Bellavista ® B36XTE
Warning
Fire or explosion Hazard
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
-
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
Certified to/Certifié pour:
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
920-000c
Gas Fireplace
CSA 2.17-2017
ANSI Z21.88-2017
CSA 2.33-2017
Installer:
Please complete the details on the back cover and leave this
manual with the homeowner.
Homeowner:
Please keep these instructions for future reference.
Owners &
Installation Manual
MODEL: B36XTE-11
Medium DV Gas Fireplace
Bellavista B36XT Video
www.regency-fire.com
06.22.20
Advertisement
Table of Contents
Related Manuals for Regency Fireplace Products Bellavista B36XTE Series
Summary of Contents for Regency Fireplace Products Bellavista B36XTE Series
- Page 1 Bellavista ® B36XTE Owners & Installation Manual Gas Fireplace MODEL: B36XTE-11 Medium DV Gas Fireplace Bellavista B36XT Video www.regency-fire.com Warning Fire or explosion Hazard Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- Page 2 To the New Owner: Congratulations! You are the owner of a state-of-the-art Gas Fireplace by REGENCY . The Bellavista™ B36XTE has been designed to provide ® you with all the warmth and charm of a wood fireplace at the flick of a switch. The Bellavista™ B36XTE has been approved by Warnock Hersey/Intertek for both safety and efficiency.
- Page 3 MANUFACTURED MOBILE HOME REQUIREMENTS INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE This Regency ® product has been tested and listed by Intertek as a Direct Vent Wall Furnace to the following standards: to Vented Gas Fireplace Heaters ANSI Z21.88-2017 • CSA 2.33-2017 and Gas-fired Appliances for Use at High Altitudes CSA 2.17-2017. This Direct Vent System Appliance must be installed in accordance with the manufacturer's installation instructions and the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, or the current Standard of Fire Safety Criteria for Manufactured Home Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240-MH Mobile Home Standard in Canada.
-
Page 4: Table Of Contents
table of contents Owner's Information Two (2) 90 Elbows (Rigid Pipe 4" x 6 - 5/8") ....45 Horizontal Terminations ..........45 Copy of Safety Decal .............5 Three (3) 90 Elbows (Rigid Pipe 4" x 6 - 5/8") ....45 Unit Dimensions with Vignette ........6 Venting Arrangements For Vertical Terminations ..46 Unit Dimensions with Optional Flush Panels ....7 Vertical Terminations ..........47... -
Page 5: Copy Of Safety Decal
safety decal This is a copy of the label that accompanies each Bellavista™ B36XTE Direct Vent Gas Fireplace. We have printed a copy of the contents here for your review. NOTE: Regency ® units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. Copy of Safety Decal Duplicate S/N Listed/Nom: VENTED GAS FIREPLACE / FOYER AU GAZ À... -
Page 6: Unit Dimensions With Vignette
dimensions Unit Dimensions with Vignette & Vignette Finishing Trim 40-3/8" (1025mm) 36" (914mm) 33-1/16" (838mm) Vignette Finishing Trim 16 " 4 " (567mm) (959mm) 8 " (48mm) 4 Sided Vignette Trim 3 Sided Vignette Trim Front view : shown with 3 sided finishing trim. ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY. -
Page 7: Unit Dimensions With Optional Flush Panels
dimensions Unit Dimensions with Optional Flush Panels and Safety Screen 3-sided finishing trim not shown: 40-1/2" wide x 35-3/4" high Bellavista B36XTE-11 Gas Fireplace | ®... -
Page 8: Important Message
owner's information Important Message 3. See general construction and assembly in- YOUNG CHILDREN SHOULD BE CARE- structions. The appliance and vent should be SAVE THESE FULLY SUPERVISED WHEN THEY ARE enclosed. INSTRUCTIONS IN THE SAME AREA AS THE APPLI- 4. This appliance must be connected to the speci- ANCE. -
Page 9: Lighting Procedure
owner's information Lighting Procedure IMPORTANT: The remote control system supplied with this appliance has 3. After approximately 4 seconds the spark ignition system will spark for 60 several options for starting/operating the appliance using the power button seconds to light the pilot. and ON/OFF key on the hand held transmitter. -
Page 10: Copy Of Lighting Plate Instructions
owner's information Copy of Lighting Plate Instructions FOR YOUR SAFETY READ BEFORE LIGHTING This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1. WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 11: Proflame I Remote Control Operating Instructions
owner's information PROFLAME I REMOTE CONTROL OPERATING INSTRUCTIONS Proflame I Remote Control Operating Instructions IMPORTANT:The Proflame Transmitter 1 is an integrated part of the TECHNICAL DATA Proflame 1 System, which consists of these elements: • Proflame 1 Transmitter, to be used in conjunction with: REMOTE CONTROL •... - Page 12 owner's information Temperature indication Display Remote‑Flame Control With the system in the "OFF" position, press the Thermostat Key and The Proflame has six (6) flame levels. With the system on, and the flame the Mode Key at the same time. Look at the LCD screen on the transmit- level at the maximum in the appliance, pressing the Down Arrow Key ter to verify that a C or F is visible to the right of the room temperature once will reduce the flame height by one step until the flame is turned off.
- Page 13 owner's information Smart Thermostat (Transmitter Operation) Remote dimmer control (Light)** The auxiliary function controls the AUX power outlet by the dimmable The Smart Thermostat function adjusts the flame height in accordance light control. To activate this function use the Mode Key (fig. 1) to index to the difference between the set point temperature and the actual room to the AUX icon (fig.
- Page 14 owner's information LOW BATTERY POWER DETECTION Transmitter The life span of the remote control batteries depends on various factors: quality of the batteries used, the number of ignitions of the appliance, the number of changes to the room thermostat set point, etc. When the Transmitter batteries are low, a Battery Icon will appear on the LCD display of the Transmitter (Fig.
- Page 15 requirements MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:...
-
Page 16: Installation Checklist
installer's information This includes: Installation Checklist 4. This appliance is Listed for bedroom instal- lations using the standard Remote (millivolt 1. Clocking the appliance to ensure the correct thermostat system). Some areas may have 1. Locate appliance: firing rate (rate noted on label 31,000 Btu/h, further requirements, check local codes a) Room location (Refer to "Locating Your after burning appliance for 15 minutes. - Page 17 installation Clearances The clearances listed below are Minimum distances unless otherwise stated: A major cause of chimney related fires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance that this fireplace and vent system be installed only in accordance with these instructions. WARNING Caution Requirements Fire hazard is an extreme risk...
- Page 18 installation Combustible Mantel Clearances Because of the extreme heat this fireplace emits, the mantel clearances are critical. Combustible mantel clearances from top of unit are shown in the diagram below. Note: Mantel starts at *1" deep and ends at *12" deep. **For Vignette with Vignette Finishing Trim flush finish, all materials (framing & finishing) below must be non-combustible if a lower mantel is desired.
-
Page 19: Mantel Leg Clearances
installation Mantel Leg Clearances 12” Side Wall (Measured from side of Fireplace Opening) 3.5” 6.5" Allowable mantel leg projection. Framing 1. Determine the total thickness of facing material (e.g. non combustible plus ceramic tiles) to allow the finished surface to be flush with the front of the unit. -
Page 20: Framing With Vignette + Vignette Trim (Stepped Finish)
installation + Vignette Trim (Stepped Finish) Framing with Vignette or with Flush Panels and Safety Screen - see next page for framing for vignette and vignette trim (flush finish) Framing Dimensions Description B36XTE Framing Width 40-5/8"(1032mm) Framing Height 42" (1067mm) O (Rear Vent) Framing Depth - Rear Vent 20-3/4"... -
Page 21: Framing With Vignette + Vignette Trim (Flush Finish)
installation Framing with Vignette and Vignette Trim (Flush Finish) Framing Dimensions Description B36XTE Framing Width 42-1/4"(1073mm) Framing Height 42" (1067mm) O (Rear Vent) Framing Depth - Rear Vent 22-1/8" (559mm) O (Top Vent) Framing Depth - Top Vent 21-7/8" (553 mm) P (Top Vent) Corner Facing Wall Width 51 - 5/16"... -
Page 22: Non- Combustible Requirements
installation Non- Combustible Requirements Vignette +Vignette Trim (Stepped Finish) or with Flush Vignette + Vignette Finishing Trim (Flush Finish) Panels and Safety Screen Diagram 1 Diagram 2 | Bellavista B36XTE-11 Gas Fireplace ®... -
Page 23: Wall Mount On / Off Switch And Remote Receiver Installation
installation Wall Mount On / Off Switch and Remote Receiver Installation Required for all installations - including Proflame remote controls IMPORTANT INSTALLATION NOTE: The Receiver must be placed inside the supplied (Low Voltage) junction type wall box and installed into the wall only. DO NOT INSTALL WITHIN THE CONFINES OF THE FIREPLACE. -
Page 24: Finishing
installation Finishing IMPORTANT FINISHING DETAIL NOTE: Before placing unit into final position - it is important to know the total Non-combustible thickness / height of finished hearth (tile, carpet, etc.) The base of the Material fireplace should be level or higher than the finished hearth height. J-style Trim or metal corner bead may be used to finish these... -
Page 25: Top Facing Support
Nail4.eps Top Facing Support Screw holes is reversed for Side installation for “C” hole position Nailing Strip Top Facing Support is reversed for “C” hole position Top Facing Support (if not using Vignette Finishing Trim) Side Nailing Strips Determine the total thickness of facing material (e.g. non combustible, drywall or wood plus The side nailing strips come attached to the unit. -
Page 26: Conversion To Top Vent
installation Conversion to Top Vent Note: This conversion must be done prior to the unit being placed in position. The unit comes equipped as a rear vent unit. These instructions are to be used, only if the unit is going to be top vented. Top Collar Assembly Kit Exhaust Assembly Intake Cover Plate... - Page 27 installation 5. From the outside rear of the firebox, remove the intake collar assembly. Remove the 4 - 1/4" x 1/2" screws. See Diagram 5. Diagram 9 Exhaust Assembly Intake Collar Assembly 9. From the outside top of the firebox, install the intake collar assembly. Secure with 4 - 1/4"...
-
Page 28: Vent Restrictor, Baffle & Heat Deflector Installation
installation Vent Restrictor, Baffle & Heat Deflector Installation Note: The vent restrictor & baffle must be installed prior to Optional Panel Installation. 1. Determine the venting configuration. 2. Remove top heat deflector and baffle plate (reverse of steps 5 & 6). 3. -
Page 29: Exterior Vent Termination Requirements
installation Exterior Vent Termination Requirements Minimum Clearance Requirements Canada Clearance above grade, veranda, porch, deck, or balcony 12"(30cm) 12"(30cm) Clearance to window or door that may be opened 12"(30cm) 9" (23cm) Clearance to permanently closed window Vertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2 feet (61cm) 24"(60cm) 24"(60cm) from the center line of the terminal (check with the local code) -
Page 30: Top Vent Reducer Installation -5"X 8" To 4"X 6-5/8
installation B36XTE/B36XTCE Top Vent Reducer Installation from 5" x 8" to 4" x 6-5/8" TOP VENT REDUCER INSTALLATION—FROM 5" X 8" TO 4' X 6-5/8" tooltip 1. Apply a bead of Millpack around the base of the inner vent collar. Slide the 2. -
Page 31: Venting - Direct Vent System (Flex)
installation Venting Direct Vent System (Flex) HORIZONTAL TERMINATIONS ONLY These venting systems, in combination with the B36XTE Direct Vent Gas Fireplace, have been tested and listed as a direct vent heater system by Warnock Hersey. The location of the termination cap must conform to the requirements in the Vent Terminal Locations diagram in the "Exterior Vent Termination Loca- tions"... - Page 32 installation VERTICAL TERMINATION 4" X 6-7/8" VENTING - VERTICAL FLEX VENT KIT (946-755) 1. Maintain the 1-½” clearance (air space) to combustibles when passing 11. Secure inner fl ex pipe to pipe adaptor by using Mill-Pac over the adaptor. through ceilings, walls, fl oors, enclosures, attic rafters or other nearby Slide the inner pipe over adaptor and secure with 3 screws.
-
Page 33: Vertical Flue Extension Kit (Part #946-756)
installation Vertical Flue Extension Kit (Part #946-756) VERTICAL FLUE EXTENSION KIT (PART # 946-756) CEILING FIRESTOP/FIRESTOP SPACER 20 foot Flex pipe Extension ( PART # 946-757) -1/4 (Used in conjunction with the 946-755 Vertical Flex kit and 948-367/P flex 4" (100mm) inner pipe to flex adaptor). -
Page 34: 4" X 6-5/8" Rigid Pipe Cross Reference Chart Only
installation 4" x 6-5/8" Rigid Pipe Cross Reference Chart Only 4" X 6-5/8" RIGID PIPE CROSS REFERENCE CHART Components from different Manufacturers may not be mixed. Not all Rigid Pipe components are available directly from FPI. Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Note: The listed manufacturers may have other lengths not shown on this chart, which would also be approved. - Page 35 installation Description *Selkirk *American Metal *Security *ICC Excel *Olympia Simpson *Metal-Fab™ Ventis DV* Direct Temp™ Secure- Vent® Direct ® Products® Direct Vent Pro Sure Seal Amerivent Direct Attic Insulation Shield 12" 46DVA-IS 4DAIS12 SV4RSA VDV-AIS04 Attic Insulation Shield 46DVA-KHA 4DAIS12 TM-4AS - Cold Climates 36"...
-
Page 36: 5" X 8" Rigid Pipe Cross Reference Chart Only
installation 5" x 8" Rigid Pipe Cross Reference Chart Only Components from different Manufacturers may not be mixed. Not all Rigid Pipe components are available directly from FPI. 5" X 8" RIGID PIPE CROSS REFERENCE CHART Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Note: The listed manufacturers may have other lengths not shown on this chart, which would also be approved. - Page 37 installation Description *Selkirk *ICC Excel *Olympia Simpson *Metal-Fab™ Ventis DV* Direct Temp™ Direct Direct Vent Pro ® Sure Seal Attic Insulation Shield 12" 58DVA-IS* VDV-AIS05 Basic Horizontal Termination Kit (A ) 5DT-HKA TM-5HTK VDV-KW05 Horizontal Termination Kit (B) 58DVA-KHA 5DT-HKB TM-5HTK VDV-K05 Vertical Termination Kit...
-
Page 38: Rigid Pipe 5" X 8
installation B36X/XT Horizontal Terminations HORIZONTAL 5” X 8” RIGID REAR VENT KIT AstroCap XL & Rigid Rear Vent Kit for Corner Installations Rigid Pipe 5" x 8" - when using Vignette Finishing Trim (see next page) FOR CORNER INSTALLATIONS Designed for a minimum vent configuration when using a rear vent application with a horizontal termination in a corner installation. -
Page 39: Horizontal 5" X 8" Rigid Rear Vent Kit
installation Horizontal 5” x 8” Rigid Rear Vent Kit AstroCap XL & Rigid Rear Vent Kit for Corner Installations Rigid Pipe 5" x 8" - when Installed with Vignette and Vignette Finishing Trim - Finished Flush Designed for a minimum vent configuration when using a rear vent application with a horizontal termination in a corner installation. -
Page 40: Venting Arrangements For Horizontal Terminations
installation Venting Arrangements for horizontal terminations Flex Vent or rigid pipe 5" x 8" The Diagrams show all allowable combinations of vent runs with 5" x 8" venting using the Regency direct vent system or rigid vent system. A vent guard should be used whenever the termination is lower than the specified minimum or as per local codes. For horizontal terminations the Regency Direct Vent Flex System may be used for installations with a maximum continuous vent maximum horizontal length of 3ft (0.9m). -
Page 41: Horizontal Terminations
installation Horizontal Terminations Flex Vent 5" x 8" These venting systems, in combination with the B36XTE Direct Vent Gas Fireplace, has been tested and listed as a direct vent heater system by Intertek. The location of the termination cap must conform to the requirements in the Vent Terminal Locations Diagram in "Exterior Vent Termination Locations" section. Regency Direct Vent (Flex) System 4 foot Termination Kit (Part# 946-615) includes all the parts needed to install the B36XTE with a either a top or ®... -
Page 42: Rigid Pipe 5" X 8
installation Horizontal Terminations RIGID PIPE 5" x 8" Vinyl Siding Standoff (Optional) Horizontal Termination Wall Thimble Pipe Length 90 Elbow Pipe Length Rigid Pipe Adaptor Rigid Pipe Adaptor Horizontal Termination Top Vent - No Vertical Rise • When venting with a 90° elbow directly off the unit, must use 5"... -
Page 43: Venting Arrangements For Horizontal Terminations
installation Venting Arrangements for Horizontal Terminations Rigid Pipe 4" x 6-5/8" (must use Reducer Part # 946-606 & 770-994 Rigid Pipe Adaptor) The diagram shows all allowable combinations of vertical runs with horizontal terminations, using one 90 two 45 elbows equal one 90 elbow). -
Page 44: Horizontal Or Vertical Rigid Pipe 4" X 6-5/8
The Regency AstroCap and Regency Riser Vent terminal are certified for installations using Regency venting systems as well as any specific chimney systems listed in this manual. AstroCap is a proprietary trademark of Regency Fireplace Products. | Bellavista B36XTE-11 Gas Fireplace... -
Page 45: Horizontal Terminations
installation Horizontal Terminations Two (2) 90 Elbows (Rigid Pipe 4" x 6 - 5/8") One 90 elbow = Two 45 elbows. Option H + H1 W i t h t h e s e o p t i o n s , 0' Min. -
Page 46: Venting Arrangements For Vertical Terminations
installation Venting Arrangements For Vertical Terminations Rigid Pipe 4" x 6-5/8" (must use Reducer Part # 946-606 & 770-994 Rigid Pipe Adaptor) The shaded area in the Diagram shows all allowable combinations of straight vertical and offset to vertical terminations, using two 90 elbows, with Rigid Pipe Venting Systems for Propane and Natural Gas. -
Page 47: Vertical Terminations
installation Vertical Terminations Three (3) 90 Elbows (Rigid Pipe 4" x 6 - 5/8") One 90 elbow = Two 45 elbows. Option H + H1 V + V1 With these options, max. 0' Min. 2' Max. 2' Min. total pipe length is 30 feet 1' Min. -
Page 48: Venting Arrangements - Co-Linear Flex System
installation Venting Arrangements With Co-Linear Flex System Masonry chimneys may take various contours which the flexible liner will accommodate. However, keep the THE APPLIANCE MUST NOT BE flexible liner as straight as possible, avoid unnecessary bending. CONNECTED TO A CHIMNEY FLUE SERVING A SEPARATE SOLID FUEL The Air Intake pipe must be attached to the inlet air collar of the termination cap. -
Page 49: Vertical Terminations
installation Vertical Terminations Co-linear Flex System Into Masonry Fireplaces FOR BOTH RESIDENTIAL & MANUFACTURED HOMES The shaded area in the Diagrams show the allowable vertical terminations. Bellavista B36XTE-11 Gas Fireplace | ®... -
Page 50: Unit Installation With Horizontal Termination
installation Unit Installation with Horizontal 5. Assemble the desired combination of pipe 7. Ensure that the pipe clearances to combus- and elbows to the appliance adaptor and tible materials are maintained (Diagram 5). Termination twist-lock for a solid connection. Install the termination cap. 4"... -
Page 51: Horizontal Termination - 5" X 8" Venting
installation Unit Installation with Horizontal NOTE: Horizontal sections must be sup- ASTROCAPXL ported at intervals not exceeding Termination DIMENSIONS (946-623/P) 3 feet (0.9 meter). (Flame picture 5" X 8" VENTING and performance will be affected (Flex Vent Systems) by sags in the liner). Minimum Vent Clearances 4. -
Page 52: Unit Installation With Vertical Termination
installation Unit Installation with Vertical nections are in the fully twist-locked position and sealed. Termination 5. Cut a hole in the roof centered on the small 4" X 6-5/8" VENTING drilled hole placed in the roof in Step 2. The (Rigid Vent Systems) hole should be of sufficient size to meet the minimum requirements for clearance... -
Page 53: Pilot Adjustment
installation Gas Pipe Pressure Testing Pilot Adjustment B36XTE - NG11 System Data The appliance must be isolated from the gas Periodically check the pilot flames. Correct Conversion Kit # 576-969 supply piping system by closing its individual flame pattern has two strong blue flames: manual shut-off valve during any pressure 1 flowing around the flame sensor and 1 For 0 to 4500 feet altitude... -
Page 54: Conversion Kit #578-977 From Ng To Lp
installation B36XTCE/ B36XTE-11 Conversion Kit #578-977 from NG to LP for B36XTE using SIT 885 NOVA Gas Valve THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! 6. Remove the pilot shield by removing 2 9. -
Page 55: Brick Panel Installation
B36X/XT installation BRICK PANEL INSTALLATION Brick Panel Installation Dangerous operating conditions may occur if the panels are broken. Handle with care. DO NOT FORCE INTO POSITION. 1) Unwrap the Brick Panels from the protective wrapping. 2) Ensure that the logs are not in the unit. Top Panel Back Panel Left Panel... -
Page 56: Optional Enamel Panel Installation
B36X / XT installation Optional Enamel Panel Installation BLACK ENAMEL PANEL INSTALLATION Black Enamel Panels • Black Enamel panels must be inspected for scratches and dimples prior to installation. All claims to be recorded at this time. Claims for damage after installation will not receive consideration. •... -
Page 57: Log Set Installation
installation B36XT Log Set Installation LOG SET INSTALLATION Installation of Optional Panels must be completed before installing the log set. Read the instructions below carefully and refer to the images. If the 2) Spread vermiculite along the base of the fi rebox. logs are broken do not use the unit until they are replaced. - Page 58 B36XT installation 6) Position Log D with the fl at side toward Log E. 5) Place Log A on the front right side of the burner. Position the notch Fit Log D into right peg on Log E. on the bottom right side of the log into the right side of the grate. Slide Log A back towards Log E until the fl...
- Page 59 B36XT installation 8) Place the lava rocks on the front of the burner tray in the places shown in the photo. Separate platinum embers and place on the front of the burner tray in and around the lava rocks. Avoid stacking platinum embers. Platinum embers may be placed over burner ports.
-
Page 60: Aeration Adjustment
installation Aeration Adjustment The burner aeration is factory set but may need CAUTION: Carbon will be produced if air adjusting due to either the local gas supply or shutter is tightly closed. altitude. Open the air shutter for a blue flame or close for a more yellow flame. -
Page 61: Optional Fan Installation
B41XTCE / B41XTE installation Optional Fan Installation FAN INSTALLATION Important: 120 Volt AC power is needed for the blower. The 6. Position the fan base with the motor end towards the rear of the receptacle box will be installed on the left hand side of the unit and firebox and then slide the fan in towards the rear of the unit. - Page 62 B41XTCE / B41XTE installation FAN INSTALLATION 9. Slide the thermodisc/cover assembly onto the bracket clip on the 11. Plug in the fan power cord to the Fan Control Module into the outlet left underside of the firebox. Ensure that no wires will touch hot marked “Fan”.
-
Page 63: Wiring Diagram With Optional Fan
installation Wiring Diagram with Optional Fan SureFire™ Switch 0.584.622 Caution: Ensure that the wires do not touch any hot surfaces and are away from sharp edges. CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. -
Page 64: Optional Wall Thermostat Installation
installation Optional Wall Thermostat Installation A wall thermostat may be installed if desired. 4) Connect the other thermostat lead to male connector disconnected from Step 1 using a female spade connector - see picture below. Recommended: Wall Thermostat should be mounted beside the Remote/Unit Receiver which comes standard with the appliance. -
Page 65: Flush Glass Door Installation
installation Flush Glass Door Installation 1) Line up slots on flush glass door with tabs in firebox. Hook slots on to tabs and lower door slowly (See Diagram 1). Tabs in Firebox Diagram 1 2) Lower the flush door, then hook the 2 adjustable tension latches - close the latches to secure the flush door(See Diagram 2). Adjustable Tension Latch location Diagram 2... -
Page 66: Vignette Frame And Safety Screen Installation
installation Vignette Frame and Safety Screen Installation B36XTE/B41XTE Black Chrome Handling Instructions All hand and finger marks MUST be cleaned off with a soft cloth. Use an ammonia based cleaner (ie. glass cleaner) to remove any finger prints before applying heat to the unit. Use supplied gloves when installing Black Chrome Faceplates. Failure to do this will result in burn stains on panels which you will be unable to remove. -
Page 67: Optional Vignette Inlay Installation
installation OPTIONAL VIGNETTE INLAY Optional Vignette Inlay Installation NOTE: Inlay not exactly as shown below. 1. Remove Inner Vignette Frame from unit if already installed. 5. Secure the Inlay in position with supplied brackets, washers, and nuts as shown. 2. Line up the inlay top bracket in the space between the safety screen frame and Vignette Frame. -
Page 68: Optional Vignette Finishing Trim Installation
installation B36XTE-10 Optional Vignette Finishing Trim Installation B36XTE -VIGNETTE FINISHING TRIM *If finishing the unit with the Vignette Finishing Trim - remove top nailing strip from unit if installed–use nailing strip supplied with top trim piece. Side nailing strips are bent around side trim piece in flush finish application. NOTE: Remove the safety screen, Vignette Faceplate Install the lower finishing trim (if required)–secure with four... -
Page 69: Premium Flush Front Installation
installation B36XTE-10 Premium Flush Front Installation - must be used with Safety Screen Part #578-929 FLUSH PANEL INSTALLATION- MUST BE USED WITH SAFETY SCREEN PART #578-929 To install the top and bottom Flush Panels: 5. Install the bottom panel to complete the installation. 1. -
Page 70: Safety Screen Installation
installation B36XTE Safety Screen Installation - must be used with Premium Flush Front SAFETY SCREEN INSTALLATION - MUST BE USED WITH OPTIONAL PREMIUM FRONT 1. Hook the safety screen frame onto brackets within the unit in locations shown below. 2. Gently lower screen on to glass door frame–two (2) magnets located on inside lower part of the screen frame will secure the screen to the glass door frame. 3. To remove–reverse steps. Magnet locations 07.23.15 919-590 B36XTe / B41XTe B36XTE Optional 3 Sided Finishing Trim Installation SAFETY SCREEN INSTALLATION - MUST BE USED WITH OPTIONAL PREMIUM FRONT OPTIONAL fINIshINg TrIm INsTALLATION... -
Page 71: Operating Instructions
operating instructions Operating Normal Operating Instructions Sounds of Gas Appliances 1. Read and understand these instructions before operating this appliance. It is possible that you will hear some sounds from your gas appliance. This is perfectly normal due to 2. Check to see that all wiring is correct and the fact that there are various gauges and types enclosed to prevent possible shock. -
Page 72: Lighting Procedure
operating instructions Lighting Procedure IMPORTANT: The remote control system supplied with this appliance has several options for starting/operating the appliance using the power button 3. After approximately 4 seconds the spark ignition system will spark for 60 and ON/OFF key on the hand held transmitter. seconds to light the pilot. -
Page 73: Copy Of Lighting Plate Instructions
operating instructions Copy of Lighting Plate Instructions FOR YOUR SAFETY READ BEFORE LIGHTING This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1. WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 74: Maintenance Instructions
maintenance Maintenance Instructions Door Glass 3. Check for evidences of excessive condensation, such as water droplets forming in the inner liner, and subsequently dripping out the joints, Your Regency fireplace is supplied with high ® 1. Always turn off the gas valve before cleaning. Continuous condensation can cause corrosion temperature 5mm-Ceramic glass. -
Page 75: Removing Valve
maintenance Removing Valve 8. Disconnect the inlet gas line. 9. Disconnect the EV1, EV2, and ground wires 1. Shut off the gas and electrical supply. from the valve - as shown below. 2. Remove the safety screen and/or Flush Panels. 3. -
Page 76: Main Assembly
parts list Main Assembly Part # Description Part # Description 576-084F Top Insulation Plate 578-917 Fan Assembly 576-099 Top Insulation 910-215/P Fan Motor (120 Volts) 556-524 Flue Collar Outer Assembly 556-095 Flue Collar Gasket 911-159 Power Cord (120 Volts) 556-097 Exhaust Gasket 910-142 Thermodisc - Fan Auto... - Page 77 parts list Main Assembly FAN SWITCH ASSEMBLY Bellavista B36XTE-11 Gas Fireplace | ®...
-
Page 78: Burner Assembly
parts list Burner Assembly Part # Description Part # Description 576-077 Rear Log Tray 911-265 Ignition Board (DFC 0.584.622) 911-013 Wiring Harness -Switch 576-525 B36XTE Burner Assembly NG/LP 911-018 Battery Holder 576-057 B36XTE Grate Assembly 911-037 Flame Sensor 911-038 Flame Electrode 904-644 Orifice # 35 NG 911-039... -
Page 79: Optional Accessories
parts list Optional Accessories Part # Description 576-916 Flush Panels 578-929 Safety Screen (for use with flush panels only) 578-928 Vignette Trim 578-918 Vignette Inlay Chrome 578-919 Vignette Inlay Black 578-920 Vignette Inlay Sunset 578-917 Fan Assembly Complete 578-922 Vignette Front Platinum 578-923 Vignette Front Black Chrome 578-924... -
Page 80: Warranty
warranty Limited Lifetime Warranty FPI Fireplace Products International Ltd. (for Canadian customers) and Fireplace Products U.S., Inc. (for U.S. customers) (collectively referred to herein as “FPI”) extends this Limited Lifetime Warranty to the original purchaser of this appliance provided the product remains in the original place of installation. The items covered by this limited warranty and the period of such coverage is set forth in the table below. - Page 81 warranty At all times FPI reserves the right to inspect reported complaints on location in the field claimed to be defective prior to processing or authorizing of any claim. Failure to allow this upon request will void the warranty. All warranty claims must be submitted by the dealer servicing the claim, including a copy of the Bill of Sale (proof of purchase by you).
- Page 82 warranty Limitations of Liability: The original purchaser’s exclusive remedy under this warranty, and FPI’s sole obligation under this warranty, express or implied, in contract or in tort, shall be limited to replacement, repair, or refund, as outlined above. IN NO EVENT WILL FPI BE LIABLE UNDER THIS WARRANTY FOR ANY INCIDENTAL OR CONSEQUENTIAL COMMERCIAL DAMAGES OR DAMAGES TO PROPERTY.
- Page 83 warranty Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 85 notes Bellavista B36XTE-11 Gas Fireplace | ®...
- Page 86 notes | Bellavista B36XTE-11 Gas Fireplace ®...
- Page 88 Installer: Please complete the following information Dealer Name & Address: ________________________________________ _____________________________________________________________ Installer: _____________________________________________________ Phone #: _____________________________________________________ Date Installed: ________________________________________________ Serial #: ______________________________________________________ Bellavista B36XT Video Printed in Canada Regency , Bellavista ,Surefire™, and AstroCap™ are trademarks of FPI Fireplace Products International Ltd. ®...
