Racetime 2 - OptoJump Program

1 Introduction

The Optojump program for Racetime functions along the same lines as the Optojump program for
PC, with which it is totally compatible, in this sense, that it allows the transference of data acquired
with Racetime 2 to the personal computer for subsequent elaboration and storage of the data.

2 Connecting the OptoJump system

Make sure that the Optojump modules are correctly aligned, as indicated in the Optojump system
assembly instructions. Connect the cable coming from the interface/battery for Optojump to the
socket located at the rear of the Racetime 2 chronometer using the appropriate 9 pole/15 pole
adaptor. Now the system is ready to function.
Microgate - Italy
RACETIME 2 Vxx.y.zz
SN ########
Ch. ### (S#######)
F1 F2
Data are not valid
Press enter
Yes
F1 F2
System locked
Contact Microgate
Yes
F1 F2
Clear all
stored data?
F1 F2

3 Switching on Racetime 2, initialization

Switch on Racetime 2 with the switch located on the back of
the device. The display will show several items of information
about the software version installed on your Racetime 2, and
the serial number of the device.
If you have to contact Microgate for any information or about
any problems, always give the serial number of your system.
F3 F4
Press a key to continue.
At this point the following screen displays may appear:
Check to see if the device was completely emptied after the
previous work session. Any previously memorised data has
been irretrievably lost. Press ENTER to continue.
No
F3 F4
Check to see if any anomalies were discovered during initial
tests on the machine. Contact Microgate for further
information.
No
F3 F4
Usually appears after switching on. Press F3 to delete
previously memorized data (your choice must be confirmed).
Yes No
F3 F4
User manual 3
