Microgate Racetime 2 User Manual page 18

Racetime 2 - OptoJump Program
N 1 T 4 Walk
Lenm. 42.4 cm
esc print values
F1 F2
5.12
Jump N. 1
Tc 0589 Tf 0649ms
Hei 51.7cm Rh
esc clear Len 183.4cm
F1 F2
5.13
N 1 T 3 Walk
Tcm 0469 Tfm0487ms
Heim30.4cm Rhm 62j/m
T=9.570
F1 F2
5.12
Press F1 (esc) to go on to the next test. The values of the test
made obviously remain in the memory for subsequent
reprinting.
Press F2 (print) to obtain a printout of the values measured;
for each jump, contact time, flight time, height, instantaneous
rhythm and step length are printed. Average values for the
same measurements are also given.
F3 F4
Note: printing takes place automatically when you pass to the
next test if the automatic print mode has been set – see chap.
4.1.
Press F3 (values) to pass to the screen display of the
individual jumps; press keys ↓ and ↑ to view the next or
previous jump respectively. F2 (clear) eliminates the jump
displayed. (Attention: it is not possible to annul elimination).
48j/m
F1 (esc) returns you to the display of average values.
F3 F4
By pressing F4 (→) you enter a second screen display in
which you can see the average values for contact time, flight
time, height and rhythm, as well as the real duration of the
test. If two photocells connected to the start line are used to
register entering and exiting of the base, the actual duration of
→
clear
the test coincides with the time taken to cover the distance of
the base.
From this screen display, it is possible to completely eliminate
F3 F4
the test performed by pressing F3. (Attention: it is not
possible to annul elimination).
5.13
Press F4 again to return to the previous screen display.
User manual 18
