Industrial Ethernet Switch
User manual
MIEN3020G-4GC-16GT
MIEN3028G-4GC-24GT
Packing list
1
The package of this switch contains the following items. If any item is found
to be missing or damaged, please contact the agent or the customer service
center of Maiwe for assistant.
Items
Industrial Ethernet Switch
Power cord
User Manual
2
Product description
This series isThis switch is an unmanaged rack-mount industrial Ethernet
switch.MIEN3020G-4GC-16GT(4 Gigabit Combo ports+16 Gigabit RJ45
ports), MIEN3028G-4GC-24GT provides 28 ports (4 Gigabit combo ports+24
Gigabit RJ45 ports).
Quantity
Remarks
1PCS
1PCS
AD220 model only
1PCS
