INSTRUCTION MANUAL
Multi-spray gun
MSA-200
Important
This manual contains IMPORTANT WARNINGS and INSTRUCTIONS.
Equipment in this manual is exclusively for painting purposes.
Do not use for other purposes.
The operator shall be fully conversant with the requirements stated in this
instruction manual including important warnings, cautions and operation and
correct handling.
Read and understand the instruction manual, before use and retain for
reference.
Be sure to observe warnings and cautions in this instruction manual.
If not, it can cause paint ejection and serious bodily injury by drawing organic solvent.
Be sure to observe following
WARNING
Indicates a potentially hazardous situation which, if not avoided, may result in serious injury or loss of life.
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury or
CAUTION
property damage.
Indicates notes which we ask you to observe. The safety precautions in this instruction manual are the
Important
minimum necessary conditions. Follow national and local regulations regarding fire prevention, electricity and
safety as well as your own company regulations.
Important specifications
■
Max. Pressure
Noise level
Spray condition
Measuring point
※ Atomizing air pressure means air pressure at gun inlet when trigger is pulled and air flows．
Main specifications
■
Model
Max.
operating fluid
9.8
MSA-200
(98 / 1440)
※Fluid output ; See 4.Selection of nozzle tip according to kind of paint.
(Automatic type)
marked items which are especially important.
Fluid ； 9.8MPa / 98bar / 1440PSI
Air ； 0.7MPa / 7bar / 100PSI
69 dB(A)
Used Nozzle tip ; NT2004CMU
Atomizing air pressure ; 0.15MPa / 1.5bar / 21.4PSI ※
Fluid pressure ; 9.8MPa / 98bar / 1440PSI
Tested with water
1m backwards from gun, 1.6 m height
Pressure MPa (bar / PSI)
Operating Operating
fluid atomizing air
4.9 0.15
(49 / 720) (1.5 / 21.4)
This Anest-iwata multi-spray gun kit complies to ATEX
regulations 94/9/EC,
Protection level ：
Ⅱ2 G X，Suitable for use in Zones 1 and 2.
X marking ：
Any static electricity discharge from the multi-spray
gun is to be diverted to the grounded the
conductive fluid hose as stipulated.
Fluid output
ml/min
Piston
operating air
Refer to
0.44
4.Selection of nozzle tip
(4.4 / 63)
according to kind of paint
－９ －
Max. Temperature
Atmosphere
5℃～40℃
Air・Fluid 5℃～43℃
Filter Size Air & fluid
(mesh) connection
G 1/4(fluid)
#200
Φ 8/tubu (atomizing air）
Φ 6/tubu （piston air）
Mass
ｇ(lbs)
680
(1.43)
