To access the most used commands ......26 data, … Configuration wizard..............26 ▪ Format: Digital files on http://www.daikineurope.com/support- 6.2.1 Configuration wizard: Language ......... 27 and-manuals/product-information/ 6.2.2 Configuration wizard: Time and date ......27 Installation manual EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
1× 1× ▪ A subset of the latest technical data is available on the regional Daikin website (publicly accessible). ▪ The full set of latest technical data is available on the Daikin Business Portal (authentication required). Online tools 1× 4×...
(example: open flames, an operating gas appliance or an operating electric heater). WARNING Make sure installation, servicing, maintenance and repair comply with instructions from Daikin and with applicable legislation (for example national gas regulation) and are executed only by authorised persons. Installation manual...
4 6]): 1 User interface panel 2 Front panel 5 Open the installer switch box as follows: 2 Remove the insulation from the shut-off valves by cutting the cable ties. EGSAH/X06+10DA9W(G) Installation manual Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
Page 8
X1YA X11YB CAUTION X22Y The hydro module is heavy. It requires at least two persons to carry it. NOTICE Make sure not to damage any insulation during the removal process. Installation manual EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
Mounting the indoor unit 3.3.1 To install the indoor unit 1 Lift the indoor unit from the pallet and place it on the floor. See unit" [ 4 5]. "2.1.2 To handle the indoor EGSAH/X06+10DA9W(G) Installation manual Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
4 Close the shut-off valve below the vessel. 5 Remove the safety valve on top of the vessel. 6 Top up the vessel with brine until it is approximately 2/3 filled. Installation manual EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
It MUST be protected against with the applicable legislation. freezing. For more information, see setting [A‑04] in temperature" [ 4 32]. "6.4.4 Brine freezing EGSAH/X06+10DA9W(G) Installation manual Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
Emergency operation: backup heater = maximum 6 kW period of time. NOTICE After water piping installation, check all connections for leaks. Installation manual EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
▪ [3.9] (read-only) Control power supply) (connection to factory-mounted cable outside of the unit) C1: Power supply for the backup heater, and the rest of the unit (1N~ or 3N~) EGSAH/X06+10DA9W(G) Installation manual Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
Page 14
C2: Preferential kWh rate power supply contact C3: Separate normal kWh rate power supply for the hydro (1N~) C4: Connection of X11Y C5: Preferential kWh rate power supply for the compressor (1N~) Installation manual EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
Page 15
Preferential kWh rate power supply contact: 16 V DC detection (voltage supplied by PCB). The voltage-free contact shall ensure the minimum applicable load of 15 V DC, 10 mA. Connect the preferential kWh rate power supply contact (S1S) as follows. 1× EGSAH/X06+10DA9W(G) Installation manual Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
INFORMATION If the desired leaving water temperature is weather dependent, the full time outdoor temperature measurement is important. Remote outdoor sensor + cable (40 m) delivered as accessory Installation manual EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
1 Top panel 2 User interface panel 3 Installer switch box cover 2 Connect the electricity meters cable to the appropriate terminals as shown in the illustration below. EGSAH/X06+10DA9W(G) Installation manual Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
To connect the space cooling/ Cable sleeve (field supply) heating ON/OFF output Wires: (2+1)×0.75 mm² Maximum load: 3.5 A, 250 V AC — unit" [ 4 6]): 1 Open the following (see "3.2.1 To open the indoor Installation manual EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
2 User interface panel 3 Front panel 4 Main switch box cover 2 Connect the changeover to external heat source cable to the appropriate terminals as shown in the illustration below. EGSAH/X06+10DA9W(G) Installation manual Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
2 Connect the safety thermostat (normally closed) cable to the appropriate terminals as shown in the illustration below. 2 Connect the power consumption digital inputs cable to the appropriate terminals as shown in the illustration below. Installation manual EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
NOTICE Before disconnecting. If you want to remove or disconnect the brine low pressure switch, first set [C‑0B]=0 (brine low pressure switch not installed). If not, this causes an error. EGSAH/X06+10DA9W(G) Installation manual Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
▪ App control of the heat pump system Unit control method On the user interface, make sure to set ▪ Integration of the heat pump system in a Smart Grid application [2.9]=2 (Control = Room thermostat) Installation manual EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
It is recommended to connect the LAN adapter to the energy application router directly. Depending on the wireless bridge or power management line adapter model, the system might not function properly. system + 230 V AC detection voltage (X1A) EGSAH/X06+10DA9W(G) Installation manual Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
The rest of the wiring to X1A differs depending on the digital outputs available on the solar inverter/energy management system and/or on the Smart Grid operation modes that you want the system to run in. Installation manual EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
▪ Afterwards. If necessary, you can make changes to the solar inverter/energy management system to LAN adapter configuration in the menu structure or the overview settings. digital inputs X1A/1+2 LAN. EGSAH/X06+10DA9W(G) Installation manual Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
This way the unit will be able to run properly. Afterwards, more detailed settings can be done via the menu structure if required. User pin code The User pin code is 0000. Installation manual EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
NOT available. Similarly as in Manual mode, the unit can take the full load with backup heater user activates this Malfunctioning main menu screen. EGSAH/X06+10DA9W(G) Installation manual Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
Depending on how the backup heater is connected to the grid and what voltage is supplied, the correct value needs to be set. In either configuration, the backup heater will operate in steps of 1 kW. Installation manual EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
Only program a storage stop when tank heating is absolutely Emitter type undesirable. For more info about this functionality, see "6.2.5 Configuration Code Description zone" [ 4 28]. wizard: Main [5.2] [6-0A] Comfort setpoint: ▪ 30°C~[6‑0E]°C EGSAH/X06+10DA9W(G) Installation manual Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
Fine-tune with slope and When offset is selected: set offset. offset: Confirm changes and return to the submenu. At regular outdoor At cold outdoor Slope Offset temperatures … temperatures … Cold ↑ — EGSAH/X06+10DA9W(G) Installation manual Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
Thermostat type Only applicable in external room thermostat control. For more info zone" [ 4 32]. about the functionality, see "6.4.1 Main Installation manual EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
Ext. amb. sensor offset Averaging time [9.C] Bivalent Bivalent Boiler efficiency Temperature Hysteresis Only applicable in Swedish language. INFORMATION Depending on the selected installer settings and unit type, settings will be visible/invisible. EGSAH/X06+10DA9W(G) Installation manual Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
The fuses or locally installed protection devices are installed according to this document, and have NOT been bypassed. The power supply voltage matches the voltage on the identification label of the unit. Installation manual EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
2 Go to [A.4]: Commissioning > UFH screed dryout. Operation and turn off Room, Space heating/cooling and Tank 3 Set a dryout program: go to Program and use the operation. UFH screed dryout programming screen. EGSAH/X06+10DA9W(G) Installation manual Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
During the 10 day brine pump operation, the setting will be displayed as ON in the menu. Once the procedure has been completed, it will change to OFF automatically. Installation manual EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
9 Technical data Technical data A subset of the latest technical data is available on the regional Daikin website (publicly accessible). The full set of latest technical data is available on the Daikin Business Portal (authentication required). Piping diagram: Indoor unit...
Only for preferential kWh rate Backup heater control PCB power supply with separate power supply with separate Inverter PCB normal kWh rate power supply normal kWh rate power supply * Demand PCB Installation manual EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
Page 39
Safety thermostat contact: DC detection (voltage supplied 16 V DC detection (voltage by PCB) supplied by PCB) Shut-off valve Shut-off valve Switch box (7) Option PCBs (7) Option PCBs Alarm output Alarm output EGSAH/X06+10DA9W(G) Installation manual Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
Page 40
Power limitation demand input 3 FIELD SUPPLY A8P: X801M: 3-5 signal 2 core Power limitation demand input 4 Router for LAN adapter A8P: X801M: 4-5 A15P: X4A signal ethernet 4D121919 Installation manual EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569811-1C – 2020.07...
Page 44
4P569811-1 C 00000002 4P569811-1C 2020.07 Verantwortung für Energie und Umwelt...
