Summary of Contents for motogadget mo.switch plain
- Page 1 Instruction manual mo.switch plain push-button unit V1.0...
- Page 2 SUITABLE TO SWITCH LOADS DIRECTLY. LOADS MUST BE SWIT- CHED BY A ELECTRONIC SWITCHING MODULE (i.e. MO.UNIT). Thank you very much for purchasing a high quality motogadget product - Made in Germany. Please read the following informations and recommendations thoroughly and follow these instructions during installation and use of the product.
- Page 3 In this regard, we refer to our General Terms of Business and Delivery, which are published at www.motogadget.com. Should a return of the received delivery be agreed, please note that we only take back goods in their original packaging. The mo.switch and its accessories must be returned within the legal period of time and without any traces of use.
-
Page 4: Safety Advice
3 Safety Advice • Before starting any work on the vehicle electrical system, the battery must be completely disconnected. To do this, fi rst the negative pole and then the positive pole are separated. When reconnecting, do it in reverse order. •... - Page 5 4 Setup rear side push-button version 3 push-buttons clamping screw front side rear side version 2 push-buttons push-buttons adapter sleeve 7/8 zoll (22,2mm) to 1 zoll...
-
Page 6: Installation
5 Installation Please note: One face on the front side is shorter to form a clamping gap. This side must face down. Stepp 1 of 3 Place both sides of the mo.switch onto the handlebar and slightly tighten the screws on the back so that the unit is not yet clamped. - Page 7 Stepp 2 of 3 Strip the connection wires and connect them to the push-buttons with the terminal screws. Make sure the terminal screws do not stand out too far, other- wise they can touch the handlebar and cause a short circuit. If necessary, shorten the clamping screws.
- Page 8 Stepp 3 of 3 Lead the wires through the hole into the handlebar and out through the central hole. Place the two sides of the mo.switch on the handlebar. Make sure the shorter face of the front side points downwards and no cables are squeezed between the handlebars and the housing.
- Page 9 Declaration of Conformity Hereby, motogadget GmbH declares the product is in compliance to EU directives. The full text of the EU Declaration of Conformity is available at the following internet address: https://manuals.motogadget.com/mo-switch-plain...
