- Page 1 ZT-2510 Series User Manual Warranty All products manufactured by ICP DAS are under warranty regarding defective materials for a period of one year, beginning from the date of delivery to the original purchaser. Warning ICP DAS assumes no liability for any damage resulting from the use of this product.
-
Page 2: Table Of Contents
Table of Content 1 Introduction of ZigBee ....... 4 2 Introduction of ZT-2510 ......5 3 Hardware Information ......... 6 3.1 Specifications ........6 3.2 ZT-2510 Front View ......8 3.3 ZT-2510 Block Diagram ......9 3.4 ZT-2510 Dimensions (Units: mm) ....9 4 Set up the ZT-2510 module ...... - Page 3 What’s in the shipping package? The package includes the following items: ZT-2510 Device ANT-124-05 CA-USB18 If any of these items are missing or damaged, please contact your local distributor for more information. Save the shipping materials and cartons in case you want to ship the module in the future.
-
Page 4: Introduction Of Zigbee
Introduction of ZigBee ZigBee is a specification for a suite of high level communication protocols using small, low-power digital radios based on an IEEE 802.15.4 standard for personal area networks. ZigBee devices are often used in mesh network form to transmit data over longer distances, passing data through intermediate devices to reach more distant ones. -
Page 5: Introduction Of Zt-2510
Introduction of ZT-2510 The Basis of ZT-2510 Series Product The ZT-2510 series module is small-sized wireless ZigBee repeater based on the IEEE802.15.4 standard. It supports network routing and signal relay transmission function in a personal area ZigBee network. The typical transmission of ICP DAS ZT series ZigBee products is 700 meters (LOS, line of sight), with a transmission frequency range of between 2.405 GHz and 2.48 GHz,... -
Page 6: Hardware Information
Hardware Information 3.1 Specifications Part Number ZT-2510 (ZigBee Router) Configuration Interface Type B CA-USB18 (1.8 M Cable) x 1; USB Type A connector (Type A to Cable Type B cable provided) Compatibility USB 1.1 and 2.0 standard Driver Windows 98/ME/2000/XP/Vista/7/8/8.1/10/Linux LED Indicator Display Green ZigBee Net... - Page 7 Environment Operating Temperature -25 ° C ~ +75 ° C Storage Temperature -40 ° C ~ +80 ° C Relative Humidity 5 ~ 95% RH (non-condensing) Wireless RF Channel RF Transmit Power 11 dBm Antenna (2.4GHz) 5 dBi Omni-Directional antenna Transmit Range (LOS) 700 m (Typical) Max.
-
Page 8: Zt-2510 Front View
3.2 ZT-2510 Front View System LED Indicator 2.4GHz RP-SMA Antenna UL 94V-0 materials USB Type B +10~+30 V Power input 1. LED Indicator of System： LED Indicator LED Color Explain ZigBee Net Green The status of ZigBee network. ZigBee RxD Yellow The status of ZigBee communication ZigBee PWR... -
Page 9: Zt-2510 Block Diagram
3.3 ZT-2510 Block Diagram LED Display ZigBee Module (Type B) (Slave) Power Circuit 3.4 ZT-2510 Dimensions (Units: mm) Front View Bottom View Left Side View Right Side View Page 9 ICP DAS, ZT-2510 User Manual, Version 2.0 Copyright @ 2012 by ICP DAS Co., Ltd. All Rights Reserved. -
Page 10: Set Up The Zt-2510 Module
Set up the ZT-2510 module 4.1 Introduction of configurations Pan ID “Pan ID” is the group identity of a ZigBee network. The “Pan ID” must be the same if they are in the same ZigBee network. (Valid values range from 0x0000 to 0x3FFF) Node ID “Node ID”... -
Page 11: Connecting The Power And Host Pc
“RF Power” is the wireless transmit power. Hex Code Description 0x0F Typical Maximum 0x08 Fit the CE/FCC certification 0x00 Typical Minimum ※ The parameter adjustment purely personal behavior, ICP DAS can not guarantee to pass CE/FCC certification if adjusting this parameter, nor assume any liability because of the adjustment parameters derived from the RF Power. -
Page 12: Install Driver
4.3 Install driver Please confirm whether there is the word [V2] in the lower right corner of the module model, and select the appropriate driver to install according to the table below Without the word [V2] With the word [V2] Hardware Version Operating... -
Page 13: Configuring Zigbee Setting
4.4 Configuring ZigBee Setting Launch the “ZT Configuration Utility” click the [Configuration Utility] button click the [ZT 25xx Series] button Click the [Serial Port] icon and then select the COM Port number connected to ZT 2510. After selecting the COM Port number, a list of model numbers will be displayed. - Page 14 Page 14 ICP DAS, ZT-2510 User Manual, Version 2.0 Copyright @ 2012 by ICP DAS Co., Ltd. All Rights Reserved.
- Page 15 Once a connection is established, select either the [Default] or the [Wizard] function from the settings mode page. Wizard Default Whether you select either the [Default] or the [Wizard] option for performing configuration, both are used to configure the Pan ID, Node ID, RF Channel, RF Power and so the relevant parameters.
-
Page 16: Zt-2510 Applications
ZT-2510 Applications (1) ZT-2510 is suitable used in which environment is many obstacles and interferences. [ZigBee Router] [ZigBee End Device] WARNING HIGH VOLTAGE [ZigBee Coordinator] ZT-2510 [ZigBee Router] [ZigBee End Device] WARNING HIGH VOLTAGE [ZigBee Coordinator] Page 16 ICP DAS, ZT-2510 User Manual, Version 2.0 Copyright @ 2012 by ICP DAS Co., Ltd. - Page 17 (2) ZT-2510 is suitable used in which environment need to extend the communication range. [ZigBee Router] [ZigBee End Device] [ZigBee Coordinator] [ZigBee Router] [ZigBee End Device] [ZigBee Coordinator] ZT-2510 ZT-2510 (3) ZT-2510 is suitable used as redundant routing path. Page 17 ICP DAS, ZT-2510 User Manual, Version 2.0 Copyright @ 2012 by ICP DAS Co., Ltd.
-
Page 18: Trouble Shooting
Trouble shooting (1) LED Indicator Status： LED Indicator Status Introduction The status of ZigBee network [ZigBee Router (Slave)] Steady Lit Signal Strength ZigBee Net Blinking (500 ms) Signal Available (Green LED) Blinking (1s) Signal Weak Blinking (2s) Signal Terrible or No ZigBee Network The status of ZigBee communication ZigBee RxD Blinking... - Page 19 (2) Technical Support. If you are any difficulties using the ZT-2510 module, save the ZigBee configurations using the described below. Please also provide a description of problem and attach file to an email and send it to service@icpdas.com Connect the ZT 2510 to the PC via USB. Launch the ZT Configuration Utility and select [Save Log] icon to save the configuration of ZT 2510 as a file.
-
Page 20: Appendixes
Appendixes Technology Support If there is any question or concerns for using ZT-2510 module, please feel free to contact us：service@icpdas.com If there is any question or concern for using ZT-2510 module, please feel free to contact us. ICP DAS will assist reply to you. Taiwan Europe Website：http://www.icpdas.com...
