Solid Wood TV Floor Stand Instruction Manual SKU: STAND-TV65C Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv65c GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
Page 3
TIPOVER WARNING SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM TIPOVER. TO HELP PREVENT TIPOVER: • NEVER ALLOW CHILDREN TO CLIMB, STAND, HANG, OR PLAY ON ANY PART OF TV OR STAND. • USE TIPOVER RESTRAINT OR ANCHOR STAND TO WALL USE OF TIPOVER RESTRAINTS MAY ONLY REDUCE, BUT NOT ELIMINATE RISK OF TIPOVER.
ASSEMBLY STEPS STEP 1 Assemble Side Legs (B) to Center Brace (D) using M6x70mm Screws (S-A) and 4mm Allen Wrench (T-A).
Page 5
STEP 2 Loosen the screw on the back of Pole (C) using 4mm Allen Wrench (T-A) and connect Pole (C) to Center Leg (A). Assemble Center Leg (A) to Center Brace (D) using M6x70mm Screw (S-A) and 4mm Allen Wrench (T-A). Attach Cover (G) to the assembly. NOTE: To remove Cover (G), press on the right side.
Page 6
STEP 3 Ensure that the flathead screw in the back of Pole (C) is positioned vertically as shown below. Thread M6x90mm Screw (S-B) into the bottom of Center Leg (A) using 4mm Allen Wrench (T-A). Retighten the screw in the back of Pole (C) using 4mm Allen Wrench (T-A).
Page 7
STEP 4 Slide Collar (H) and M45.5 Spacer (S-C) over Pole (C) and secure it in the desired location using M6x30mm Screw (S-D) and 4mm Allen Wrench (T-A). STEP 5 Remove the Security Screw (F1) from Lower VESA Bracket (F) and open the clamp.
Page 8
STEP 6 OPTION A: Flat Back Monitor Position VESA brackets horizontally on the back of the TV, making sure Upper VESA Bracket (E) is on top and Lower VESA Bracket (F) is below. Secure using screws (M-A or M-B) with Square Washers (M-F), M5 Washers (P-G), and Security Clips (P-B) installed to top holes.
Page 9
STEP 7 Slide the TV with VESA Brackets (E, F) onto Pole (C), letting Upper VESA Bracket (E) rest on Collar (H). Close the clamp on Lower VESA Bracket over Pole (C) and secure with previously removed Security Screw (F1). Remove the magnetic cable channel cover on the back of Center Leg (A) and route cables. >20mm Magnetic Cover...
Page 10
STEP 8 (Option A) Wood Stud Wall Using Security Bracket (P-C) as a guide, mark the drilling location on wall at the same height as the upper VESA bracket. Use of a stud finder is recommended. Drill the hole at least 1.6” (40mm) deep using a 1/8”...
Page 11
STEP 8 (Option B) Concrete/Brick Wall Using Security Bracket (P-C) as a guide, mark the drilling location on wall at the same height as Upper VESA Bracket (E). Drill the hole at least 40mm (1.6”) deep using a 7mm (9/32”) drill bit. Mount Security Bracket (P-C) to wall using Anchor (P-F) and ST4.8x38mm Screw (P-E).
Page 12
: 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
