C8051T620/2-DK
12
SILICON LABS
www.silabs.com
P3
Figure 8. C8051T320 QFP32 Socket Daughter Board
SILICON LABS
www.silabs.com
P3
Figure 9. C8051T321 QFN28 Socket Daughter Board
SILICON LABS
www.silabs.com
P3
Figure 10. C8051T326 QFN28 Socket Daughter Board
C8051T320 QFP32 SKT DB
J2
J1
C8051T321 QFN28 SKT DB
J2
J1
C8051T326 QFN28 SKT DB
J3
J1
J2
