Start-up
5.2.1

Mounting the DHC Radiator Thermostat

In case of visible damage to the existing radiator,
valve or heating pipes, consult a specialist.
Remove the old thermostat dial from your radiator valve.
1. Rotate the thermostat dial to the maximum value
(N) anti-clockwise (see figure 4).
» The thermostat dial no longer presses against the
valve spindle, making it easier to remove.
The thermostat dial could be fixed in different ways:
Union nut:
•
1. Unscrew the union nut in an anticlockwise direc-
tion (O).
2. Remove the thermostat dial (P).
• Snap-on fastenings:
1. Unscrew the union nut in an anticlockwise direc-
tion (O).
2. Remove the thermostat dial (P).
Compression fitting: The thermostat dial is held
•
in place by a mounting ring which is held together
with a screw.
1. Loosen the screw.
2. Remove the thermostat dial (P).
