IDE from task bar. IDE starts and the rior Startup dialog box appears CodeWarrior Startup dialog box appears Startup Dialog Box c. Select ColdFire Evaluation Boards > ColdFire V3 > M53015EVB d. Select P&E USB BDM Multilink c. Select ColdFire Evaluation Boards > ColdFire V3 > M53015EVB d. - Page 13 Quick Start Guide for M53015EVB f. Choose C g. Enter a project name in Project name text box. The software automatically creates a folder with the same name in the default location, or click Set to browse and select an alternate location for your e.
- Page 14 C/C++ Options Window STEP Connect c. Open Terminal Window configured for 19200, 8 bits, no flowcontrol, 1 stop bit Connect USB cable to J48 and RS-232 cable to J52 connectors on the d. From main menu bar, select Project > board.
- Page 15 Quick Start Guide for M53015EVB...
- Page 16 Learn more at www.freescale.com/coldfire. Freescale, the Freescale logo, CodeWarrior and ColdFire are trademarks or registered trademarks of Freescale Semiconductor, Inc. in the U.S. and other countries Reg. U.S. Pat. & Tm. Off. All other product or service names are the property of their respective owners.
