Instruction manual mo.stop
DEVICE HOUSINGS AND ALL OTHER DELIVERED PARTS MUST NOT BE OPENED OR DISMANTLED. IN CASE OF
NON-COMPLIANCE ALL GUARANTEE CLAIMS BECOME INVALID. MOTOGADGET ACCEPTS NO LIABILITY FOR
DIRECT OR INDIRECT DAMAGE OR SUBSEQUENT DAMAGE OF ANY KIND RESULTING FROM THE USE,
INSTALLATION OR CONNECTION OF THE MO.STOP OR OTHER DELIVERED EQUIPMENT. THIS EXCLUSION OF
LIABILITY PARTICULARLY INCLUDES DAMAGE TO PERSONS, MATERIAL LOSSES AND FINANCIAL DAMAGES.
THE USE OF THE DEVICE IN AREAS OF PUBLIC TRAFFIC IS UNDERTAKEN AT THE USER'S OWN RISK.
Application area
The mo.stop is a electronic switch. The device can only switch resistive loads like light bulbs or LED lamps up to a maximal
current of 7A. This maximum current is equivalent to 4 light bulbs with 21W (hazard warning lights). The device is not suitable
to switch capacitance loads (horn) or inductive loads (coils, relay). The ambient temperature must not below -20° (-4°F) and not
exceed +85° (185°F). If a LED lamp is used with modus 1 or modus 4; during the continuous illuminating phase might very
short dark phases (approx. 4 Milliseconds) be visible. These dark sections occur every second and are technical determined. At
setting modus 4 or 6 the device need after power down a break of 4 seconds to start the switching cycle again. If the break is to
short, the connected lamp will illuminate with the same switching pattern as it was switched off.
Power supply
The mo.stop can operate in a voltage range from 5,5V to 18V DC and is suitable for 6V and 12V vehicle power systems.
Operating the device without a battery, for example, using a direct connection to the vehicle's generator is not envisaged or
recommended. The device will not switch if used with a voltage below 5,5V. A voltage higher as 18V will destroy the device.
Also a short circuit (operate without a load) will destroy the device. Do not use the device if it is not working properly (lamps are
permanently switched on). Every type of LED tail-light has internally a different routing. If your LED tail-light is not working with
this connecting instruction, you will find help at support at www.motogadget.com.
Connection
Make sure you connect the mo.stop in the right polarity. Connect the red cable in direction +12V and the black cable in
direction earth. A short operation in reverse polarity (<5s) will not damage the mo.stop. In this case the connected lamp will
permanently illuminate. An operation longer than 5 seconds in reverse polarity will destroy the device. Please check the polarity
of the connection cables with a voltmeter before connection and operation.
If the device is used at a LED tail-light / brake-light unit the enclosed resistor has to be connected between brake-light input and
vehicle earth as shown below.
Attention! The minimal supply cable width is 0,75mm2. You must fuse the +12V power supply cable with
a max. 10A safety fuse. If the device will be use without fuse, damage at the connecting cable or the
mo.stop itself can cause a shortcut and a cable fire. There may be risk of your life! Make sure you are
capable to connect the device properly. If you are not sure, let the professional shop do the job!
Attachment
Please consider following recommendations for choosing the place of attachment:
•
water protected place
•
sufficient distance to hot engine or exhaust parts (max. ambient temperature in operation is 85°C)
•
a minimum distance of 30 cm to sources of electromagnetic interferences (ignition coils, high tension cables).
Important is a sufficient strain relief and bend protection of the connection cables. At mechanical stressed areas an
additional insulating is necessary to prevent damage at the cable insulation. It must no mechanical stresses and
strains act on the device (pull, push or shock forces). The device has to be attached direct at the cable loom with
plastic cable ties.
