Summary of Contents for motogadget mo.switch basic
- Page 1 V1.0...
- Page 2 SUITABLE TO SWITCH LOADS DIRECTLY. LOADS MUST BE SWIT- CHED BY A ELECTRONIC SWITCHING MODULE (i.e. MO.UNIT). Thank you very mutch for pruchasing a high quality motogadget product - Made in Germany. Please read the following information and recommendations thoroughly and follow these in- structions during installations and use of the product.
-
Page 3: Exclusion Of Liability
In this regard, we refer to our General Terms of Business and Delivery, which are published at www.motogadget.com. Should a return of the received delivery be agreed, please note that we only take back goods in their original packaging. The mo.switch and its accessories must be returned within the legal period of time and without any traces of use. -
Page 4: Safety Instructions
3. Safety Instructions • THE VEHICLE BATTERY MUST BE COMPLETELY DISCONNECTED PRIOR TO ANY WORK ON THE VEHICLE’S ELECTRICAL SYSTEM. FIRST, DISCONNECT THE NEGA- TIVE TERMINAL AND THEN THE POSITIVE TERMINAL. FOR RECONNECTION PROCEED IN THE REVERSE ORDER • USING THE MO.SWITCH WITH PLUS POLE CONNECTED TO VEHICLE FRAME (OLDER ENGLISH MOTORCYCLES) IS NOT POSSIBLE. - Page 5 . mo.switch combinations 4 push buttons - kickstarter & no instrument horn lights turn left turn right 5 push buttons - kickstarter & instrument or E-starter & no instrument light horn starter or instrument turn left / right 6 push buttons - E-starter & instrument horn light turn left / right...
- Page 6 . Setup housing ringlet push buttons push button plate screw chopper disc adapter sleve 22mm to 1inch ground terminal tapered screw for ground connetion housing clamping screw fixing screw button plate...
- Page 7 6. Wiring Mount all handlebar attachments and finalize their position. Clamp mo.switch housing to handlebar. Drill 4 holes with 5mm diameter into the handlebar. Deburr the holes inside and outside carefully.
- Page 8 . Wiring 7.1 Ground connection to handlebar With an ohmmeter, the resistance between battery negative pole and the handlebar surface is measured. If the resistance is higher than 3 ohms, a separate ground wire must be routed from the negative battery terminal to one of the mo.switch housing ground points. Handlebars that are not made of metal, e.g.
-
Page 9: Standard Wiring
HORN purple mo.unit input TURNL ground wire 9 pol. motogadget wire white mo.unit input TURN R (optional) article no. 9003061 brown mo.unit input BRAKE blue mo.unit input... - Page 10 7.3 Wiring with mo.button horn lights brake switch orange ground point ground point purple mo.button - black to left ground point mo.button white yellow blue starter instrument menue turn left turn right (optional) from battery minus to right ground point mo.button - green ground wire to mo.unit input KILL...
- Page 11 7.4 Using the delivered cable connection sleeves remove 4mm of wire insulation and push both wire ends into sleeve crimp both sides of sleeve with crimping tool place the heat shrink tube to sleeve center and shrink the tube...
