ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ
ZT-2510 Series
Warranty
All products manufactured by ICP DAS are under warranty
regarding defective materials for a period of one year, beginning
from the date of delivery to the original purchaser.
Warning
ICP DAS assumes no liability for any damage resulting from the use
of this product. ICP DAS reserves the right to change this manual
at any time without notice. The information furnished by ICP DAS
is believed to be accurate and reliable. However, no responsibility is
assumed by ICP DAS for its use, not for any infringements of
patents or other rights of third parties resulting from its use.
Copyright
Copyright © 2012 by ICP DAS. All rights are reserved.
Trademark
Names are used for identification only and may be registered
trademarks of their respective companies.
Technology Support
If you have any problems, please feel free to contact us
via email at
ICP DAS, ZT‐2510 Series User Manual, Version 1.0
Copyright @ 2012 by ICP DAS Co., Ltd. All Rights Reserved.
+7(495)109-02-08 sales@bbrc.ru www.bbrc.ru
service@icpdas.com
User Manual
Page 1
Advertisement
Table of Contents
Related Manuals for ICP DAS USA ZT-2510 Series
Summary of Contents for ICP DAS USA ZT-2510 Series
- Page 1 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ZT-2510 Series User Manual Warranty All products manufactured by ICP DAS are under warranty regarding defective materials for a period of one year, beginning from the date of delivery to the original purchaser.
-
Page 2: Table Of Contents
ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Table of Content 1 Introduction of ZigBee ....... 4 2 Introduction of ZT‐2510 ......5 3 Hardware Information ......... 6 3.1 Specifications ........6 3.2 ZT‐255x Front View ....... 7 3.3 ZT‐2510 Block Diagram ......8 3.4 ZT‐2510 Dimensions (Units: mm) ....8 4 Set up the ZT‐2510 module ......9 4.1 ... - Page 3 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru What’s in the shipping package? The package includes the following items: ZT-2510 Device ANT-124-05 CA-USB18 Release Note If any of these items are missing or damaged, please contact your local distributor for more information.
-
Page 4: 1 Introduction Of Zigbee
ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Introduction of ZigBee ZigBee is a specification for a suite of high level communication protocols using small, low-power digital radios based on an IEEE 802.15.4 standard for personal area networks. ZigBee devices are often used in mesh network form to transmit data over longer distances, passing data through intermediate devices to reach more distant ones. -
Page 5: 2 Introduction Of Zt-2510
+7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Introduction of ZT‐2510 The Basis of ZT-2510 Series Product The ZT-2510 series module is small-sized wireless ZigBee repeater based on the IEEE802.15.4 standard. It supports network routing and signal relay transmission function in a personal area ZigBee network. The typical transmission of ICP DAS ZT series ZigBee products is 700 meters (LOS, line of sight), with a transmission frequency range of between 2.405 GHz and 2.48 GHz,... -
Page 6: 3 Hardware Information
ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Hardware Information Specifications Part Number ZT-2510 (ZigBee Router) Configuration Interface Type B CA-USB18 (1.8 M Cable) x 1; USB Type A connector (Type A to Cable Type B cable provided) Compatibility USB 1.1 and 2.0 standard... -
Page 7: Zt-255X Front View
ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ZT‐255x Front View System LED Indicator 2.4GHz RP-SMA Antenna UL 94V-0 materials USB Type B +10~+30 V Power input 1. LED Indicator of System： LED Indicator LED Color Explain ZigBee Net Green... -
Page 8: Zt-2510 Block Diagram
ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ZT‐2510 Block Diagram LED Display ZigBee Module (Type B) (Slave) Power Circuit ZT‐2510 Dimensions (Units: mm) Front View Bottom View Left Side View Right Side View Page 8 ICP DAS, ZT‐2510 Series User Manual, Version 1.0 Copyright @ 2012 by ICP DAS Co., Ltd. All Rights Reserved. ... -
Page 9: 4 Set Up The Zt-2510 Module
ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Set up the ZT‐2510 module 4.1 Introduction of configurations “Pan ID” is the group identity of a ZigBee network, and must be the same if they are in the same ZigBee network. (Valid values range from 0x0000 to 0x3FFF) “Node ID”... -
Page 10: Connecting The Power And Host Pc
ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru “RF Power” is the transmit power. Code Note 0x0F Typical Maximum 0x08 Fit the CE/FCC certification 0x00 Typical Minimum ※ 4.2 Connecting the Power and Host PC Connect the interface USB port for doing configuration. ... -
Page 11: Configuring Zigbee Setting
ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru 4.3 Configuring ZigBee Setting Launch the “ZT Configuration Utility” and click the [ZT Series] button. Click the [Serial Port] icon and then select the COM Port number. 1 After selecting the COM Port number, a list of model numbers will be displayed. - Page 12 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Once a connection is established, select either the [Default] or the [Wizard] function from the settings mode page. 4 Wizard Default Whether you select either the [Default] or the [Wizard] option for performing configuration, both are used to configure the Pan ID, Node ID, RF Channel, RF Power and so the relevant parameters.
-
Page 13: 5 Zt-2510 Applications
ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru ZT‐2510 Applications (1) ZT-2510 is suitable used in which environment is many obstacles and interferences. [ZigBee Router] [ZigBee End Device] WARNING HIGH VOLTAGE [ZigBee Coordinator] ZT-2510 [ZigBee Router] [ZigBee End Device] WARNING HIGH... - Page 14 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru (2) ZT-2510 is suitable used in which environment need to extend the communication range. [ZigBee Router] [ZigBee End Device] [ZigBee Coordinator] [ZigBee Router] [ZigBee End Device] [ZigBee Coordinator] ZT-2510 ZT-2510 (3) ZT-2510 is suitable used as redundant routing path.
-
Page 15: 6 Trouble Shooting
ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Trouble shooting (1) LED Indicator Status： LED Indicator Status Introduction The status of ZigBee network [ZigBee Router (Slave)] Steady Lit Signal Strength ZigBee Net Blinking (500 ms) Signal Available (Green LED) Blinking (1s) Signal Weak... - Page 16 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru (2) Technical Support. If you are any difficulties using the ZT-255x module, save the ZigBee configurations using the described below. Please also provide a description of problem and attach file to an email and send it to service@icpdas.com Set the DIP switch of the ZT-255x device to the [ZBSET] position then reboot the device.
- Page 17 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Appendixes Technology Support If there is any question or concerns for using ZT-2000 series module, please feel free to contact us：Service@icpdas.com If there is any question or concern for using ZT-2000 series module, please feel free to contact us.
