Racetime 2 - OptoJump Program
A: New tests
B: Stored tests
C: Data transmission
A B
F2
F1
5.1 6.1
F1=Start data transm.
Start
F1 F2

4 Main menu

After choosing the OptoJump program on the chronometer
(see chapter 3 -
necessary if your Racetime 2 is equipped with only the
OptoJump program), you enter the main menu, from which it
is possible to access all the available functions.
F1 – New tests – To enter the menu for the selection of the
tests to be performed (chap. 5)
F2 – Tests done – To access the menu for the display of
previously memorized tests (chap. 6)
C more
F3 F4
4.1
F3 – Data transmission – Activates the transmission of
memorized data to the PC. Connect the PC to Racetime 2 with
the appropriate cable (Cod.CAB046 or Cod.CAB047 +
Cod.CAB001), and press F1 (Start) to confirm the start of
transmission. The memorized data is transmitted according to
esc
the protocol given in the Appendix. For reception, we
recommend you use the OptoJump program on PC (versions
F3 F4
3.20 and subsequent). In this way the transferred data will be
stored and can be viewed as if it had been acquired directly
with the Personal Computer.
User manual
choosing the program is obviously not
5
