ZT-2053
ZigBee Wireless Module with 14 Digital Input
Channels
Quick Start Guide
Product Website:
https://www.icpdas-usa.com/zt_2053
Introduction
The ZT-2053 offers 14 digital input channels which can be used for either dry or
wet contact. Its effective distance for dry contact is up to 500 meters. All channels
are able to be used as 16-bit counters. The ZT-2053 includes 14 LED indicators to
display the channel status as well as 4 kV ESD protection and 3750 Vrms intra-
module isolation. Users can easily to configure the module address, protocol,
checksum, ZB-PID and ZB-channel settings using a combination of rotary and DIP
switches.
1
What's in the Shipping Package?
The shipping package contains the following items:
ZT‐2053 DIO Device
ANT‐124‐05
Quick Start
ZT-2053 - 14-channel DI Module with Counters- QuickStart (Sep/2017)
ICP DAS USA, Inc. |
www.icpdas-usa.com
| 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ZT-2053 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ICP DAS USA ZT-2053

  • Page 1 Introduction The ZT-2053 offers 14 digital input channels which can be used for either dry or wet contact. Its effective distance for dry contact is up to 500 meters. All channels are able to be used as 16-bit counters. The ZT-2053 includes 14 LED indicators to display the channel status as well as 4 kV ESD protection and 3750 Vrms intra- module isolation.
  • Page 2: Preparing The Device

    Preparing the Device Refer the chapter 3. to configure the DIP switch of ZT-2053 I/O device. Install the ZT Configuration Utility to configure the ZT-2053 coordinator. CD: \Napdos\ZigBee\ZT_Series\Utility http://ftp.icpdas.com/pub/cd/usbcd/napdos/zigbee/ zt_series/utility Power Supply: +10 ~ +30 V Setting up the ZT‐2053 DIO Device 3.1 Introduction to the Configuration Parameters...
  • Page 3 Modbus RTU Modbus RTU Modbus Gateway Modbus Gateway Modbus TCP Modbus RTU ------ Modbus Gateway ZT-2053 - 14-channel DI Module with Counters- QuickStart (Sep/2017) ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717...
  • Page 4 Rotation Switch and DIP Switch The configuration of ZT-2053 series can be adjusted by using the external rotary switch and the DIP switches. The ZT-2053 device should only be rebooted once the configuration is complete. DIP Switch to the ZT‐2042/ZT‐2043/ZT‐2053/ZT‐2055 ...
  • Page 5: Rotation Switch

    Pan ID = 0x0001 ------ 0x08 ------ ZigBee 0x04 ------ RF Channel 0x02 ------ 0x01 ZT-2053 - 8-channel DI DAQ module - QuickStart (Nov/2016) ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717...
  • Page 6 ※ Configuration Utility (Used to configure ZT-2000 I/O device Coordinator) http://ftp.icpdas.com.tw/pub/cd/usbcd/napdos/zigbee/zt_series/utility/ ZT-2053 - 8-channel DI DAQ module - QuickStart (Nov/2016) ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717...
  • Page 7 Pan ID=0x0000 0x08 ZigBee 0x04 ZigBee RF Channel = 0x0E RF Channel 0x02 ------ ZT-2053 - 8-channel DI DAQ module - QuickStart (Nov/2016) ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717...
  • Page 8: Communication Test

    Clicking “Search” button will start searching which ZT-2000 I/O device is in the same ZigBee network. If there is any ZT-2000 I/O devices displayed, double clicking the “module name” will start the I/O channels operated platform. ZT-2053 - 8-channel DI DAQ module - QuickStart (Nov/2016) ICP DAS USA, Inc. | www.icpdas-usa.com...
  • Page 9 ZT-2053 - 8-channel DI DAQ module - QuickStart (Nov/2016) ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717...
  • Page 10: Troubleshooting

    After clicking the [Save Log] icon, enter the “File Name” and the “File Path” in the Windows “Save” dialog box. Once the configuration has been successfully saved, the following message will be displayed. ZT-2053 - 8-channel DI DAQ module - QuickStart (Nov/2016) ICP DAS USA, Inc. | www.icpdas-usa.com...
  • Page 11 Steady Lit The DI/DO channel is Enabled Steady Unlit The DI/DO channel is Disabled ZT-2053 - 8-channel DI DAQ module - QuickStart (Nov/2016) ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717...
