Microgate Racetime 2 User Manual page 12

Racetime 2 - OptoJump Program
Jump N. 4
Tc 0205 Tf 0618ms
Hei 46.9cm Rh
T=0 :03.371
F1 F2
Jump N. 10
Tc 0235 Tf 0471ms
Hei 27.2cm Rh
T=9.570 CleTst OK
F1 F2
N 1 T 3
Power=23.87 W/Kg
Work= 7.13 Cal/Kg
esc print values
F1 F2
5.4
At this point, Racetime 2 is waiting for the start of the test. If
the athlete's position does not correspond to the start type
settings (from inside or outside the measurement base) an
error message is displayed.
During performance of the test, the following information is
displayed:
• Serial jump number
72j/m
• Contact time for the present jump
• Flight time
• Height of jump (shift of center of gravity) of the athlete
F3 F4
• Instantaneous rhythm in jumps/minutes
• In the lower part of the display, a running time indicator
The end of the test is signaled by a beep.
The test can be interrupted before completion by pressing CE.
Attention: if the test is interrupted, the data acquired up to this
64j/m
point is NOT saved.
It is possible to confirm by pressing F4 (OK) or to annul the
whole test by pressing F3 (CleTst).
F3 F4
5.5
If the test is confirmed (F4), the specific power (W/Kg)
JtiE 10j
developed during the test and the specific work (Cal/Kg)
performed are displayed.
On the first line of the display appear the athlete's code and
→
the test number and test type, with the following meaning:
JnbE=Jumptest jumps, external start
JnbI=Jumptest jumps, internal start
F3 F4
After this the number of jumps set is also given.
To go on to the next test, press F1 (esc). The values of the test
performed are of course memorized for subsequent printing.
To obtain a printout of the values measured, press F2 (print);
for each jump, contact time, flight time, height and
instantaneous rhythm are printed. The average values for
some measurements are given, as well as strength and work.
Note: printing takes place automatically when you pass to the
next test if the automatic print mode has been set – see chap.
4.1.
User manual
being tested
shows how much time has passed since the start of the
test.
12
