7.3 Wiring with mo.button
red
yellow
turn left
horn
ground point
mo.button - black
to left ground point
mo.button
white
turn right
mo.button - green
to mo.unit input KILL
lights
brake switch
ground point
purple
blue
starter
instrument menue
(optional)
from battery minus
to right ground point
ground wire
(optional)
orange
