VFD parameter settings - Danfoss CDS-803 Drive

Figure 17 CDS-803 Drive P/N 101-260-230 or 460-VFD (22 kW Ultra units)

Menu ID
3.** Reference / Ramps
3.0* Reference Limits
3-02 Minimum Reference
3.4* Ramp 1
3-41 Ramp 1 Ramp Up Time
3-42 Ramp1 Ramp Down Time
4.** Limits / Alarms
4.1* Motor Limits
4-18 Current Limit
5.** Digital In/Out
5.1* Digital Inputs
5-12 Terminal 27 Digital Input
VFDs built after 7/2017 - last 3 digits of serial number indicate the month and year of manufacture: *******468, 46th week of 2018.
5-12 Terminal 27 Digital Input
VFDs built before 7/2017 - last 3 digits of serial number indicate the month and year of manufacture: *******047, 4th week of 2017.
5.4* Relays
5-40 Function Relay
8.** Comm. And Options
8.3* FC Port Settings
8-30 Protocol
8-31 Address
8-32 Baud Rate
8-33 Parity / Stop Bits
28.** Compressor Functions
28.0* Short Cycle Protection
28-00 Short cycle protection
28.1* Oil Return Management
28-10 Oil Return Management
28-11 Low Speed Running Time
28-12 Fixed Boost Interval
28-13 Boost Duration
Description
30 Hz
120s
300s
110%
[0] No operation
[2] Coast Inverse
[0] [9] Alarm
[1] [5] Drive Running
Modbus RTU
19
19,200
No Parity / 1 Stop Bit
[0] Disable
[1] On
60 min (Minutes)
1 H (Hour)
60 s (Seconds)
77
(22 kW Ultra units)
Setting
gForce Ultra IOM
