Regency Ultimate ™ U900E
Warning
Fire or explosion Hazard
failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appli-
ance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Certified to/Certifié pour: CSA 2.17-2017
920-007e
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
Gas Fireplace
ANSI Z21.88-2017
CSA 2.33-2017
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
00E
MODELS:
U9
-NG11 Natural Gas
00E
U9
-LP11 Propane
www.regency-fire.com
05.27.21
Advertisement
Table of Contents
Related Manuals for Regency Fireplace Products Ultimate U900E-NG11
Summary of Contents for Regency Fireplace Products Ultimate U900E-NG11
- Page 1 Regency Ultimate ™ U900E Owners & Installation Manual Gas Fireplace MODELS: -NG11 Natural Gas -LP11 Propane www.regency-fire.com Warning Fire or explosion Hazard failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appli- ance.
- Page 2 MANUFACTURED MOBILE HOME REQUIREMENTS INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE This Regency product has been tested and listed by Intertek as a Direct Vent Wall Furnace to the following standards: to ® Vented Gas Fireplace Heaters ANSI Z21.88-2017 • CSA 2.33-2017 and Gas-fired Appliances for Use at High Altitudes CSA 2.17-2017.
-
Page 3: On Demand Pilot Light (Seven Day Safety Timer)
To the New Owner: Congratulations! You are the owner of a state-of-the-art Gas Fireplace by REGENCY . The U900E has been designed to provide ® you with all the warmth and charm of a fireplace at the flick of a switch. The model U900E has been approved by Warnock Hersey/Intertek for both safety and efficiency. -
Page 4: Table Of Contents
table of contents owner's information Unit Installation with Horizontal Termination ........39 Dura-Vent Horizontal terminations ..........40 unit installation with Vertical Termination ........41 On Demand Pilot Light (seven day safety timer) ......3 4" x 6-5/8" venting ................41 Copy of Safety Decal ..............5 Vertical flue extension kit (part #946-756) ........43 Decal location .................5 Ceiling Firestop / firestop spacer (part #946-757) ......43... -
Page 5: Copy Of Safety Decal
safety decal This is a copy of the label that accompanies each U900E-NG and U900E-LP Direct Vent Gas Fireplace. We have printed a copy of the contents here for your review. NOTE: Regency ® units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. COPY OF SAFETY DECAL Duplicate S/N Listed/Nom: VENTED GAS FIREPLACE / FOYER AU GAZ À... - Page 6 dimensions Reference Description Inches/Millimeters Gas Connection Opening Height 1-11/16" (43mm) Gas Connection Height 2-11/16" (67mm) Gas Connection Inset 1-1/8" (29mm) Gas Connection Opening Width 4-11/16" (119mm) Outer Faceplate size - 43-1/16" W x 25-1/4" H Glass Surround size - 47" W x 25-1/4" H Finishing Trim (Clean Edge Design) size - 40-1/8"...
-
Page 7: Important Message
owner's information IMPORTANT MESSAGE YOUNG CHILDREN SHOULD BE CARE- 4. This appliance must be connected to the SAVE THESE specified vent and termination cap to the outside FULLY SUPERVISED WHEN THEY ARE INSTRUCTIONS of the building envelope. Never vent to another IN THE SAME AREA AS THE APPLI- room or inside a building. -
Page 8: Lighting Procedure
owner's information LIGHTING PROCEDURE IMPORTANT: The remote control system supplied with this appliance has Note: The first try for ignition will last approximately 60 seconds. If there is no several options for starting/operating the appliance using the battery holder flame ignition (rectification) the board will stop sparking for approximately and ON/OFF key on the hand held transmitter. -
Page 9: Copy Of The Lighting Plate Instructions
owner's information COPY OF THE LIGHTING PLATE INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING POUR VOTRE SÉCURITÉ – À LIRE AVANT LA MISE EN MARCHE This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1. -
Page 10: Proflame Ii Remote Control Operating Instructions
owner's information PROFLAME II REMOTE CONTROL OPERATING INSTRUCTIONS IMPORTANT:The Proflame Transmitter 2 is an integrated part of the TECHNICAL DATA Proflame 2 System, which consists of these elements: REMOTE CONTROL • Proflame 2 Transmitter, to be used in conjunction with: •... - Page 11 owner's information Temperature indication Display Remote-Flame Control With the system in the "OFF" position, press the Thermostat Key and The Proflame has six (6) flame levels. With the system on, and the the Mode Key at the same time. Look at the LCD screen on the transmit- flame level at the maximum in the appliance, pressing the Down Arrow ter to verify that a C or F is visible to the right of the room temperature Key once will reduce the flame height by one step until the flame is...
- Page 12 owner's information Smart Thermostat (Transmitter Operation) Remote dimmer control (Light)** The auxiliary function controls the AUX power outlet by the dimmable The Smart Thermostat function adjusts the flame height in accordance light control. To activate this function use the Mode Key (fig. 1) to index to the difference between the set point temperature and the actual to the AUX icon (fig.
- Page 13 owner's information Continuous Pilot/Intermittent Pilot (CPI/IPI) selection 5. "Clr" will remove a mode—use the up or down arrow while hold- ing down ON/OFF and MODE (mode icon will disappear once removed). Note: Power vent models do not have a Continuous 6.
-
Page 14: Installer's Information
installer's information INSTALLATION CHECKLIST 4. This appliance is Listed for bedroom installations 15. Reinstall installation access panel. using the standard Remote (thermostat system). 1. Locate appliance Some areas may have further requirements, 16. Final check. a) Room location (Refer to "Locating Your Gas check local codes before installation. -
Page 15: Ma Code - Co Detector
requirements installer's information MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:... -
Page 16: Clearances
installation CLEARANCES The clearances listed below are minimum distances unless otherwise stated: A major cause of chimney related fires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance that this fireplace and vent system be installed only in accordance with these instructions. Flue Pipe Clearances to Combustibles Clearance: Dimension... -
Page 17: Mantel Clearances
installation MANTEL CLEARANCES Due to the extreme heat this fireplace emits, the mantel clearances are critical. Combustible mantel clearances from top of front facing are shown in the diagram on the right. Note: Ensure the paint that is used on the mantel and the facing is "high quality"... -
Page 18: Unit Assembly Prior To Installation
installation UNIT ASSEMBLY PRIOR TO INSTALLATION The nailing strips must be correctly positioned and attached before unit is slid into position. NAILING STRIPS The nailing strips come attached to the unit. There is 1 plate on each side, these nailing strips are secured to the framing. IMPORTANT NOTE Framing depth measurement is noted with the nailing strips set as far forward on the firebox as possible. -
Page 19: Framing Dimensions
installation FRAMING DIMENSIONS Framing Description U900E Dimensions Framing Height 42-1/4" (1073mm) Framing Width 45" (1143mm) Framing Depth 22-3/4" (578mm) Minimum Height to Combustibles 52-1/4" (1327mm) Corner Facing Wall Depth 51-1/2" (1308mm) Corner Facing Wall Width 72-1/2"(1842mm) Vent Centerline Height 39" (991mm) Non-combustible facing height 20"... -
Page 20: Optional Framing Kit
installation U900E OPTIONAL FRAMING KIT OPTIONAL FRAMING KIT 1. Construct the wood framing, ensure inside dimensions are 42-7/8" H x 44-3/8" W as shown below. 44-3/8” 42-7/8” (466-126) Flat side out 5. Secure horizontal steel header stud (466-128) with 2 screws per side as 2. -
Page 21: Horizontal Vent Deflector Installation
installation HORIZONTAL VENT DEFLECTOR INSTALLATION Note: This installation is only required for horizontal terminations. If any 3. Install the horizontal section of the deflector to the vertical section at the rise is used when venting this unit - the deflector and extender are desired height with 2 screws. -
Page 22: Wall Mount On / Off Switch And Battery Holder Installation
installation WALL MOUNT ON / OFF SWITCH AND BATTERY HOLDER INSTALLATION REQUIRED FOR ALL INSTALLATIONS IMPORTANT INSTALLATION NOTE: The Battery Holder must be placed inside the supplied (Low Voltage) junction type wall box and installed into the wall only. DO NOT INSTALL WITHIN THE CONFINES OF THE FIREPLACE SWITCH MUST BE ACCESSIBLE Battery Holder Installation 1. -
Page 23: Non-Combustible Requirements
installation NON-COMBUSTIBLE REQUIREMENTS * Installation of the ON/OFF Wall Switch/Battery Holder must be completed before installing non-combustible facing. All three pieces (top, 2 sides) may be ordered separately to meet the non combustible requirements. Calcium silicate board is a high - grade material with cement, quartz, natural and selected minerals as the main raw materials. -
Page 24: Framing & Finishing
installation FRAMING & FINISHING 1) Frame in the enclosure for the unit with framing material. 5) If material such as brick, stone, etc extends past the faceplate depth 1-1/2", when finishing around the faceplate, the minimum opening dimensions IMPORTANT: The facing material must be of non-combustible noted below must be adhered to ensuring for the removal of the faceplate material. - Page 25 Discoloration is not the responsibility of Regency Fireplace Products. This is out of the control of Regency Fireplace Products Ltd., therefore not covered under any part of the warranty policy.
-
Page 26: Exterior Vent Termination Requirements
installation EXTERIOR VENT TERMINATION REQUIREMENTS Minimum Clearance Requirements Canada Clearance above grade, veranda, porch, deck, or balcony 12"(30cm) 12"(30cm) Clearance to window or door that may be opened 12"(30cm) 9" (23cm) Clearance to permanently closed window Vertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2 feet (61cm) 19"(48cm) 19"(48cm) from the center line of the terminal (check with the local code) -
Page 27: Vent Restrictor Setting
installation VENT RESTRICTOR SETTING Vent restriction is required for certain venting installations, see the diagrams in the "Venting Arrangements" section to determine if they are required for your installation. The Vent Restrictor plate is located on the inside top of the firebox. To set the vent restriction as indicated in the venting arrangements diagrams, refer to the following instructions;... -
Page 28: Venting
installation VENTING DIRECT VENT SYSTEM (FLEX) HORIZONTAL TERMINATIONS ONLY These venting systems, in combination with the U900E Direct Vent Gas Fireplace, have been tested and listed as a direct vent heater system by Warnock Hersey/ITS. The location of the termination cap must conform to the requirements in the Vent Terminal Locations diagram in the "Exterior Vent Termination Locations"... -
Page 29: 4" X 6-5/8" Rigid Pipe
installation 4” X 6-5/8” RIGID PIPE CROSS REFERENCE CHART ONLY Components from different Manufacturers may not be mixed. Not All Rigid Pipe components are available directly from FPI. 4" X 6-5/8" RIGID PIPE CROSS REFERENCE CHART Note: Olympia Ventis DV is only approved for certain models. See list of approved models in cross-reference chart. Components from different Manufacturers may not be mixed. - Page 30 installation Description Simpson *Selkirk *American Metal *Metal-Fab™ *Security *ICC Excel *Olympia Direct Vent Pro ® Direct Temp™ Products® Sure Seal Secure- Vent® Direct Ventis DV*** Amerivent Direct Attic Insulation Shield 12" 46DVA-IS 4DAIS12 4DIS SV4RSA VDV-AIS04 Attic Insulation Shield 4DAIS12 TM-4AS - Cold Climates 36"...
-
Page 31: Rigid Pipe Venting Systems
Direct Vent , American Metal Products Ameri Vent Direct Vent, Security Secure Vent , Selkirk Direct-Temp. AstroCap is a proprietary ® ® trademark of Regency Fireplace Products. Dura-Vent® and Direct Vent are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc. Regency Ultimate ™ U900E-11 Gas Fireplace... -
Page 32: Venting Introduction
installation VENTING INTRODUCTION The U900E uses the "balanced flue" technology Co-Axial system. The inner liner vents products of combustion to the outside while the outer liner draws outside combustion air into the combustion chamber thereby eliminating the need to use heated room air for combustion and losing warm room air up the chimney. Note: These flue pipes must not be connected to any other appliance. -
Page 33: Venting Arrangement For Vertical Terminations
installation VENTING ARRANGEMENT FOR VERTICAL TERMINATIONS Vertical Venting with One(1) 90 Elbows (1 - 90 2 - 45 ) with straight Vertical and or a maximum offset using 2 - 90º elbows The shaded area in the diagram shows all allowable combinations of straight vertical and offset to vertical terminations, using one elbow, with Rigid Pipe Venting Systems. - Page 34 installation Vertical Venting with Three (3) 90 Elbows One 90 elbow = Two 45 elbows. Option H + H1 V + V1 With these options, 0' Min. 2' Max. 2' Min. max. total pipe length 1' Min. 2' Max 3' Min. is 30 feet with min.
- Page 35 installation Horizontal Venting with Two (2) 90 Elbows One 90 elbow = Two 45 elbows. Option H + H1 W i t h t h e s e o p t i o n s , 1' Min. 3' Max. maximum total pipe length 2' Min.
-
Page 36: Vertical Termination -Co-Linear Flex System
installation VERTICAL TERMINATION - CO-LINEAR FLEX SYSTEM INTO A MASONRY CHIMNEY THE APPLIANCE MUST NOT BE CONNECTED TO A CHIMNEY FLUE SERVING A SEPARATE SOLID FUEL BURNING APPLIANCE. This appliance is designed to be attached to two 3" (76mm) co-linear aluminium flex running the full length of the chim- ney. -
Page 37: Venting Arrangements - Vertical Termination
installation VENTING ARRANGEMENTS - VERTICAL TERMINATION WITH CO-LINEAR FLEX SYSTEM FOR BOTH RESIDENTIAL & MANUFACTURED HOMES INTO MASONRY FIREPLACES The shaded area in the diagrams show the allowable vertical terminations. Restrictor Position Set 0-3" Factory Setting Regency Ultimate ™ U900E-11 Gas Fireplace... -
Page 38: Unit Installation With Horizontal Termination
installation UNIT INSTALLATION WITH HORI- 7. Ensure that the pipe clearances to combustible 5. Assemble the desired combination of pipe and materials are maintained (Diagram 3). Install elbows to the appliance adaptor and twist-lock ZONTAL TERMINATION the termination cap. for a solid connection. 4"... -
Page 39: Unit Installation With Horizontal Termination
installation ASTROCAP UNIT INSTALLATION WITH HORI- NOTE: Horizontal sections must be supported at intervals not exceeding 3 feet (0.9 meter). DIMENSIONS (946-523/P) ZONTAL TERMINATION (Flame picture and performance will be 4" X 6-5/8" VENTING affected by sags in the liner). (Flex Vent Systems) 4. -
Page 40: Dura-Vent Horizontal Terminations
installation DURA-VENT HORIZONTAL 5) Mark the wall for a 10" x 10" square hole. The center of the square hole should line up with TERMINATIONS the centerline of the horizontal pipe. Cut and frame the 10 inch square hole in the exterior Install the vent system according to the wall where the vent will be terminated. -
Page 41: Unit Installation With Vertical Termination
installation UNIT INSTALLATION WITH VERTI- 4. Assemble the desired lengths of pipe and CAL TERMINATION elbows. Ensure that all pipes and elbow con- 4" X 6-5/8" VENTING nections are in the fully twist-locked position (Rigid Vent Systems) and sealed. 1. Maintain the 1-1/2" clearances (air spaces) to combustibles when passing through ceilings, walls, roofs, enclosures, attic rafter, or other Diagram 4... - Page 42 installation VERTICAL TERMINATION 4" X 6-7/8" VENTING - VERTICAL FLEX VENT KIT (946-755) 1. Maintain the 1-½” (38 mm) clearance (air space) to combustibles when 11. Secure inner fl ex pipe to pipe adaptor by using Mill-Pac over the adaptor. passing through ceilings, walls, fl...
-
Page 43: Vertical Flue Extension Kit (Part #946-756)
installation VERTICAL FLUE EXTENSION KIT (PART #946-756) VERTICAL FLUE EXTENSION KIT (PART # 946-756) 20 foot (6.1 m) Flex pipe Extension CEILING FIRESTOP/FIRESTOP SPACER (Used in conjunction with the 946-755 Vertical Flex kit and 948-367/P flex 4" (102 mm) inner to flex adaptor). -
Page 44: High Elevation
installation PILOT ADJUSTMENT 885 S.I.T. VALVE U900E-NG11 SYSTEM DATA DESCRIPTION Periodically check the pilot flames. Correct flame Min. Supply Pressure 5" WC (1.25 kpa) pattern has two strong blue flames: 1 flowing Max. Supply Pressure 1/2" Psi (3.45 kpa) around the flame sensor and 1 flowing across 1) 6 Stage flame adjustment Manifold Pressure - High 3.5"... -
Page 45: Aeration Adjustment
installation AERATION ADJUSTMENT The burner aeration is factory set but may need adjusting due to either the local gas supply or altitude. Open the air shutter for a blue flame or close for a more yellow flame. Minimum Air Shutter Opening: 1/4"... -
Page 46: Wiring Diagram
installation WIRING DIAGRAM CAUTION: This heater does not require a 120V A.C. supply Ensure that the wires do WARNING: for operation. In case of a power failure, the re- not touch a hot surface and are away Electrical Grounding mote control/thermostat will continue to operate. from sharp edges. -
Page 47: Log Set Installation
gF900 installation Log Set InStaLLatIon LOG SET INSTALLATION Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation. Improper positioning of the logs may create carbon build-up and can alter the unit's performance which is not covered under warranty. - Page 48 installation GF900 7. Position Log 6 to rest on Log 1 and Log 3 as shown in Diagram 9. 4. Rest Log 4 on Log 1 and Ceramic Log Burner as shown in Diagram 6. Diagram 9 Diagram 6 8. Line up locator on bottom of Log 7 with locator on Ceramic Log Burner as shown in Diagram 10.
-
Page 49: Front Trim Removal / Installation
installation FRONT TRIM REMOVAL / INSTALLATION 1. Remove faceplate, inner door frame, and glass door if already installed - see instructions in this manual. 2. Remove two (2) screws in locations shown below to remove front trim piece. 3. Reverse steps to reinstall. Front Trim Piece Diagram 1 - Front Trim Screw Locations INNER PANEL REMOVAL / INSTALLATION... -
Page 50: Screen & Inner Door Frame Installation
installation SCREEN & INNER DOOR FRAME INSTALLATION SAFETY SCREEN / INNER DOOR FRAME REMOVAL/INSTALLATION THE INNER DOOR FRAME (3) MUST BE PURCHASED SEPARATELY IN EITHER STAINLESS STEEL OR BLACK 1. The inner door trim (1) and safety screen (2) come attached to the fireplace. 4. -
Page 51: Glass Surround Installation
installation GF900 GLASS SURROUND INSTALLATION GLASS SURROUND INSTALLATION Install the fascia to the unit by hooking the left and right side mounting brackets into the mounting slots at the side of the fi rebox as shown below. It is recommended that you use the fi rst mounting slot (the one closest to the door frame overlay) out of the 3 so that the faceplate and door frame overlay are fl... -
Page 52: Faceplate Installation
installation FACEPLATE INSTALLATION Install the faceplate to the unit by hooking the left and right side mounting brackets into the mounting slots at the side of the firebox as shown below. It is recommended that you use the first mounting slot (the one closest to the door frame overlay) out of the 3 so that the faceplate and door frame overlay are flush with one another. -
Page 53: First Fire
operating instructions FIRST FIRE 8. Remote control requires coding. See remote coding instructions for details. The first fire in your fireplace is part of the paint NOTE: This appliance will operate with 4 AA back- curing process. To ensure that the paint is properly up batteries installed (see Back-up Battery cured, it is recommended that you burn your section for details) during power outages. -
Page 54: Lighting Procedure
operating instructions LIGHTING PROCEDURE IMPORTANT: The remote control system supplied with this appliance has Note: The first try for ignition will last approximately 60 seconds. If there is no several options for starting/operating the appliance using the battery holder flame ignition (rectification) the board will stop sparking for approximately and ON/OFF key on the hand held transmitter. -
Page 55: Copy Of The Lighting Plate Instructions
operating instructions COPY OF THE LIGHTING PLATE INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1. WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 56: Normal Operating Sounds Of Gas Appliances
maintenance NORMAL OPERATING SOUNDS OF 2) Clean glass (never when unit is hot), appliance, CAUTION: ANY SAFETY SCREEN and door with a damp cloth. Never use an GAS APPLIANCES OR GUARD REMOVED FOR SER- abrasive cleaner. VICING AN APPLIANCE MUST BE It is possible that you will hear some sounds from 3) The heater is finished in a porcelain finish or REPLACED PRIOR TO OPERATING... -
Page 57: Glass Gasket
maintenance GLASS GASKET GENERAL VENT MAINTENANCE If the glass gasket requires replacement use a tadpole glass gasket (Part # 936-157). Conduct an inspection of the venting system semi- annually. Recommended areas to inspect as follows: 1. Check the Venting System for corrosion in areas GLASS DOOR that are exposed to the elements. -
Page 58: Fan Service
maintenance FAN SERVICE 7. Remove burner by removing 2 screws in locations shown below. PRIOR TO SERVICING THE FAN, ENSURE UNIT HAS COOLED TO ROOM TEMPERATURE, ALL POWER IS DISCONNECTED AND GAS SUPPLY IS TURNED OFF. 1. Remove faceplate, inner frame, glass door, front trim piece and inner panels - see instructions in this manual. -
Page 59: Glass Door Removal
maintenance GLASS DOOR REMOVAL WARNING: Do not operate the appliance with the glass panels removed, cracked or broken. Replacement of the glass panels should be done by a licensed or qualified service person. Glass should be cool if cleaning is necessary. 1. -
Page 60: Valve Tray Replacement
maintenance VALVE TRAY REPLACEMENT PRIOR TO VALVE TRAY REPLACEMENT, ENSURE UNIT HAS COOLED TO ROOM TEMPERATURE, ALL POWER IS DISCONNECTED AND 7. Remove burner by removing 2 screws in locations shown below. GAS SUPPLY IS TURNED OFF. 1. Remove faceplate, inner frame, glass door, front trim piece and inner panels - see instructions in this manual. -
Page 61: Gas Maintenance
maintenance Gas Maintenance GAS MAINTENANCE Recommended Annual Routine Maintenance for Gas Fireplaces, Stoves and Inserts In order for your Regency appliance to continue to provide comfort to your home periodic maintenance must be performed to ensure it is operating at peak efficiency. The items in the list should be checked by a licensed gas service technician during the annual service check. Your unit may require more frequent maintenance checks if you notice any changes in how it operates. Operational changes to look for can include, but are not limited to, extended start up time, increased fan noise, residue/carbon build up, white build up on the glass/firebox, increased operating noise etc. Should any of these or other conditions arise, discontinue use and schedule a service check with your local licensed gas technician. The list below shows items your licensed service technician will need to check and service at least annually. Clean Inspect Check • Glass • Pilot assembly • Voltage on thermocouple/thermopile (mil- • Interior bricks / panels • Burner livolt models) • Burner ports & burner air shutter • Pressure relief gaskets/doors • Ohms reading on flame sense (electronic •... -
Page 62: Main Assembly
parts list MAIN ASSEMBLY Part # Description Part # Description 904-644 Orifice - NG #35 396-527 Bottom Door Latch 904-390 Orifice - LP #52 636-576/P U900E Valve Assy LP 911-084 Sit Valve NG 636-774/P U900E Valve Assy NG 466-044 Front deflector 911-085 Sit Valve LP 466-060... - Page 63 parts list MAIN ASSEMBLY Regency Ultimate ™ U900E-11 Gas Fireplace...
-
Page 64: Accessories
parts list ACCESSORIES Part # Description 32 636-914 Inner Door Frame - Black 33 636-924 Faceplate & Door Frame Black 636-951 Faceplate & Door Frame Black Glass (not shown) 467-900 Steel Stud Framing (not shown) 636-936 Non-Combustible Board (not shown) 636-969 LP Conversion Kit (not shown) Regency Ultimate ™... - Page 65 notes Regency Ultimate ™ U900E-11 Gas Fireplace...
-
Page 66: Warranty
warranty Limited Lifetime Warranty FPI Fireplace Products International Ltd. (for Canadian customers) and Fireplace Products U.S., Inc. (for U.S. customers) (collectively referred to herein as “FPI”) extends this Limited Lifetime Warranty to the original purchaser of this appliance provided the product remains in the original place of installation. The items covered by this limited warranty and the period of such coverage is set forth in the table below. - Page 67 warranty At all times FPI reserves the right to inspect reported complaints on location in the field claimed to be defective prior to processing or authorizing of any claim. Failure to allow this upon request will void the warranty. All warranty claims must be submitted by the dealer servicing the claim, including a copy of the Bill of Sale (proof of purchase by you).
- Page 68 warranty Limitations of Liability: The original purchaser’s exclusive remedy under this warranty, and FPI’s sole obligation under this warranty, express or implied, in contract or in tort, shall be limited to replacement, repair, or refund, as outlined above. IN NO EVENT WILL FPI BE LIABLE UNDER THIS WARRANTY FOR ANY INCIDENTAL OR CONSEQUENTIAL COMMERCIAL DAMAGES OR DAMAGES TO PROPERTY.
- Page 69 warranty Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 70 warranty Regency Ultimate ™ U900E-11 Gas Fireplace...
- Page 71 warranty Regency Ultimate ™ U900E-11 Gas Fireplace...
- Page 72 Installer: Please complete the following information Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial #: ____________________________________________________________ Printed in Canada Regency and Ultimate are trademarks of FPI Fireplace Products International Ltd. © Copyright 2021, FPI Fireplace Products International Ltd. All rights reserved.
