Summary of Contents for Palmgren PALM9683295
- Page 1 9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 Operating Manual & Parts List 9683295 10˝ × 16˝ variable speed, 3-phase Band Saw Read carefully and follow all safety rules and operating instructions before first use of this product. 9645931.01-0620...
-
Page 2: Getting Started
• Arsenic and chromium from chemically treated lumber. The power supply to Palmgren Model 9683295 10˝ × 16˝ Band Saw needs to be 230 V AC, 3-phase, 6.2 A, 60 Hz. Your risk from these exposures varies, depending on how often you do this type of work. -
Page 3: Specifications
9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 Palmgren Operating Manual & Parts List 9683295 SAFETY RULES (CONTINUED) • Avoid unintentional starting. Be sure the machine is off when not in use and before attaching the machine to a power supply. TOOL SHOULD BE MAINTAINED •... -
Page 4: Installation
9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 Palmgren Operating Manual & Parts List 9683295 • The exact power source voltage, frequency and number of phase ASSEMBLY shall be checked according to this manual and specifications. WARNING: Do not disconnect grounding terminal before CONTROL BOX ARM disconnecting power source. -
Page 5: Operation
9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 Palmgren Operating Manual & Parts List 9683295 NOTE: OPERATION • When standard wall pipe or tubing or thin wall tubing, channel iron, angles I-beams are cut, a 10 pitch saw blade of “wave” set • In the event of incorrect operation or dangerous conditions, the type is frequently used to good advantage. -
Page 6: Removing And Installing The Blade
9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 Palmgren Operating Manual & Parts List 9683295 OPERATION (CONTINUED) STARTING AND STOPPING THE MACHINE Refer to Figure 5. REMOVING AND INSTALLING THE BLADE The saw bow must be in the raised position before starting the When your machine was shipped, a blade was supplied and machine. -
Page 7: Adjusting Blade Guide Brackets
9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 Palmgren Operating Manual & Parts List 9683295 OPERATION (CONTINUED) OPERATING VISE Refer to Figures 10 and 11. ADJUSTING BLADE GUIDE BRACKETS The workpiece is placed between the vise jaws with the required Refer to Figure 7. amount to be cut-off extending out past the blade. To position the The blade guides should be set as close to the vise jaws as possible. -
Page 8: Setting Up The Machine For Operation
9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 Palmgren Operating Manual & Parts List 9683295 OPERATION (CONTINUED) CHANGING SPEEDS Your machine is provided with a range of speeds, 80 to 250 SFPM. To SETTING UP THE MACHINE FOR OPERATION change speeds, proceed as follows: Refer to Figure 12. -
Page 9: Blade Selection Guide
9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 Palmgren Operating Manual & Parts List 9683295 OPERATION (CONTINUED) BLADE SELECTION GUIDE TEETH PITCH AND RAKE TEETH SET Saw teeth are slightly bent out of the plane of the saw body, resulting in a wide cut in the workpiece. This parameter is called “tooth set.”... -
Page 10: Troubleshooting
9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 Palmgren Operating Manual & Parts List 9683295 TROUBLESHOOTING SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION Motor will not start; fuses or circuit 1. Short circuit in line cord or plug 1. Inspect line cord or plug for damaged breakers blow insulation and shorted wires. - Page 11 9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 Palmgren Operating Manual & Parts List 9683295 TROUBLESHOOTING (CONTINUED) SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION Tooth breakage Cut advancing too quickly Decrease cutting advance, exerting less cutting pressure. Adjust the braking device. Wrong cutting speed Change speed and/or type of blade.
- Page 12 9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 Palmgren Operating Manual & Parts List 9683295 TROUBLESHOOTING (CONTINUED) SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION Premature blade wear Faulty running-in of blade See OPERATION - BLADE SELECTION GUIDE LINES page 9. Teeth positioned in the direction opposite Remove the blade and reinstall it with the teeth of the cutting direction cutting in the proper direction.
- Page 13 9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 Palmgren Operating Manual & Parts List 9683295 TROUBLESHOOTING (CONTINUED) SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION Blade breakage/damag Blade guide pads not adjusted properly Check the adjustment of the blade guides. or dirty because of lack of maintenance See OPERATION SET-UP / Blade guide insert adjustments on page 7.
-
Page 14: Maintenance
9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 Palmgren Operating Manual & Parts List 9683295 TROUBLESHOOTING (CONTINUED) SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION Faulty cut Worn out bandwheels. Flywheel housing The support and guide flange of the bandwheels full of chips are so worn they cannot maintain the proper align- ment of the blade causing’... - Page 15 9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 Palmgren Operating Manual & Parts List 9683295...
- Page 16 9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 Palmgren Operating Manual & Parts List 9683295...
- Page 17 9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 Palmgren Operating Manual & Parts List 9683295...
- Page 18 9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 Palmgren Operating Manual & Parts List 9683295...
- Page 19 9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 Palmgren Operating Manual & Parts List 9683295...
- Page 20 9683295_oipm_En012_9645931.01-0620 __ 07-02-2020 PALMGREN WARRANTY C.H. Hanson / Palmgren warrants their products to be free of defects in material or workmanship. This warranty does not cover defects due directly or indirectly to misuse, abuse, normal wear and tear, failure to properly maintain the product, heated, ground or otherwise altered, or used for a purpose other than that for which is was intended.
