- Page 1 User reference guide Daikin Altherma 3 GEO EGSAH06DA9W EGSAH10DA9W User reference guide EGSAX06DA9W(G) English Daikin Altherma 3 GEO EGSAX10DA9W(G)
-
Page 2: Table Of Contents
Using holiday mode ............ 27 Thermostat type [2.A] 5 Energy saving tips Additional zone (if applicable) 6 Maintenance and service Thermostat type [3.A] Overview: Maintenance and service ......... 29 Information User reference guide EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 3: Quick Actions
Additional zone Space heating/cooling To turn room temperature control ON or OFF 1 Go to [C.1]: Operation > Room. Operation Room Space heating/cooling 2 Set operation to On or Off. EGSAH/X06+10DA9W(G) User reference guide Daikin Altherma 3 GEO 4P569819-1 – 2019.02... - Page 4 Select slope or offset. Increase or decrease the slope/offset. When slope is selected: set slope and go to offset. When offset is selected: set offset. Confirm changes and return to the submenu. User reference guide EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569819-1 – 2019.02...
-
Page 5: Domestic Hot Water
X1 is equally higher as the preferred temperature at X2. preferred temperature at X2. X1, X2 Outdoor ambient temperature Y1~Y4 Desired tank temperature WD curve before changes WD curve after changes Slope Offset EGSAH/X06+10DA9W(G) User reference guide Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 6: General Information
Daikin Online Control Heating app Waste batteries must be treated at a specialized treatment facility If set up by your installer, you can use the Daikin for reuse. By ensuring waste batteries are disposed of correctly, Online Control Heating app to control and... -
Page 7: Meaning Of Warnings And Symbols
Indicates a situation that could result in minor or moderate injury. NOTICE Indicates a situation that could result in equipment or property damage. INFORMATION Indicates useful tips or additional information. EGSAH/X06+10DA9W(G) User reference guide Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 8: Operation
▪ Installer: 1 h Dials and buttons You use the dials and buttons: ▪ To navigate through the screens, menus and settings of the LCD screen ▪ To set values User reference guide EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 9: Menu Structure: Overview User Settings
User profile Operation Room Space heating/cooling Tank Setpoint screen Not applicable (**) Only accessible by installer INFORMATION Depending on the selected installer settings and unit type, settings will be visible/invisible. EGSAH/X06+10DA9W(G) User reference guide Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 10: Possible Screens: Overview
The most common screens are as follows: – Home screen Main menu screen Lower level screens: c1: Setpoint screen c2: Detailed screen with values c3: Screen with weather-dependent curve c4: Screen with schedule User reference guide EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 11: Home Screen
Measured outdoor temperature Quiet mode active Outdoor brine piping g Indoor unit / domestic hot water tank Floor-standing indoor unit with integrated tank Water pressure EGSAH/X06+10DA9W(G) User reference guide Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 12: Main Menu Screen
Restriction: Only for the installer. Commissioning Perform tests and maintenance. Change the active user profile. User profile Turn heating/cooling functionality and Operation domestic hot water preparation on or off. User reference guide EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 13: Setpoint Screen
7.2.1 Time/date Hours Minutes Settings Values Selected setting and value Possible actions on this screen Go through the list of settings. Change the value. Go to the next setting. EGSAH/X06+10DA9W(G) User reference guide Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 14: Turning Operation On Or Off
Tank heating operation OFF 4.4.2 To turn ON or OFF Room temperature control 1 Go to [C.1]: Operation > Room. Operation Room Space heating/cooling 2 Set operation to On or Off. User reference guide EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 15: Reading Out Information
Example: Defrost/oil return mode [8.7] About Version information about the system [8.8] Connection status Information about the connection status of the unit, the room thermostat and the LAN adapter. EGSAH/X06+10DA9W(G) User reference guide Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 16: Space Heating/Cooling Control
Room thermostat type of the main zone: ▪ Heating: Only heating mode ▪ Cooling: Only cooling mode ▪ Automatic: operation mode changes automatically based on the outdoor temperature. Restricted according to the operation mode schedule. User reference guide EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 17: To Change The Desired Room Temperature
Only adjust the leaving water temperature settings in case of problems. You can use the leaving water temperature setpoint screen to read out and adjust the desired leaving water temperature. EGSAH/X06+10DA9W(G) User reference guide Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 18: Domestic Hot Water Control
In reheat mode the DHW tank continuously heats up to the minimum amount of hot water is available at all times. temperature shown on the home screen (example: 50°C) when the Example: temperature drops below a certain value. User reference guide EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 19: To Change The Domestic Hot Water Temperature
▪ You cannot wait for the next scheduled action to heat up the domestic hot water tank. Then you can activate powerful operation. The domestic hot water tank will start heating up the water to the Comfort temperature. EGSAH/X06+10DA9W(G) User reference guide Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 20: Preset Values And Schedules
> Schedule. 2 Program the selection using the scheduling screen. — You can set the High, Medium and Low electricity prices according to your electricity supplier. 3 Confirm the changes. User reference guide EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 21: Using And Programming Schedules
Edit Copy INFORMATION The procedures to program other schedules are similar. 3 Select OK to confirm. To program the schedule: overview Example: You want to program the following schedule: EGSAH/X06+10DA9W(G) User reference guide Daikin Altherma 3 GEO 4P569819-1 – 2019.02... - Page 22 To rename the schedule: Copy 1 Select the name of the current schedule. User defined 1 Result: Next to the copied day, "C" is displayed. 3 Select Tuesday. User defined 1 User reference guide EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569819-1 – 2019.02...
- Page 23 1 Program 3 room temperature schedules in heating mode and give them appropriate names. Example: EarlyShift, DayShift and LateShift 2 Select the schedule that you currently want to use. EGSAH/X06+10DA9W(G) User reference guide Daikin Altherma 3 GEO 4P569819-1 – 2019.02...
-
Page 24: Weather-Dependent Curve
"4.9.4 Using weather-dependent curves" on page 25. 4.9.2 2-points curve Define the weather-dependent curve with these two setpoints: ▪ Setpoint (X1, Y2) ▪ Setpoint (X2, Y1) Example Weather-dependent curve when offset is selected: User reference guide EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 25: Using Weather-Dependent Curves
WD heating, fixed cooling dependent curve of a zone or tank: mode OR Weather dependent Main zone – Cooling [2.4] Main zone > Setpoint Weather dependent mode Additional zone – Heating EGSAH/X06+10DA9W(G) User reference guide Daikin Altherma 3 GEO 4P569819-1 – 2019.02... - Page 26 — Raise Cold Cold Raise Raise Raise Raise Cold Lower Raise Lower Raise — Lower — Lower Cold Raise Lower Raise Lower Lower Lower Lower Lower "4.9.2 2-points curve" on page 24. User reference guide EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569819-1 – 2019.02...
-
Page 27: Other Functionalities
To configure the holiday 1 Activate the holiday mode. — ▪ Go to [7.3.1]: User settings > Holiday > Activation. 7.3.1 Activation From Till ▪ Select On. EGSAH/X06+10DA9W(G) User reference guide Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 28: Energy Saving Tips
1°C and check if you still have enough hot water. ▪ Program to turn ON the domestic hot water pump only during periods of the day when instant hot water is necessary. Example: In the morning and evening. User reference guide EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 29: Maintenance And Service
Do NOT use the unit until a service person confirms that the part from which the refrigerant leaked has been repaired. EGSAH/X06+10DA9W(G) User reference guide Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 30: Troubleshooting
The weather-dependent curve is Adjust the weather-dependent When the backup heater takes over the heat load, set incorrectly. curve. See "4.9 Weather- electricity consumption will be considerably higher. dependent curve" on page 24. User reference guide EGSAH/X06+10DA9W(G) Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 31: Symptom: The System Is Making Gurgling Noises After Commissioning
▪ If yes, make sure that the room where you want to purge air is sufficiently ventilated. Reason: Refrigerant might leak into the water circuit, and subsequently into the room when you purge air from the heat emitters or collectors. EGSAH/X06+10DA9W(G) User reference guide Daikin Altherma 3 GEO 4P569819-1 – 2019.02... -
Page 32: Relocation
Optional equipment Equipment made or approved by Daikin that can be combined with the product according to the instructions in the accompanying documentation. Field supply Equipment NOT made by Daikin that can be combined with product according instructions accompanying documentation. - Page 36 4P569819-1 2019.02...
