ICP DAS USA Zigbee ZT-2060 Quick Start Manual

ZT-2060
Zigbee Wireless 6-channel Digital Input, 4-channel
Relay Output Module
Quick Start Guide
Product Website:
https://www.icpdas-usa.com/zt_2060.html
Introduction
The ZT-2060 offers 4 Form A power relay output channels and 6 digital input
channels, each of which features photocouple isolation. In addition, you can
choose sink-type or source-type input via wire connections. All channels are able
to be used as 16-bit counters. The ZT-2060 has 10 LED indicators to display the
channel status, and has 4 kV ESD protection and 3000 VDC intramodule isolation.
Users can easily configure the module address, protocol, checksum, ZB-PID and
ZB-channel settings using a combination of rotary and DIP switches.
1
What's in the Shipping Package?
The shipping package contains the following items:
ZT‐2060 DIO Device ANT‐124‐05 Quick Start
ZT-2060 Zigbee 6-ch DI, 4-ch Relay Output Module- QuickStart (Jan/2018)
