Regency Fireplace Products U41 Owner's Manual

Gas insert zero clearance kit

Advertisement

Quick Links

Owners &
Installation
Tested by:
Warnock Hersey:
U41/I41 GAS INSERT
ZERO CLEARANCE KIT
KIT # 660-900
PLEASE KEEP THESE INSTRUCTIONS FOR
FUTURE REFERENCE
WARNING:
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property dam-
age. Refer to this manual.
assistance or additional information
consult an authorized installer, serv-
ice agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapours and liquids in
the vicinity of this or any other appli-
ance.
Installation and service must be per-
formed by an authorized installer,
service agency or the gas supplier.
FPI Fireplace Products International Ltd.
6988 Venture St., Delta, B.C.
Canada, V4G 1H4
Australian Heating Distributors
10/46 James St.,
Guildford, Western Australia 6055
908-427
FOR YOUR SAFETY
What to do if you smell gas:
- Do not try to light any
appliance
For
- Do not touch any electri-
cal switch: do not use any
phone in your building.
- Immediately call your gas
supplier from a neigh-
bour's phone. Follow the
gas supplier's instructions.
- If you cannot reach your
gas supplier, call the fire
department.
Masport Head Office - Australia
54 Boundary Rd. Braeside
P.O. Box 553
Mordialloc 3195
Ph. (03) 9586-7777
Fax. (03) 9586-2980
Masport Head Office - New Zealand
1-37 Mt Wellington Hwy.Panmure,
P.O. Box 14349
Auckland 6.
Ph. (9) 570-9009
Fax. (9) 527-1294
01/16/04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the U41 and is the answer not in the manual?

Questions and answers

Summary of Contents for Regency Fireplace Products U41

  • Page 1 U41/I41 GAS INSERT ZERO CLEARANCE KIT KIT # 660-900 Owners & Installation PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE FOR YOUR SAFETY WARNING: What to do if you smell gas: Improper installation, adjustment, alteration, service or maintenance - Do not try to light any...
  • Page 2: Required Parts

    U41/I41 Zero Clearance Kit Specifications Using Kit# 660-900 you can convert the Gas Insert models U41 and GENERAL INFORMATION I41 into highly efficient heat producing Zero Clearance Fireplaces.
  • Page 3: Installation

    12-3/4" 324mm 9.0" 229mm 12-7/8" 327mm 9.5" 242mm 13" 330mm Note: A non-combustible mantel may be installed at a lower height if the framing is made of metal studs covered with a non-combustible board. U41/I41 Gas Insert Zero Clearance Kit...
  • Page 4 Durock, Micor, Hardibacker, Capeboard, etc. 1-1/2" 38mm 18" 457mm c) 1"(25mm) thickness of brick. 1-1/4" 32mm 17" 432mm 1" 26mm 16" 407mm 7/8" 22mm 15" 381mm 5/8" 16mm 13" 330mm 1/4" 11" 280mm 0" 9" 229mm U41/I41 Gas Insert Zero Clearance Kit...
  • Page 5: Zero Clearance Kit Assembly

    (3 per side) and 3 predrilled holes framing header. in the Front Base assembly. It is recommended that the Front Base assembly and Main body base be nailed to the floor. U41/I41 Gas Insert Zero Clearance Kit...
  • Page 6 Underwriters Laboratories and marked "WIND" may terminate at levels lower than the 10 ft. - 2 ft. rule. See chimney manufacturer's instructions for further information. NOTE: Cold Climate Installation Do not install against a non-insulated wall or in a chase. U41/I41 Gas Insert Zero Clearance Kit...
  • Page 7: Optional Outside Combustion Air Supply Installation

    The height at which the mantel must be installed above the top louver depends on the depth of the mantel. If the mantel is to be painted, use a heat resistant paint to prevent discolouration. Faceplate and trim installation instructions are in the U41/I41 Insert manual. NOTE: the top faceplate assembly has insulation installed for safety reasons and must not be removed.
  • Page 8 © Copyright 2004, FPI Fireplace Products International Ltd. All rights reserved. Printed in Canada...
