C8051T620/2-DK
5.5. Programming Utilities
The Silicon Labs IDE is the primary tool for downloading firmware to the MCU during development. There are two
software programming tools that are intended for use during prototyping or in the field: the MCU Production
Programmer and the Flash Programming Utilities. The MCU Production Programmer is installed with the IDE to the
directory, C:\Silabs\MCU\Utilities\Production Programmer\ (default). The Flash Programming Utilities can be
optionally installed from the web installer, and are installed to C:\Silabs\MCU\Utilities\FLASH Programming\
(default).
5.6. ToolStick Terminal
The onboard debug circuitry provides both an in-system programming and debugging interface and a
communications interface to the target microcontroller's UART. The ToolStick Terminal software can access the
debug hardware's communications path and provides a terminal-like interface on the PC. Note that for concurrent
debugging and UART communications, the CP2103 USB-to-UART bridge is also included onboard.
In addition to the standard terminal functions (Send File, Receive File, Change Baud Rate), two GPIO pins on the
target microcontroller can be controlled using the terminal for either RTS/CTS handshaking or software-
configurable purposes. The ToolStick Terminal software is available on the downloads webpage:
www.silabs.com/
mcudownloads.
Rev. 0.5
7
