BLEDAUG
Bluetooth Low Energy Demo Applications User's Guide
Rev. 3.6 — 26 November 2024
Document information
Information
Keywords
Abstract
Content
Bluetooth Low Energy host stack, KW45, K32W1, FRDM-MCXW71, KW47, MCXW72
development platforms, evaluation kit (EVK), KW47-EVK, MCXW72-EVK and FRDM-MCXW72
evaluation kits, KW45B41Z-EVK, K32W148-EVK, , hardware and toolchain requirements,
Software Development Kit (SDK), sample applications
This document describes the Bluetooth Low Energy host stack enablement for KW45B41Z-
EVK, K32W148-EVK, FRDM-MCXW71, KW47-EVK, MCXW72-EVK, and FRDM-MCXW72
development platforms development platforms. It describes the hardware and toolchain
requirements and steps to build and run the demo applications included in the software
development kit.
User guide
